1 − 13 1.1.5 Electrical specifications (1) Number of placement point s Up to 3,000 placement points can be def ined per pr ogram . For multi-mat rix PW Bs, up to 10,000 points can be def ined, which is the number of cir …
1 − 12
(4) Least input placement angle increment
Programmable placement angle setting unit: 0.05°
(5) Automatic tool changer (ATC)
The ATC can accommodate up to 21 nozzles per one head.
(6) Transport rail height
900 mm ± 20 mm
(7) Machine dimensions and weight
W : [KE-2030M] 1,800 mm
[KE-2030L] 1,800 mm
[KE-2030E] 1,800 mm
[KE-2030M] 1,900 mm (including PWB transfer unit)
[KE-2030L] 2,150 mm (including PWB transfer unit)
[KE-2030E] 2,550 mm (including PWB transfer unit)
D : [KE-2030M] 1,326 mm
[KE-2030L] 1,326 mm
[KE-2030E] 1,450 mm
[KE-2030M] 1,510 mm (including keyboard)
[KE-2030L] 1,510 mm (including keyboard)
[KE-2030E] 1,634 mm (including keyboard)
H : [KE-2030M] 1,550 mm
(height of the main unit when the PWB transfer height is 900 mm)
[KE-2030L] 1,834 mm
(height of the vision monitor when the PWB transfer height is 900 mm)
[KE-2030E] 2,200 mm
(height of the signal tower when the PWB transfer height is 900 mm)
Mass: [KE-2030M] 1,880 kg
[KE-2030L] 1,890 kg
[KE-2030E] 1,900 kg
(8) Air requirements
Air pressure : 0.49 ± 0.05 Mpa
Air consumption : 400 L/min.(ANR)
Dry air : Atmospheric dew point -17°C or lower
(9) Noise level
76dB
(10) Country of manufacturing
Manufactured in Japan
(11) Environmental conditions
Operating
Ambient temperature: +10° C to +35° C
Relative humidity: 50% or less (at 35° C)
90% or less (at 20° C)
Transport and storage
Temperature: -25° C to +70° C
Relative humidity: 20% to 95% (No condensation)
1 − 13
1.1.5 Electrical specifications
(1) Number of placement points
Up to 3,000 placement points can be defined per program.
For multi-matrix PWBs, up to 10,000 points can be defined, which is the number
of circuits multiplied by the number of placement points.
(2) Control Systems
Table 1.1.5.1
Item Control system Resolution
X-Y
Z
θ (head)
Y (Movable station)
Closed loop by AC servo motor
Semi-closed loop by AC servo motor
Semi-closed loop by AC servo motor
Semi-closed loop by AC servo motor
0.005mm
0.00125mm
0.02°
0.00025mm
(3) Main CPU
Pemtium
(4) Display
Character display : 10.4" color (TTF liquid crystal display panel)
Graphics display : 9" monochrome
(5) Data and program input/output
A program which has been generated with an external programming device or
manually created from the keyboard can be input by means of a 3.5" floppy disk.
(2HD/1.44 MB type only)
When the machine is connected to a host line computer, the LAN interface
permits high-speed communications.
(6) Printer interface
Centronics interface
(7) Power requirements
Voltage : Three-phase, 200 V, 220 V, 240 V
(for Japan)
200 V, 220 V, 240 V, 380 V, 400 V, 415 V AC
(for the machines to be exported)
Apparent power : 5 kVA
Frequency : 50/60 Hz
Size of the primary-side power cable : 6 mm
2
or more
Size of the protective grounding lead wire : 6 mm
2
or more
1 − 14
(8) UPS
This machine is equipped with the uninterruptible power supply (UPS) to prevent
data from being damaged or lost due to power failure.
Batteries are used as the back-up power supply of the UPS, so the UPS is
designed to stop the system before these batteries run down. Therefore, even
during power failure, the system can be terminated safely so that any data cannot
be damaged or lost even when a power failure occurs.
