P-311-003 - 第328页
Fig. I1-3 センターフレーム Center Frame 207 208 209 207 208 209 236 238 239 236 238 239 236 238 239 237 238 240 237 238 240 236 238 239 221 230 230 225 228 229 229 226 230 230 224 228 227 233 234 235 222 222 DE T AI L “B” B 255 …
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1102-003
118 211FE443 BRACKET 1 109000501H-018
123 221AA029 ROHS_HEX-SCT 14 109000501H-023
124 221HA005 WASHER 14 109000501H-024
125 221HA105 WASHER 14 109000501H-025
126 221AA024 ROHS_HEX-SCT 3 109000501H-026
127 221HA004 WASHER 3 109000501H-027
128 221HA104 WASHER 3 109000501H-028
131 211AE242 COVER 1 2090005009-001
132 211J1644 STAY 1 2090005009-002
133 211DE658 PLATE 2 2090005009-003
134 0900F00E SUPPORT 1 2090005009-004
135 23H20053 ACCESS_SW_(KEY) 1 2090005009-005
136 221AA006 ROHS_HEX-SCT 7 2090005009-006
137 221HA003 WASHER 7 2090005009-007
138 221HA103 WASHER 5 2090005009-008
139 221FA006 NUT_HEX 11 2090005009-009
140 221EA099 ROHS_BOLT 2 2090005009-010
141 221HA004 WASHER 2 2090005009-011
142 221HA104 WASHER 2 2090005009-012
144 221EA097 ROHS_BOLT 2 2090005009-014
145 0900F00K PLATE 2 2090005009-015
154 4S1F0051 SWITCH_LIMIT 1 309000500B-004
155 9W310120 CORD 1 309000500B-005
156 23K10434 CASE_CONN 1 309000500B-006
157 4J300191 CAB_JOINTTERMIN 8 309000500B-007
158 4J300174 CAB_JOINTSLEEVE 14 309000500B-008
159 23N20103 TUBE_WIRING 1 309000500B-009
160 23N20117 TUBE_WIRING 2 309000500B-010
161 23N30737 ACCESS_WIRING(M 1 309000500B-011
162 0921E60M CORD 1 309000500B-012
163 0921E60N CORD 1 309000500B-013
Fig. I1-2
Fig. I1
UNIT-8
Fig. I1
COVER
SIGMA-P4
Fig. I1-3
センターフレーム
Center Frame
207
208
209
207
208
209
236
238
239
236
238
239
236
238
239
237
238
240
237
238
240
236
238
239
221
230
230
225
228
229
229
226
230
230
224
228
227
233
234
235
222
222
DE T AI L “B”
B
255
256
259
258 257
261 260 254
242
243
241
244
244
243
241
244
244
242
1102-003
Fig. I1
カバー部
COVER SECTION
UNIT-8
Fig. I1
COVER
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1102-003
207 221AA056 ROHS_HEX-SCT 4 1090005115-007
208 221HA007 WASHER 4 1090005115-008
209 221HA107 WASHER 4 1090005115-009
221 0900F002 FRAME 1 1090001101-001
222 0900B104 COVER 2 1090001101-002
224 211FE435 BRACKET 1 1090001101-004
225 211FE434 BRACKET 1 1090001101-005
226 211FE437 BRACKET 1 1090001101-006
227 211FE436 BRACKET 1 1090001101-007
228 222R0057 SPRING(GUS) 2 1090001101-008
229 222R0054 SPRING(GUS) 2 1090001101-009
230 221C0113 SET_SCREW 4 1090001101-010
233 221AA029 ROHS_HEX-SCT 2 1090001101-013
234 221HA005 WASHER 2 1090001101-014
235 221HA105 WASHER 2 1090001101-015
236 221AA240 ROHS_HEX-SCT 16 1090001101-016
237 221AA043 ROHS_HEX-SCT 16 1090001101-017
238 221HA006 WASHER 32 1090001101-018
239 221HA106 WASHER 16 1090001101-019
240 221HA304 ROHS_WASHER 16 1090001101-020
241 0900F11H GUL_HINGE_BRACK 1 3090001102-001
242 211FE109 BRACKET 1 3090001102-002
243 216D0546 PIN_HINGE 1 3090001102-003
244 221KB003 RING_E_06W 1 3090001102-004
254 4T3A0235 PILOT_LAMP 1 3090005007-004
255 23K10433 CASE_CONN 1 3090005007-005
256 4J300191 CAB_JOINTTERMIN 5 3090005007-006
257 23N20111 TUBE_WIRING 4 3090005007-007
258 0900G11G TUBE_WIRING 1 3090005007-008
259 23N20103 TUBE_WIRING 1 3090005007-009
260 211DE366 PLATE 1 3090005007-010
261 23N30737 ACCESS_WIRING(M 1 3090005007-011
Fig. I1-3
Fig. I1
UNIT-8
Fig. I1
COVER
SIGMA-P4
