P-311-003 - 第266页
MEMO
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1102-003
Fig. G1-6
Fig. G1
501 4W205163 CODE 1 2090001012-001
502 0900B002 CORD 1 2090001012-002
503 4W205166 CODE 1 2090001012-003
504 4W205087 CODE 1 2090001012-004
505 0900B001 CORD 1 2090001012-005
506 4W205088 CODE 1 2090001012-006
507 4W205090 CODE 1 2090001012-007
508 4W205030 CODE 1 2090001012-008
509 4W205031 CODE 1 2090001012-009
510 4W205001 CODE 1 2090001012-010
511 4W205016 CODE 1 2090001012-011
512 4W202694 CORD 1 2090001012-012
513 4W204703 CORD 1 2090001012-013
514 4W204575 CORD(USB_5M_A-B 2 2090001012-014
515 4W202695 CORD 2 2090001012-015
516 0900G11C CODEG/Y18-200 1 2090001012-016
517 4J300015 CAB_JOINTTERMIN 1 2090001012-017
518 23N20115 TUBE_WIRING 1 2090001012-018
519 23N20103 TUBE_WIRING 11 2090001012-019
520 23N30182 ACCESS_WIRING 5 2090001012-020
521 221DA053 MACHINE_SCREW 9 2090001012-021
522 23N30632 WIRING 6 2090001012-022
523 23N30738 ACCESS_WIRING(M 6 2090001012-023
524 23N30737 ACCESS_WIRING(M 24 2090001012-024
525 4W410068 WIRE_PARTS 2 2090001012-025
526 6P450074 NAME PLATE_NOTICE 1 2090001012-026
527 23N30181 ACCESS_WIRING 1 2090001012-027
UNIT-6
Fig. G1
MECHA
SIGMA-P4
MEMO
UNIT-7: ELECTRICAL SECTION
1102-003
Fig. H1
Electrical Box
A
VIEW A
ELECTRICAL SECTION
