P-311-003 - 第95页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 1 102-003 1 0900910A ASSY_SYUTYU 1 1090003006-001 8 221AA016 ROHS_HEX-SCT 2 1090003006-008 9 221HA004 WASHER 2 1090003006-009 10 221HA104 W ASHER 2 1090003006-010 1 1 0900…
Fig. C1-1
スクリーンフレーム
Stencil Frame
51
50
49
54
47
53
52
48
1
35
72
71
57
40
1
1
55
32
34
39
67
66
65
46
45
44
37
36
8
9
10
37
40
76
75
74
73
76
75
74
73
76
75
74
70
69
68
73
1 1
1
1
1
58
56
63
64
37
38
39
39
37
41
42
41
42
43
41
42
41
42
31
33
1102-003
Fig. C1
スクリーンホルダ部
STENCIL HOLDER SECTION
UNIT-2
Fig. C1
STENCIL
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1102-003
1 0900910A ASSY_SYUTYU 1 1090003006-001
8 221AA016 ROHS_HEX-SCT 2 1090003006-008
9 221HA004 WASHER 2 1090003006-009
10 221HA104 WASHER 2 1090003006-010
11 0900D00S COVER 1 1090003006-011
31 0900D00R PLATE 1 109000300V-001
32 211DD887 PLATE 1 109000300V-002
33 0900D00Q PLATE 1 109000300V-003
34 0900D009 PLATE 1 109000300V-004
35 221AA240 ROHS_HEX-SCT 6 109000300V-005
36 221AA240 ROHS_HEX-SCT 6 109000300V-006
37 226J2593 SHAFT 4 109000300V-007
38 226J2593 SHAFT 2 109000300V-008
39 226J2593 SHAFT 3 109000300V-009
40 221AA240 ROHS_HEX-SCT 8 109000300V-010
41 0900D00B CLAMP 8 109000300V-011
42 216S3292 LEVER 4 109000300V-012
43 211FD494 BRACKET 1 109000300V-013
44 221AA021 ROHS_HEX-SCT 3 109000300V-014
45 221HA004 WASHER 3 109000300V-015
46 221HA104 WASHER 3 109000300V-016
47 225C0058 VALVE 1 109000300V-017
48 211FE686 BRACKET 1 109000300V-018
49 221AA016 ROHS_HEX-SCT 2 109000300V-019
50 221HA004 WASHER 2 109000300V-020
51 221HA104 WASHER 2 109000300V-021
52 225F0307 PIPE_FITTINGS 1 109000300V-022
53 225B0346 AIR_LINE_EQPT 2 109000300V-023
54 225F0368 PIPE_FITTINGS 2 109000300V-024
55 222L0925 GUIDE_LINEAR 1 109000300V-025
56 222L0924 GUIDE_LINEAR 1 109000300V-026
57 221AA031 ROHS_HEX-SCT 7 109000300V-027
58 221AA031 ROHS_HEX-SCT 10 109000300V-028
63 0900D00U BRACKET 1 109000300V-033
64 23G10056 SENSOR_PHOTO 2 109000300V-034
65 221DA010 MACHINE_SCREW 4 109000300V-035
66 221HA203 WASHER 4 109000300V-036
67 221HA003 WASHER 4 109000300V-037
68 221AA016 ROHS_HEX-SCT 2 109000300V-038
69 221HA004 WASHER 2 109000300V-039
70 221HA104 WASHER 2 109000300V-040
71 216D0609 PIN_HINGE 1 109000300V-041
72 221K0052 RING 1 109000300V-042
73 225F0519 PIPE_FITTINGS 6 109000300V-043
74 221AA023 ROHS_HEX-SCT 3 109000300V-044
SIGMA-P4
Fig. C1
Fig. C1-1
UNIT-2
Fig. C1
STENCIL
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. C1-1
1102-001
Fig. C1
75 221HA004 WASHER 3 109000300V-045
76 221HA104 WASHER 3 109000300V-046
SIGMA-P4
UNIT-2
Fig. C1
STENCIL
