1 7 Push-in 7 Conveyor Unit KV6-080508 1 2 9 12 4 5 13 13 16 16 15 6 7 3 10 11 NORMAL 8 14 No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level 1 KGA-M9221-00X PLA TE PUSH IN 1 (2002/11/27) OK / 2-…
2
6
Attachment 30cc
Attachment
KV6-0705
15
16
11
12
14
4
2
3
10
9
9
7
1
5
8
6
17
16
18
13
EFD 30cc
MUSASHI, IEI 30cc
OLD
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KM4-M7175-00X MUFFLER: ANB1-C06 1 /
2 KM4-M7176-01X CAP, SYRINGE IEI 30CC 1 /
3 KM4-M7177-20X SYRINGE COVER 30CC 1 /
4 90990-17J019 O-RING 1 /
5 KM4-M7182-00X TUBE: TSU0805N 350 mm /
6 $TSR8-01 JOINT 1 /
7 $SL6-M5 JOINT 1 /
8 KV6-M7179-00X PLATE, STOPPER 1 /
9 90990-22J005 PACKING 2 /
10 91317-05008 BOLT HEX. SOCKET HEAD 1 /
11 KG3-M7118-00X PISTON 1 /
12 91317-05090 BOLT HEX. SOCKET HEAD 1 /
13 KGM-M7172-00X ADAPTA ASSY 30CC 1 /
14 KV6-M7190-00X HOLDER, ADAPTA (30CC) 1 MUSASHI, IEI 30cc /
15 KV6-M7191-01X ADAPTA, RING (30CC) 1 /
16 KV6-M7193-00X NUT, ADAPTA (30CC) 1 /
17 KV6-M7191-20X ADAPTA, RING EFD30CC 1 /
18 KV6-M7190-20X HOLDER, ADAPTA (EFD30CC) 1 EFD 30cc /
1
7
Push-in
7 Conveyor Unit
KV6-080508
1
2
9
12
4
5
13
13
16
16
15
6
7
3
10
11
NORMAL
8
14
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KGA-M9221-00X PLATE PUSH IN 1 (2002/11/27) OK /
2-1 KV7-M9222-00X BRACKET,PUSH IN 1 T=3.2 /
2-2 KV7-M9222-01X BRACKET,PUSH IN 1 T=2.0 (2006/1/13) NG /
3 KV7-M9223-00X HOLDER CYL. 1 /
4 KV7-M9224-01X COLLAR 1 L=7.5 (2006/2/20) Set /
5-1 KV7-M9225-00X BRACKET,HOLDER 1 T=3.2 /
5-2 KV7-M9225-01X BRACKET,HOLDER 1 T=2.0 (2006/1/13) NG /
6 90990-41J061 COLLAR 1 (2008/4/17) OK /
7 KV7-M9227-01X BLOCK,COLLAR 1 (2006/2/20) Set /
8 90933-03J694 BEARING 1 (2002/3/12) OK /
9 KG7-M9166-00X CYLINDER 1 (2003/8/29) OK B
10 KJ9-M177F-11X Y-KNUCKLE 1 (2005/11/3) OK /
11 $SC4-M5A SPEED CONTROLLER 2 /
12 91317-04006 BOLT HEX.SOCKET HEAD 2 /
13 91317-04008 BOLT HEX.SOCKET HEAD 4 /
14 91317-04014 BOLT HEX.SOCKET HEAD 1 /
15 91317-04016 BOLT HEX.SOCKET HEAD 1 /
16 92907-04200 WASHER PLAIN 2 /
2
7
Push-Up
Conveyor
KV6-080617
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KV7-M9201-00X BRACKET, MOTOR 1 /
2 KV7-M9202-00X STAY, ADJUST 1 /
3 KV7-M9203-00X SHAFT 1 2 /
4-1 KV7-M9205-00X PULLEY 1 1 (BANDO) /
4-2 KV7-M9205-01X PULLEY 1 1 P22-3GT (UNITTA)
2001/10/18
NG /
5 90990-28J076 WASHER 1
(2007/12/18)
OK /
6 90K55-523D5U AC SERVO MOTOR 1 B
7 90933-01J200 BEARING 4
(2001/6/29)
OK A
8 99009-10400 CIRCLIP 2 /
9 KV7-M9204-00X SHAFT 2 1 /
10 KV7-M9207-00X FLANGE 1 1 /
11 KV7-M9208-00X FLANGE 2 1 /
12-1 KV7-M9209-00X PULLEY 2 1 (BANDO) /
12-2 KV7-M9209-01X PULLEY 2 1 P60-3GT (UNITTA)
2001/10/18
NG /
13 KV7-M9211-00X HOUSING 1 /
14 90990-41J060 COLLAR 1
(2008/4/17)
OK /
15 KV7-M9213-00X NUT 1 /
16 KV7-M9214-00X SCREW 1 /
17 KV7-M9215-00X JOINT 1 /
18 KV7-M9217-00X FLANGE 1 /
19 KV7-M9218-00X SPRING 1 /
20 KV7-M921C-00X ROLLER 1 /
21 90933-01J905 BEARING 3 2 6905ZZ /
22 99009-42500 CIRCLIP 1 /
23 99009-25400 CIRCLIP 1 /
24 KV7-M9219-00X STOPPER 1 /
25 KV7-M921B-00X BOLT, STOPPER 1 /
26 KV7-M920D-00X DOG 1 /
27 KV7-M920E-00X BRACKET 1 /
28 KGA-M921G-00X SENSOR, ORG 1
(2002/2/28)
OK B
29-1
KGA-M920A-00X PLATE 440 1 W440 /
KGA-M920A-10X PLATE 382 1 W382 /
KGA-M920A-20X PLATE 335 1 W335 /
29-2
KGA-M920A-01X PLATE 440 1 W440
(2001/3/15)
NG /
KGA-M920A-11X PLATE 382 1 W382
(2001/3/15)
NG /
KGA-M920A-21X PLATE 335 1 W335
(2001/3/15)
NG /
30-1 KV7-M920C-00X STAY,F 1 /
30-2
KGA-M920C-00X STAY 1 W440
(2001/3/15)
NG /
KGA-M920C-10X STAY 1 W382
(2001/3/15)
NG /
KGA-M920C-20X STAY 1 W335
(2001/3/15)
NG /
31-1
KV7-M921A-00X BELT 1 W440,W382,W335 (BANDO) B
KV7-M921A-30X BELT 1 W250 (BANDO) B
31-2
KV7-M921A-01X BELT 1 W440,W382,W335 (UNITTA)
2001/10/18
NG B
KV7-M921A-31X BELT 1 W250 (UNITTA)
2001/10/18
NG B
32 91317-04008 BOLT HEX. SOCKET HEAD 2 /
33 91317-04010 BOLT HEX. SOCKET HEAD 10 /
34 91317-04012 BOLT HEX. SOCKET HEAD 1 /
35 91317-04022 BOLT HEX. SOCKET HEAD 2
(2002/2/1)
OK /
36 91317-05012 BOLT HEX. SOCKET HEAD 8 /
37 91317-05014 BOLT HEX. SOCKET HEAD 4 /
38 91317-05016 BOLT HEX. SOCKET HEAD 2 /
39 91317-05020 BOLT HEX. SOCKET HEAD 8 /
40 91317-06060 BOLT HEX. SOCKET HEAD 1 /
40 92A08-03306 SCREW,SET 1
(2001/9/21)
OK /
42 92907-04200 WASHER PLAIN 2 /
43 92907-06200 WASHER PLAIN 1 /
44 92990-04200 WASHER PLAIN 1 /
45 KGA-M921T-00X BOLT 4 /
46 95602-10100 NUT U 4
(2006/1/10)
OK /
47 92907-10600 WASHER PLAIN 1 M10
(2003/11/13)
/
48 KV7-M921D-10X PUSH UP PIN UNIT 9 /
49-1 KGA-M920A-30X PLATE 250 1 W250 FigA /
49-2 KGA-M920A-31X PLATE 250 1 W250 FigB
(2001/3/15)
NG /
49-3 KGA-M920A-32X PLATE 250 1 W250 FigC
2003/4/22
NG /
50-1 KV7-M920C-30X STAY,F 1 W250 FigD /
50-2 KGA-M920C-30X STAY 1 W250 FigE
(2001/3/15)
NG /
50-3 KGA-M920C-31X STAY 1 W250 FigF
2003/4/22 NG /
6
29
48
2
35
30
31
35
4
37
33
1
5
34
36
45
46
36
40
43
7
7
9
38
42
38
42
3
3
7
7
8
8
7
7
16
21
22
14
21
23
13
33
15
17
41
20
12
11
32
44
26
39
27
28
39
19
33
18
10
33
25
24
47
4
OLD
29
30
OLD
W250
OLD
49 FigC
49 FigB
49 FigA
50 FigF
50 FigE
50 FigD
