P-311-003 - 第30页
MEMO
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
0912-002
Fig. A1
Fig. A1-5
401 0900A204 TUBE 1 1090000201-001
402 0900A205 TUBE 1 1090000201-002
403 0900A206 TUBE 1 1090000201-003
404 0900A204 PIPE_FITTINGS 2 1090000201-004
405 0900A205 PIPE_FITTINGS 1 1090000201-005
406 0900A206 PIPE_FITTINGS 1 1090000201-006
SIGMA-P4
SIGMA-P4
Fig. A1
UNIT LAYOUT
MEMO
0912-002
TABLE, PCB CHUCK SECTION
()Fig. B1
Table, PCB CHUCK Section(REAR REFERENCE)
()Fig. B1
Table, PCB CHUCK Section(FRONT REFERENCE)
UNIT-1: TABLE, PCB CHUCK SECTION
