P-311-003 - 第250页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 1B4 23N201 17 TUBE_WIRING 14 109000500A-014 1B5 23N30737 ACCESS_WIRING(M 6 109000500A-015 1B6 23N201 15 TUBE_WIRING 4 109000500A-016 1B8 23N3001 1 ACCESSORY_WRING 3 109000…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1102-003
136 221AA030 ROHS_HEX-SCT 1 109000101R-036
137 221HA005 WASHER 2 109000101R-037
138 221HA105 WASHER 2 109000101R-038
146 221HA303 ROHS_WASHER 1 109000101R-046
149 221AA043 ROHS_HEX-SCT 2 109000101R-049
150 221HA006 WASHER 2 109000101R-050
151 221HA106 WASHER 2 109000101R-051
164 23K20117 ACCESSORY_CONN 2 109000101R-064
165 4J100919 CONNECTOR 2 109000101R-065
166 23K20110 ACCESSORY_CONN 1 109000101R-066
167 4J100920 CONNECTOR 1 109000101R-067
168 23K20118 ACCESSORY_CONN 3 109000101R-068
169 221DA012 MACHINE_SCREW 12 109000101R-069
170 221HA003 WASHER 12 109000101R-070
171 221HA103 WASHER 12 109000101R-071
172 211J1660 STAY 1 109000101R-072
181 0900F01E SUPPORT 1 1090001100-001
182 211AD958 COVER 1 1090001100-002
183 4U210135 UNIT_DISPLAY 1 1090001100-003
184 211AD957 COVER 1 1090001100-004
185 211AE070 COVER 1 1090001100-005
187 211AD970 COVER 1 1090001100-007
188 211AE289 COVER 1 1090001100-008
189 211AD966 COVER 1 1090001100-009
190 221AA100 ROHS_HEX-SCT 4 1090001100-010
191 221DA202 MACHINE_SCREW 4 1090001100-011
192 221DA217 RO_MACHIN_SCREW 4 1090001100-012
193 221DA207 MACHINE_SCREW 8 1090001100-013
194 221DA138 MACHINE_SCREW 2 1090001100-014
195 221FA007 NUT_HEX 4 1090001100-015
196 221HA004 WASHER 4 1090001100-016
197 221HA104 WASHER 4 1090001100-017
1A1 211C1554 PANEL 1 109000500A-001
1A2 4S1B0085 SWITCH_BUTTON 1 109000500A-002
1A3 4T400003 DISPLAY_ELEMENT 1 109000500A-003
1A4 23H20029 ACCESSORY_SW 1 109000500A-004
1A5 4S1B0032 SWITCH_BUTTON 1 109000500A-005
1A6 4S1B0012 SWITCH_BUTTON 1 109000500A-006
1A7 23H20003 ACCESSORY_SW 1 109000500A-007
1A8 4S1B0180 SWITCH_BUTTON 1 109000500A-008
1A9 23K10433 CASE_CONN 1 109000500A-009
1B0 23K10402 CASE_CONN 1 109000500A-010
1B1 4J300191 CAB_JOINTTERMIN 13 109000500A-011
1B2 0914B907 TERMINAL 4 109000500A-012
1B3 23N20103 TUBE_WIRING 23 109000500A-013
Fig. G1-2
Fig. G1
UNIT-6
Fig. G1
MECHA
SIGMA-P4
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1B4 23N20117 TUBE_WIRING 14 109000500A-014
1B5 23N30737 ACCESS_WIRING(M 6 109000500A-015
1B6 23N20115 TUBE_WIRING 4 109000500A-016
1B8 23N30011 ACCESSORY_WRING 3 109000500A-018
1B9 0900B00V CORD 1 109000500A-019
1C0 0900B019 CORD 2 109000500A-020
Fig. G1-2
1102-003
Fig. G1
UNIT-6
Fig. G1
MECHA
SIGMA-P4
