3 Technical data and assemblies User manual SIPLACE X-Series
3.1 Performance data From software version 708.1 Version 05/2015
106
3.1.2 Machine performance SIPLACE X4i S
3
Placement head types SIPLACE SpeedStar (C&P20)
SIPLACE SpeedStar (C&P20 P)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
Definition of placement performance
For a definition of placement performance values, see the note on page 105.
SIPLACE X4i S
Placement performance
See the note above for definition of placement performance values.
Machine Placement area 1 Placement area 2 IPC value Benchmark
value
Theoretical
value
X4i S-A C&P20 / C&P20 C&P20 / C&P20 102,000 120,000 135,500
C&P20 / C&P20 CPP_L/CPP_L 91,500 103,500 123,750
C&P20 / C&P20 CPP_H / CPP_H 85,000 100,000 112,500
C&P20 P / C&P20 P C&P20 P / C&P20 P 125,000 150,000 200,000
C&P20 P / C&P20 P CPP_L/CPP_L 102,000 120,000 160,000
C&P20 P / C&P20 P CPP_H / CPP_H 100,300 118,000 157,300
CPP_L/CPP_L CPP_L/CPP_L 79,900 94,000 112,000
CPP_L/CPP_L CPP_H / CPP_H 73,950 87,000 97,800
CPP_H / CPP_H CPP_H / CPP_H 68,000 80,000 90,000
X4i S-B C&P20 / C&P20 CPP_H/TH 72,250 85,000 96,600
C&P20 P / C&P20 P CPP_H/TH 85,000 99,900 133,200
CPP_L/CPP_L CPP_H/TH 58,150 68,400 77,500
CPP_H / CPP_H CPP_H/TH 52,190 61,400 69,075
X4i S-C C&P20 / C&P20 TH / TH 60,350 71,000 80,700
C&P20 P / C&P20 P TH / TH 70,900 85,500 114,000
CPP_L/CPP_L TH / TH 49,300 58,000 65,900
CPP_H / CPP_H TH / TH 43,350 51,000 57,300
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
Important notes
When setting up a machine (S; F, HS, HF, X or D-Series) next to a SIPLACE X-Series, be aware that there is limited room between the two
machines. In these cases, use a suitable conveyor extension to create room of 0.5m for the operator between the two machines.
To achieve top placement performance, fit the first machine in a SIPLACE X-Series S line with a input conveyor extension and the last
machine in the line with an output conveyor extension.
User manual SIPLACE X-Series 3 Technical data and assemblies
From software version 708.1 Version 05/2015 3.1 Performance data
107
3.1.3 SIPLACE X4 S machine performance
3
Placement head types SIPLACE SpeedStar (C&P20)
SIPLACE SpeedStar (C&P20 P)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
SIPLACE X4 S
Placement performance
For a definition of placement performance values, see the note on page 105.
Placement area 1 Placement area 2 IPC value Benchmark
value
Theoretical
value
X4 S-A C&P20 / C&P20 C&P20 / C&P20 85,000 100,000 136,400
C&P20 / C&P20 CPP_L/CPP_L 79,475 93,500 129,800
C&P20 / C&P20 CPP_H / CPP_H 75,650 89,000 120,000
C&P20 P / C&P20 P C&P20 P / C&P20 P 105,000 125,000 170,500
C&P20 P / C&P20 P CPP_L/CPP_L 90,500 106,500 145,250
C&P20 P / C&P20 P CPP_H / CPP_H 86,250 101,500 138,450
CPP_L/CPP_L CPP_L/CPP_L 74,800 88,000 123,200
CPP_L/CPP_L CPP_H / CPP_H 70,550 83,000 112,500
CPP_H / CPP_H CPP_H / CPP_H 66,300 78,000 106,000
X4 S-B C&P20 / C&P20 CPP_H/TH 62,900 74,000 102,300
C&P20 P / C&P20 P CPP_H/TH 68,500 81,000 110,480
CPP_L/CPP_L CPP_H/TH 57,800 68,000 95,700
CPP_H / CPP_H CPP_H/TH 53,550 63,000 85,650
X4 S-C C&P20 / C&P20 TH / TH 50,150 59,000 82,500
C&P20 P / C&P20 P TH / TH 60,500 71,500 97,520
CPP_L/CPP_L TH / TH 45,050 53,000 75,900
CPP_H / CPP_H TH / TH 40,800 48,000 65,250
X4 S-D CPP_H/TH TH / TH 28,050 33,000 48,400
X4 S-E TH / TH TH / TH 15,300 18,000 28,600
Important notes
When setting up a machine (S; F, HS, HF, X or D-Series) next to a SIPLACE X-Series, be aware that there is limited room between the two
machines. In these cases, use a suitable conveyor extension to create room of 0.5m for the operator between the two machines.
To achieve top placement performance, fit the first machine in a SIPLACE X-Series S line with a input conveyor extension and the last
machine in the line with an output conveyor extension.
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
3 Technical data and assemblies User manual SIPLACE X-Series
3.1 Performance data From software version 708.1 Version 05/2015
108
3.1.4 Machine performance SIPLACE X4 S micron
3
3.1.5 Machine performance SIPLACE X4i S micron
3
Placement head types SIPLACE SpeedStar (C&P20 M)
SIPLACE MultiStar (CPP)
SIPLACE X4 S micron
Placement performance
For a definition of placement performance values, see the note on page 105.
Placement area 1 Placement area 2 IPC value Benchmark
value
Theoretical
value
C&P20 M / C&P20 M C&P20 M / C&P20 M 82,000
*a
90,000
a
124,000
a
C&P20 M / C&P20 M C&P20 M / C&P20 M 62,000
*b
70,000
b
95,000
b
C&P20 M / C&P20 M CPP_L/CPP_L 86,500 102,000 145,000
C&P20 M / C&P20 M CPP_H / CPP_H 86,000 95,000 134,400
*)a Without "High Precision" option
*)b With "High Precision" option
Placement head types SIPLACE SpeedStar (C&P20 M)
SIPLACE MultiStar (CPP)
SIPLACE X4i S micron
Placement performance
For a definition of placement performance values, see the note on page 105.
Placement area 1 Placement area 2 IPC value Benchmark
value
Theoretical
value
C&P20 M / C&P20 M C&P20 M / C&P20 M 102,000 120,000 135,500
C&P20 M / C&P20 M CPP_L/CPP_L 91,500 103,500 123,750
C&P20 M / C&P20 M CPP_H / CPP_H 85,000 100,000 112,500
Important notes
When setting up a machine (S; F, HS, HF, X or D-Series) next to a SIPLACE X-Series, be aware that there is limited room between the two
machines. In these cases, use a suitable conveyor extension to create room of 0.5m for the operator between the two machines.
To achieve top placement performance, fit the first machine in a SIPLACE X-Series S line with a input conveyor extension and the last
machine in the line with an output conveyor extension.
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
