RV-2-3DH PRODUCT SPECIFICATIONS
2
Various image processing functions
The process mode lets you create and modify inspection algorithms yourself, to process images in various
ways like a multi-functional image processor can. Using the image merge function, you can also inspect a
large part that does not fit in a single image frame.
3D measurement
When a gray code and a striped pattern developed originally by us are projected by 4 pipes of the projector
for 3D using the currently adopted DMD element, a range of 0.2 mm ~ 15 mm can be measured(When the
resolution is 5.0 μm/pixel, a range of 0.2 mm ~ 6mm can be measured). As a result, higher-precision 3D
measurement than the existing e-3D can be performed in addition to an existing clear image.
RV-2-3DH PRODUCT SPECIFICATIONS
3
2. Basic Specification
Item Specification
Model name RV-2-3DH
External dimensions W 940 mm × D 1,276 mm × H 1,530 mm (excluding signal beacon)
Weight 1,000 kg
Electric power
3-phase AC200 to 230 V 50/60 Hz 2.0 kVA or less
* Connection specification
Power supply cable: 2.0 mm
2
x 4-core cable, less than 3 m
Terminal block size: Terminal screw(M4), compatible
power cable
AWG10-14 (2-5.5sq)
Terminal shape: Round terminal with insulation Terminal size 5.5 mm,
compatible screw diameter 4 mm
Air supply pressure
0.49 Mpa Air consumption: 10 L / min
* Connection specification
Hose connection shape: Hi Cupla 20PM (Nitto Kohki)
Reference international standards for machine safety
Machinery Directive EN ISO 12100:2010, EN 60204-1:2006+A1:2009, 2006/42/EC ANNEX I
RV-2-3DH PRODUCT SPECIFICATIONS
4
3. Environment Condition
Transportation and storage conditions
Item Environment condition
Transportation and
storage temperature
+10～+60℃
Transportation and
storage humidity
30% to 80% (with no condensation)
Operating environment condition
Item Environment condition
Ambient temperature
+15～+30℃
Ambient humidity 30% to 65% (with no condensation)
Altitude 1000 m or less from the sea level
Degree of pollution
2 (IEC60664-1 compliant, corresponding to general electronic circuit board
assembly lines)
Overvoltage category III (IEC60664-1 compliant)
