P-311-003 - 第216页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE Fig. F1-2 0912-002 1B4 221G0216 NUT 1 3090007009-004 1B5 0900H00H NUT 2 3090007009-005 1B6 221H0138 WASHER 4 3090007009-006 1C1 216B1804 HOLDER 1 309000700G-001 1C2 213A15…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1102-003
102 216C1021 ROD 1 109000700B-002
103 221BA024 BOLT_HEX 2 109000700B-003
104 221HA006 WASHER 2 109000700B-004
105 221HA106 WASHER 2 109000700B-005
106 211FE939 BRACKET 1 109000700B-006
107 221AA017 ROHS_HEX-SCT 2 109000700B-007
108 221HA004 WASHER 2 109000700B-008
109 221HA104 WASHER 2 109000700B-009
110 221DA004 MACHINE_SCREW 4 109000700B-010
111 221HA001 WASHER 4 109000700B-011
112 221HA101 WASHER 4 109000700B-012
113 09007006 ASSY_SENSOR 1 109000700B-013
114 23G00148 SENSOR_PELEC 1 109000700B-014
115 213C0282 ROLLER 1 109000700B-015
116 213D1320 DISK 1 109000700B-016
117 221DA220 RO_MACHIN_SCREW 2 109000700B-017
118 222D0341 BEARING_RADIAL 2 109000700B-018
119 221K0043 RING 2 109000700B-019
120 221DA011 MACHINE_SCREW 2 109000700B-020
121 221HA003 WASHER 2 109000700B-021
122 221HA203 WASHER 2 109000700B-022
124 23G10029 SENSOR_PHOTO 1 109000700B-024
138 221AA017 ROHS_HEX-SCT 12 109000700B-038
139 221HA004 WASHER 12 109000700B-039
140 221HA104 WASHER 12 109000700B-040
161 221FA007 NUT_HEX 4 109000700B-061
162 221HA004 WASHER 4 109000700B-062
163 221HA104 WASHER 4 109000700B-063
164 221CA005 SET_SCREW 2 109000700B-064
165 223Q0626 PULLEY_TIMING 1 109000700B-065
166 223L0392 BELT_TIMING 1 109000700B-066
167 221AA029 ROHS_HEX-SCT 4 109000700B-067
168 221HA005 WASHER 4 109000700B-068
169 221HA105 WASHER 4 109000700B-069
191 23N30721 ACCESS_WIRING(G 1 109000700B-091
194 0900700J ASSY_MOTOR 1 109000700B-094
195 223F0125 GEAR_REDUCTION 1 109000700B-095
196 0900J001 BRACKET 1 109000700B-096
1A1 216B1804 HOLDER 1 309000700A-001
1A2 223Q0756 PULLEY_TIMING 1 309000700A-002
1A3 222D0193 BEARING_RADIAL 2 309000700A-003
1A4 221G0216 NUT 1 309000700A-004
1B1 216B1804 HOLDER 1 3090007009-001
1B2 0900H00Z PULLEY_TIMING 1 3090007009-002
1B3 222D0193 BEARING_RADIAL 2 3090007009-003
Fig. F1-2
Fig. F1
UNIT-5
Fig. F1
CLEANING
SIGMA-P4
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. F1-2
0912-002
1B4 221G0216 NUT 1 3090007009-004
1B5 0900H00H NUT 2 3090007009-005
1B6 221H0138 WASHER 4 3090007009-006
1C1 216B1804 HOLDER 1 309000700G-001
1C2 213A1578 SHAFT 1 309000700G-002
1C3 222D0193 BEARING_RADIAL 2 309000700G-003
1C4 221G0216 NUT 1 309000700G-004
1C5 222M1509 SPRING_COMP 1 309000700G-005
Fig. F1
UNIT-5
Fig. F1
CLEANING
SIGMA-P4
MEMO
