3 Technical data and assemblies User manual SIPLACE X-Series
3.1 Performance data From software version 708.1 Version 05/2015
110
3.1.7 SIPLACE X2 S machine performance
3
Placement head types SIPLACE SpeedStar (C&P20)
SIPLACE SpeedStar (C&P20 P)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
Placement performance
SIPLACE X2 S
For a definition of placement performance values, see the note on page 105.
Machine Placement area 1 Placement area 2 IPC value Benchmark
value
Theoretical
value
X2 S-A C&P20 C&P20 45,000 54,000 68,200
C&P20 CPP_L 40,200 49,500 64,900
C&P20 CPP_H 38,250 46,500 59,900
C&P20 P C&P20 P 52,000 62,500 85,250
C&P20 P CPP_L 45,500 53,750 73,300
C&P20 P CPP_H 43,000 50,750 69,220
CPP_L CPP_L 37,400 45,000 61,600
CPP_H CPP_H 33,500 39,000 55,500
CPP_L CPP_H 35,450 42,000 57,900
X2 S-B C&P20 TH 27,000 32,000 40,750
C&P20 P TH 30,800 36,250 49,450
CPP_L TH 24,000 27,500 37,450
CPP_H TH 20,600 24,500 32,900
X2 S-C TH TH 9,000 10,000 13,000
Important notes
When setting up a machine (S; F, HS, HF, X or D-Series) next to a SIPLACE X-Series, be aware that there is limited room
between the two machines. In these cases, use a suitable conveyor extension to create room of 0.5m for the operator between
the two machines.
To achieve top placement performance, fit the first machine in a SIPLACE X-Series S line with a input conveyor extension and
the last machine in the line with an output conveyor extension.
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
User manual SIPLACE X-Series 3 Technical data and assemblies
From software version 708.1 Version 05/2015 3.1 Performance data
111
3.1.8 Placement data
3
Component range
*a
03015 to max. 200 mm x 110 mm
Component height C&P20 4 mm
C&P20 P 4 mm
C&P20 M 4 mm
CPP
*b
6 mm
CPP
*c
8.5 mm to 11.5 mm
TH 25 mm (greater height on request)
X/Y accuracy
*d
C&P20 ± 41 μm (3σ), ± 55 μm (4σ) Component camera, type 23 (6 x 6)
C&P20 ± 41 μm (3σ), ± 55 μm (4σ) Component camera, type 41 (6 x 6)
C&P20 P ± 36μm (3σ), ± 48 μm (4σ) Component camera, type 23 (6 x 6)
C&P20 P ± 36 μm (3σ), ± 48 μm (4σ) Component camera, type 41 (6 x 6)
C&P20 M ± 25 μm (3σ)
*e
Component camera, type 41 (6 x 6)
C&P20 M ± 20 μm (3σ)
*f
Component camera, type 41 (6 x 6)
CPP ± 41 μm (3σ), ± 55 μm (4σ) Component camera, type 30 (27 x 27)
CPP ± 34 μm (3σ), ± 45 μm (4σ) Component camera, type 33 (55 x 45)
TH ± 26 μm (3σ), ± 35 μm (4σ) Component camera, type 33 (55 x 45)
TH ± 22 μm (3σ), ± 30 μm (4σ) Component camera, type 25 (16 x 16)
Angular accuracy C&P20 ± 0.5° (3σ), ± 0.7° (4σ) Component camera, type 23 (6 x 6)
C&P20 ± 0.5° (3σ), ± 0.7° (4σ) Component camera, type 41 (6 x 6)
C&P20 P ± 0.5° (3σ), ± 0.7° (4σ) Component camera, type 23 (6 x 6)
C&P20 P ± 0.5° (3σ), ± 0.7° (4σ) Component camera, type 41 (6 x 6)
C&P20 M ± 0.5° (3σ) Component camera, type 41 (6 x 6)
CPP
*g
± 0.4° (3σ), ± 0.5° (4σ) Component camera, type 30 (27 x 27)
CPP
*h
± 0.5° (3σ), ± 0.7° (4σ) Component camera, type 30 (27 x 27)
CPP ± 0.2° (3σ), ± 0.3° (4σ) Component camera, type 33 (55 x 45)
TH ± 0.05° (3σ), ± 0.07° (4σ) Component camera, type 33 (55 x 45)
TH ± 0.05° (3σ), ± 0.07° (4σ) Component camera, type 25 (16 x 16)
*)a Please note that the placeable component range is also affected by the pad geometry, the customer-specific standards, the
component packaging tolerances and the component tolerances.
*)b CPP head: in low installation position (stationary component camera not possible).
*)c CPP head: in high installation position
*)d The accuracy value, measured using the vendor-neutral IPC standard.
*)e SIPLACE X4 S micron without "High Precision" option.
*)f SIPLACE X4 S with "High Precision" option.
*)g Component dimensions between 6 mm x 6 mm and 27 mm x 27 mm.
*)h Component dimensions smaller than 6 mm x 6 mm.
3 Technical data and assemblies User manual SIPLACE X-Series
3.1 Performance data From software version 708.1 Version 05/2015
112
3.1.9 PCB conveyor data SIPLACE X2 S / X3 S / X4 S / X4i S
3
Single conveyor Flexible dual con-
veyor
Dual conveyor in sin-
gle conveyor mode
Board dimensions
(length x width
*a
)
X2 S / X3 S / X4 S - standard 50 mm x 50 mm to
450 mm x 560 mm
50 mm x 50 mm to
450 mm x 320 mm
50 mm x 50 mm to
450 mm x 560 mm
X2 S / X3 S / X4 S - long board
*b
*c
50 mm x 50 mm to
850 mm x 560 mm
50 mm x 50 mm to
850 mm x 320 mm
50 mm x 50 mm to
850 mm x 560 mm
X4i S - standard
*d
50 mm x 50 mm to
380 mm x 560 mm
50 mm x 50 mm to
450 mm x 300 mm
50 mm x 50 mm to
450 mm x 510 mm
50 mm x 50 mm to
450 mm x 510 mm
50 mm x 50 mm to
380 mm x 320 mm
--
X4i S - long board
b
50 mm x 50 mm to
610 mm x 510 mm
50 mm x 50 mm to
610 mm x 300 mm
50 mm x 50 mm to
610 mm x 510 mm
Stationary conveyor side Right or left Right, left or outer
Automatic electrical width adjust-
ment
Standard
PCB thickness
Standard 0.3 mm to 4.5 mm
PCB warpage See page 165
PCB weight
*e
Standard Max. 3.0 kg Max. 2.0 kg Max. 2.0 kg
Clearance on PCB underside 25 mm
PCB conveyor height
Option
Standard
Option SMEMA
900 mm
930 mm
950 mm
Type of interface
Standard
Option
SMEMA
Siemens
Component-free PCB handling
edge
3 mm
PCB changeover time
Single conveyor
Dual conveyor
*f
< 1.5 seconds
0 seconds
*)a When using board widths > 450 mm, make sure that the peripheral modules can also process these board widths.
*)b The "long board option" requires a license.
*)c Boards from 650 mm length require an additional input and output conveyor extension.
*)d I-PLacement and alternating placement mode are possible with board lengths up to 380 mm. Only alternating place-
ment mode is possible for boards longer than 380 mm.
*)e The board weight value refers to the weight of the board plus the weight of the components.
*)f 0 seconds in asynchronous mode, otherwise 1.5 seconds.
Important notes
When setting up a machine (S; F, HS, HF, X or D-Series) next to a SIPLACE X-Series, be aware that there is limited room between the two
machines. In these cases, use suitable conveyor extensions to create room of 0.5m for the operator between the two machines.
To achieve top placement performance, fit the first machine in a SIPLACE X-Series line with an input conveyor extension and the last
machine in the line with an output conveyor extension.
