P-311-003 - 第119页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 0912-002 261 23G10056 SENSOR_PHOTO 5 1090003102-061 262 221DA01 1 MACHINE_SCREW 10 1090003102-062 263 221HA203 WASHER 10 1090003102-063 264 221HA003 WASHER 10 1090003102-0…
Fig. C2-3
スクリーン認識部
Stencil Recognition Section
261
283
278
2F6
266
267
2F1
2F7
2F8
2G1
2F9
2G0
2G4
299
2G6
2G3
2G2
2G5
2F5
274
271
272
273
262
265
263
264
288
2F2
2F3
2F4
2B7
2B8
2B9
2C0
2C1
2C2
275
276
277
2B6
2B5
2B2
2C4
2C8
2C5
2C3
2D8
2D3
2D2
2D6
2D1
2D7
2B3
2B1
268
269
270
2B4
280
281
282
2A0
2A1
2A2
294
290
289
295
296
297
291
292
293
See Fig.C2-1
Key No.28
See Fig.C2-1
Key No.87
1102-003
Fig. C2
スキージヘッド部
SQUEEGEE HEAD SECTION
UNIT-2
Fig.C2
SQUEEGEE
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
0912-002
261 23G10056 SENSOR_PHOTO 5 1090003102-061
262 221DA011 MACHINE_SCREW 10 1090003102-062
263 221HA203 WASHER 10 1090003102-063
264 221HA003 WASHER 10 1090003102-064
265 226J2593 PIN 2 1090003102-065
266 221AA017 ROHS_HEX-SCT 8 1090003102-066
267 222L0968 GUIDE_LINEAR 1 1090003102-067
268 221AA034 ROHS_HEX-SCT 2 1090003102-068
269 221HA005 WASHER 2 1090003102-069
270 221HA105 WASHER 2 1090003102-070
271 221DA011 MACHINE_SCREW 2 1090003102-071
272 221HA203 WASHER 2 1090003102-072
273 221HA003 WASHER 2 1090003102-073
274 23G10056 SENSOR_PHOTO 1 1090003102-074
275 221AA017 ROHS_HEX-SCT 4 1090003102-075
276 221HA004 WASHER 4 1090003102-076
277 221HA104 WASHER 4 1090003102-077
278 0900D109 ROHS_HEX-SCT 4 1090003102-078
280 221AA016 ROHS_HEX-SCT 2 1090003102-080
281 221HA004 WASHER 2 1090003102-081
282 221HA104 WASHER 2 1090003102-082
283 211DE733 PLATE 1 1090003102-083
288 221AA120 ROHS_HEX-SCT 4 1090003102-088
289 226J2505 CABLE_VEYOR 1 1090003102-089
290 226J2507 CABLE_VEYOR 1 1090003102-090
291 221AA027 ROHS_HEX-SCT 2 1090003102-091
292 221HA005 WASHER 2 1090003102-092
293 221HA105 WASHER 2 1090003102-093
294 226J2506 CABLE_VEYOR 1 1090003102-094
295 221AA027 ROHS_HEX-SCT 2 1090003102-095
296 221HA005 WASHER 2 1090003102-096
297 221HA105 WASHER 2 1090003102-097
299 211AD559 COVER 1 1090003102-099
2A0 221AA016 ROHS_HEX-SCT 4 1090003102-100
2A1 221HA004 WASHER 4 1090003102-101
2A2 221HA104 WASHER 4 1090003102-102
2B1 4Z110175 LIGHTING UNIT 1 2090006000-001
2B2 4Z100144 SCOPE_UNIT 1 2090006000-002
2B3 4U220095 UNIT CAMERA 1 2090006000-003
2B4 211J1598 STAY 1 2090006000-004
2B5 211G4293 BLOCK 1 2090006000-005
2B6 221AA044 ROHS_HEX-SCT 1 2090006000-006
2B7 221AA042 ROHS_HEX-SCT 2 2090006000-007
2B8 221HA006 WASHER 2 2090006000-008
2B9 221HA106 WASHER 2 2090006000-009
Fig. C2-3
Fig. C2
UNIT-2
Fig. C2
SQUEEGEE
SIGMA-P4
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. C2-3
0912-002
2C0 221AA011 ROHS_HEX-SCT 3 2090006000-010
2C1 221HA003 WASHER 3 2090006000-011
2C2 221HA103 WASHER 3 2090006000-012
2C3 211AD821 COVER 1 2090006000-013
2C4 211AD822 COVER 1 2090006000-014
2C5 221AA099 ROHS_HEX-SCT 2 2090006000-015
2C8 221AA099 ROHS_HEX-SCT 2 2090006000-018
2D1 211AD820 COVER 1 2090006000-021
2D2 211AD819 COVER 1 2090006000-022
2D3 221AA099 ROHS_HEX-SCT 2 2090006000-023
2D6 221AA099 ROHS_HEX-SCT 2 2090006000-026
2D7 221DA002 MACHINE_SCREW 1 2090006000-027
2D8 221DA051 SEMS_PANHEADSCR 2 2090006000-028
2F1 09003108 ASSY_MOTOR 1 2090006001-001
2F2 221AA018 ROHS_HEX-SCT 4 2090006001-002
2F3 221HA004 WASHER 4 2090006001-003
2F4 221HA104 WASHER 4 2090006001-004
2F5 211FA333 BRACKET 1 2090006001-005
2F6 223C0264 COUPLING 1 2090006001-006
2F7 222F0010 BEARING_UNIT 1 2090006001-007
2F8 221AA018 ROHS_HEX-SCT 4 2090006001-008
2F9 223B0459 BALL_SCREW 1 2090006001-009
2G0 221AA018 ROHS_HEX-SCT 4 2090006001-010
2G1 211G4419 BLOCK 1 2090006001-011
2G2 221BA013 BOLT_HEX 1 2090006001-012
2G3 221FA009 NUT_HEX 1 2090006001-013
2G4 211G6282 BLOCK 1 2090006001-014
2G5 213D1308 DISK 1 2090006001-015
2G6 221CA005 SET_SCREW 2 2090006001-016
Fig. C2
UNIT-2
Fig.C2
SQUEEGEE
SIGMA-P4
