Assembly instructions: Vacuum pump for SIPLACE X-series 04/2009 Edition 73 2 2 Y ou will find the current spare part s list at www .siplace.com. Log in, then click “st art” under “ SIPLACE Sp are Parts Cat alog , find yo…

100%1 / 128
Assembly instructions: Vacuum pump for SIPLACE X-series
04/2009 Edition
72
2
2
1 Assembly instructions for vacuum pump, X-series, 70X
Item no.: 00196433-xx
4 Upgrade kit for vacuum, X-series R10, consisting of:
Item no.: 03075305-xx
1 Tube 1
Item no.: 03075307-xx
1 Tube 2
Item no.: 03075308-xx
1 Clamp 1
Item no.: 03072049-xx
1 DIN 125-A 3.2-140HV-St
Item no.: 00095471-xx
1 Mount, complete
Item no.: 03072082-xx
3 DIN912-M3 x 35-A2-70
Item no.: 03045039-xx
2 DIN 9021 - 3.2 - 140 HV - A2
Item no.: 00343075-xx
0.49 m Duo hose
Item no.: 03075472-xx
1 Hose 1, vacuum 2G E
Item no.: 03039017-xx
1 Hose 2, vacuum 2G E
Item no.: 03039018-xx
Vacuum pump installation kit for X4I Item no.: 00119797-xx
1
Upgrade kit: Vacuum electrical circuit for X-series R10, con-
sisting of:
Item no.: 03075734-xx
1 Vacuum pump connecting unit, complete
Item no.: 03071318-xx
1 Cable: Power to vacuum connecting unit
Item no.: 03072411-xx
1 Cable: Sub-distributor - vacuum pump
Item no.: 03075762-xx
2 Power circuit-breaker 3RV10 4.5 - 6.3A 3-pole
Item no.: 03075731-xx
1 Retrofit kit for sub-distributor
Item no.: 03072999-xx
1 Vacuum distributor 4 ports/2 pumps, complete, consisting of:
Item no.: 03075278-xx
1 Vacuum distributor 4 gantries/2 pumps
Item no.: 03075262-xx
8 QS-1/2-16 PLUG-IN THREADED JOINT
Item no.: 03004184-xx
2 Hose nozzle, screw-in, R1 Schl-Di 32
Item no.: 03015219-xx
8 Blanking plug QSC-16H
Item no.: 03051739-xx
1 Angled vacuum connection 03038058, complete
Item no.: 03075301-xx
1 Mount for vacuum connection X, complete
Item no.: 03075466-xx
8 Connecting hose, vacuum pump X
Item no.:03075872 -xx
8 QS-16 plug-in threaded joint
Item no.: 03035036-xx
1 Assembly instructions for vacuum pump, X-series, 70X
Item no.: 00196433-xx
2 Upgrade kit for vacuum, X-series R10, consisting of:
Item no.: 03075305-xx
1 Tube 1
Item no.: 03075307-xx
1 Tube 2
Item no.: 03075308-xx
1 Clamp 1
Item no.: 03072049-xx
1 DIN 125-A 3.2-140HV-St
Item no.: 00095471 -xx
1 Mount, complete
Item no.: 03072082 -xx
3 DIN912-M3 x 35-A2-70
Item no.: 03045039 -xx
2 DIN 9021 - 3.2 - 140 HV - A2
Item no.: 00343075-xx
Assembly instructions: Vacuum pump for SIPLACE X-series
04/2009 Edition
73
2
2
You will find the current spare parts list at www.siplace.com.
Log in, then click “start” under
“SIPLACE Spare Parts Catalog, find your spare part – quickly and easily!”. 2
0.49 m Duo hose
Item no.: 03075472-xx
1 Hose 1, vacuum 2G E
Item no.: 03039017-xx
1 Hose 2, vacuum 2G E
Item no.: 03039018-xx
2 Upgrade kit for vacuum X4i, rotated, consisting of:
Item no.: 03075306-xx
1 Tube 1, rotated
Item no.: 03074600-xx
1 Tube 2, rotated
Item no.: 03074604-xx
1 DIN 125-A 2.5-140HV-A2
Item no.: 00325452- xx
1 DIN 125-A 3.2-140HV-St
Item no.: 00095471-xx
1 DIN912-M3 x 14-A2-70
Item no.: 03045032-xx
1 Mount, complete
Item no.: 03072082-xx
2 DIN912-M3 x 35-A2-70
Item no.: 03045039-xx
2 DIN 9021 - 3.2 - 140 HV - A2
Item no.: 00343075-xx
1 Clamp
Item no.: 03075571-xx
1 DIN912-M3 x 18-A2-70
Item no.: 03006821-xx
1 Mount
Item no.: 03075547-xx
0.49 m Duo hose
Item no.: 03075472-xx
1 Hose 1, vacuum 2G E
Item no.: 03039017- xx
1 Hose 2, vacuum 2G E
Item no.: 03039018- xx
2 Air hose TS1612 B, black nylon 12
Item no.: 03004163-xx
Assembly instructions: Vacuum pump for SIPLACE X-series
04/2009 Edition
74
2.6 Pneumatic system and vacuum supply
2
It is not possible to convert placement machines with serial numbers earlier than B079. 2
2
2
2
The compressed air must not be switched on during the conversion otherwise there is a potential
risk of damaging the placement head. 2
2
The conversion to vacuum pump operation of a placement machine with two C&P20 heads is il-
lustrated below. 2
2
2
No more than two CP20 A placement heads may be connected to a vacuum pump.
For the requirements (which depend on the machine configuration), see Chapter 2.7.2. 2
2
2
2
If a TwinHead or CPP placement head is used, the air supply, the gantry distributor and the cable
and hose carrier for the gantry concerned must NOT be converted as this would stop the Twin-
Head or CPP working. 2
2
2
2
The machine and thus the vacuum pump should not be switched off and on again in quick suc-
cession as this can greatly shorten the service
life of the pump.
Switching the vacuum pump off and on for longer production stoppages, for example, is monitored
by the placement mach
ine. 2
2
