Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE Fig. G1-5 1 102-003 Fig. G1 4C5 0900B00Y CORD BK 10-2000 1 109000100P-045 4C6 0900B017 TUBE 5-400 1 109000100P-046 4C7 23N30738 ACCESS_WIRING(M 5 109000100P-047 4C8 6P4500…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1102-003
Fig. G1-5
Fig. G1
436 221AA030 ROHS_HEX-SCT 4 109000101R-036
437 221HA005 WASHER 6 109000101R-037
438 221HA105 WASHER 2 109000101R-038
446 221HA303 ROHS_WASHER 4 109000101R-046
447 221AA029 ROHS_HEX-SCT 2 109000101R-047
481 0900B015 BRACKET 1 109000100P-001
482 211FE903 BRACKET 1 109000100P-002
483 211FE427 BRACKET 1 109000100P-003
485 4S1B0032 SWITCH_BUTTON 1 109000100P-005
486 23H20003 ACCESSORY_SW 1 109000100P-006
487 4S230115 BREAKER 1 109000100P-007
488 226C0247 HANDLE 1 109000100P-008
489 211AC913 COVER 1 109000100P-009
490 4S300006 FUSE_SPECIAL 3 109000100P-010
491 4J200032 FUSE_HOLDER 3 109000100P-011
492 4V360007 SEMICO_VARISTOR 1 109000100P-012
493 4F300089 FILTER_NOISE 2 109000100P-013
494 23K10402 CASE_CONN 1 109000100P-014
495 23K10421 CASE_CONN 1 109000100P-015
496 4J300191 CAB_JOINTTERMIN 6 109000100P-016
497 4J300116 CAB_JOINTTERMIN 3 109000100P-017
498 4J300115 CAB_JOINTTERMIN 9 109000100P-018
499 4J300016 CAB_JOINTTERMIN 5 109000100P-019
4A0 4J300015 CAB_JOINTTERMIN 3 109000100P-020
4A1 226J0373 MOUNTING_BASE 4 109000100P-021
4A2 23N30737 ACCESS_WIRING(M 5 109000100P-022
4A3 23N20107 TUBE_WIRING 3 109000100P-023
4A4 23N20103 TUBE_WIRING 13 109000100P-024
4A5 23N20115 TUBE_WIRING 3 109000100P-025
4A6 23N20109 TUBE_WIRING 5 109000100P-026
4A7 23N20105 TUBE_WIRING 12 109000100P-027
4A8 23N20117 TUBE_WIRING 12 109000100P-028
4A9 23N20110 TUBE_WIRING 4 109000100P-029
4B0 0900B00V CORD BK 26-1500 1 109000100P-030
4B1 0900B00U CORD BL 26-2000 1 109000100P-031
4B2 221DA064 MACHINE_SCREW 1 109000100P-032
4B3 221DA053 MACHINE_SCREW 17 109000100P-033
4B4 221DA062 MACHINE_SCREW 2 109000100P-034
4B5 221DA052 MACHINE_SCREW 1 109000100P-035
4B6 23N30011 ACCESSORY_WRING 2 109000100P-036
4B7 221AA016 ROHS_HEX-SCT 2 109000100P-037
4B8 221HA004 WASHER 2 109000100P-038
4B9 221HA104 WASHER 2 109000100P-039
4C3 0900B00W CORD G/Y 14-150 1 109000100P-043
4C4 0900B00X CORD BK 18-1000 1 109000100P-044
UNIT-6
Fig. G1
MECHA
SIGMA-P4
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. G1-5
1102-003
Fig. G1
4C5 0900B00Y CORD BK 10-2000 1 109000100P-045
4C6 0900B017 TUBE 5-400 1 109000100P-046
4C7 23N30738 ACCESS_WIRING(M 5 109000100P-047
4C8 6P450074 NAME PLATE_NOTICE 3 109000100P-048
4D1 0900B105 BOX 1 209000100L-001
4D2 4S1B0032 SWITCH_BUTTON 1 209000100L-002
4D3 23H20003 ACCESSORY_SW 1 209000100L-003
4D4 4S1B0180 SWITCH_BUTTON 1 209000100L-004
4D5 23K10433 CASE_CONN 1 209000100L-005
4D6 23K10402 CASE_CONN 1 209000100L-006
4D7 4J300191 CAB_JOINTTERMIN 8 209000100L-007
4D8 4J300050 CAB_JOINTTERMIN 4 209000100L-008
4D9 23N20117 TUBE_WIRING 2 209000100L-009
4E0 23N20117 TUBE_WIRING 4 209000100L-010
4E1 23N30737 ACCESS_WIRING(M 4 209000100L-011
4E2 23N20115 TUBE_WIRING 4 209000100L-012
4E4 0921E60M CORD 1 209000100L-014
4E5 0913B204 CORD 1 209000100L-015
UNIT-6
Fig. G1
MECHA
SIGMA-P4
