3 Technical data and assemblies User manual SIPLACE X-Series
3.2 Ambient conditions and connection values From software version 708.1 Version 05/2015
116
3.2.3 Electrical ratings and energy consumption
3
SIPLACE X2 S
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 360 V~ to 3 x 480 V~ ± 10 %; 50/60 Hz
3 x 200 V~ to 3 x 240 V~ ± 10 %; 50/60 Hz
*a
3 x16 A characteristic C
3 x25 A characteristic C
Mains power con-
nection
Cable 5 x 4 mm² 5 x 25 A with CEKON connector (3 x 360 V~ to 3 x 480 V~)
Cable 5 x 4 mm² 5 x 25 A (3 x 200 V~ to 3 x 240 V)
Energy consumption
With a vacuum pump
*b
With two vacuum pumps
b
Without vacuum pumps
*c
Nominal apparent
power
2.7 kVA -- 1.4 kVA
Nominal active
power
1.8 kW -- 1.1 kW
SIPLACE X3 S
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 360 V~ to 3 x 480 V~ ± 10 %; 50/60 Hz
3 x 200 V~ to 3 x 240 V~ ± 10 %; 50/60 Hz
a
3 x16 A characteristic C
3 x25 A characteristic C
Mains power con-
nection
Cable 5 x 4 mm² 5 x 25 A with CEKON connector (3 x 360 V~ to 3 x 480 V~)
Cable 5 x 4 mm² 5 x 25 A (3 x 200 V~ to 3 x 240 V)
Energy consumption
With one vacuum pump
b
With two vacuum pumps
b
Without vacuum pumps
c
Nominal apparent
power
2.7 kVA 4.1 kVA 1.4 kVA
Nominal active
power
1.8 kW 2.6 kW 1.1 kW
*)a With options package
*)b Vacuum pump for C&P20 head only.
*)c Optional
User manual SIPLACE X-Series 3 Technical data and assemblies
From software version 708.1 Version 05/2015 3.2 Ambient conditions and connection values
117
3
SIPLACE X4 S / X4 S micron
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 360 V~ to 3 x 480 V~ ± 10 %; 50/60 Hz
3 x 200 V~ to 3 x 240 V~ ± 10 %; 50/60 Hz
*a
3 x16 A characteristic C
3 x25 A characteristic C
Mains power con-
nection
Cable 5 x 4 mm² 5 x 25 A with CEKON connector (3 x 360 V~ to 3 x 480 V~)
Cable 5 x 4 mm² 5 x 25 A (3 x 200 V~ to 3 x 240 V)
Energy consumption
With a vacuum pump
*b
With two vacuum pumps
b
Without vacuum pumps
*c
Nominal apparent
power
2.7 kVA 4.1 kVA 1.4 kVA
Nominal active
power
1.8 kW 2.6 kW 1.1 kW
SIPLACE X4i S / X4i S micron
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 360 V~ to 3 x 480 V~ ± 10 %; 50/60 Hz
3 x 200 V~ to 3 x 240 V~ ± 10 %; 50/60 Hz
a
3 x16 A characteristic C
3 x25 A characteristic C
Mains power con-
nection
Cable 5 x 4 mm² 5 x 25 A with CEKON connector (3 x 360 V~ to 3 x 480 V~)
Cable 5 x 4 mm² 5 x 25 A (3 x 200 V~ to 3 x 240 V)
Energy consumption
With one vacuum pump
b
With two vacuum pumps
b
Without vacuum pumps
c
Nominal apparent
power
2.7 kVA 4.1 kVA 1.4 kVA
Nominal active
power
1.8 kW 2.6 kW 1.1 kW
*)a With options package
*)b Vacuum pump for C&P20 head only.
*)c Optional
3 Technical data and assemblies User manual SIPLACE X-Series
3.2 Ambient conditions and connection values From software version 708.1 Version 05/2015
118
3.2.4 Compressed air supply and compressed air specification
3
Compressed air supply
Compressed air pressure val-
ues
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
Compressed air connection R 3/4" inner thread (pipe thread) with 1/2" hose connection
Compressed air consumption
*a
Placement head configuration Compressed air
consumption
*b
with vacuum pump
Compressed air con-
sumption
without vacuum
pump
*c
SIPLACE X4i S / X4 S
C&P20/C&P20/C&P20/C&P20
C&P20/C&P20/CPP/CPP
C&P20/C&P20/TH/TH
C&P20/C&P20/CPP_H
*d
/TH
CPP/CPP/CPP/CPP
CPP/CPP/CPP_H/TH
CPP/CPP/TH/TH
CPP/TH/TH/TH
TH/TH/TH/TH
260 Nl/min
370 Nl/min
330 Nl/min
350 Nl/min
480 Nl/min
460 Nl/min
440 Nl/min
420 Nl/min
400 Nl/min
990 Nl/min
720 Nl/min
680 Nl/min
700 Nl/min
480 Nl/min
460 Nl/min
440 Nl/min
420 Nl/min
400 Nl/min
SIPLACE X4 S micron
C&P20 M/C&P20 M/C&P20 M/C&P20 M
C&P20 M/C&P20 M/CPP/CPP
260 Nl/min
370 Nl/min
990 Nl/min
720 Nl/mi
SIPLACE X4i S micron
C&P20 M/C&P20 M/C&P20 M/C&P20 M
C&P20 M/C&P20 M/CPP/CPP
260 Nl/min
370 Nl/min
990 Nl/min
720 Nl/min
SIPLACE X3 S
C&P20/C&P20/C&P20
C&P20/C&P20/CPP
C&P20/C&P20/TH
CPP/CPP/CPP
CPP / TH
CPP/TH/TH
TH/TH/TH
185 Nl/min
230 Nl/min
230 Nl/min
360 Nl/min
340 Nl/min
340 Nl/min
300 Nl/min
720 Nl/min
600 Nl/min
590 Nl/min
360 Nl/min
340 Nl/min
340 Nl/min
300 Nl/min
SIPLACE X2 S
C&P20 / C&P20
C&P20/CPP
C&P20/TH
CPP / CPP
CPP / TH
TH / TH
130 Nl/min
185 Nl/min
165 Nl/min
240 Nl/min
220 Nl/min
200 Nl/min
480 Nl/min
360 Nl/min
340 Nl/min
240 Nl/min
220 Nl/min
200 Nl/min
Compressed air specification
Particle size 0.1 µm
Particle density 0.1 mg/m³
Maximum oil content
(class 1)
Particle density 0.01 mg/m³
Pressure dewpoint (class 4) Dewpoint + 3°
*)a Average consumption values.
*)b Under normal atmospheric conditions at 20°C and 1013 hPa.
*)c Optional
*)d CPP_H = Multistar CPP in high assembly position
Please note
The compressed air consumption values are identical for the C&P20, C&P 20 M and C&P20 P.
