6 − 22
Supply Choice:
This combo box is used for switching the Parts no. setup screen:
screen for components set on the front side or that for rear side.
No. Item Description
1 Front Displays the components set on the front side only.
2 Rear Displays the components set on the rear side only.
Station Choice:
This combo box is used for switching the Parts no. setup screens:
screen for components set on the right station or that for left station.
No. Item Description
1 Right Station Displays the components set on the right station only.
2 Left Station Displays the components set on the left station only.
Initial: Enter an initial number of components at the field at which the
input focus is located.
Remain: Enter the number of remaining components at the field at which
the input focus is located.
Level: At the field at which the input focus is located, enter the level of
the number of remaining components at which a warning is
output.
Warning: The input focus does not move to this item. The indication
disappears when the number of remaining components is
validated or when the component replenishing command is
executed.
③ Descriptions of the buttons displayed on the screen
No. Button Description
1 Replenish Comp Enters the value set in the "Initial" field into the "Remain" field of the line at which
the input focus is located, and clears all warnings.
2 Clear Set a value in the “Initial” field to the “Remain” field, and clears all warnings.
3 OK Validates the settings in the displayed "Parts no. setup" screen, quits this screen,
then returns to the screen form which you called this command, the "Production
conditions" or "Production status" screen.
4 Cancel Quits the "Parts no. setup" screen without validating the settings on this screen,
then returns to the screen from which you called this command, the "Production
conditions" or "Production status" screen.
5 APPLY Validates the settings on the "Parts no. setup" screen.
6 − 23
④ Setting the [Remain] field
When you click any "Remain" field with the right button of a track ball, the list
showing the following commands appears on the screen.
No. Command Description
1 Replenish Comp Enters the number set in the "Initial" field to the "Remain" field of the line at which
the input focus is located, then clears all warnings.
2 Clear Set a value in the “Initial” field to the “Remain” field, and clears all warnings.
3 Replenish all
feeders
Executes the [Replenish Comp] command for all components.
4 Clear all Executes the [Clear] command for all components.
6.2.2 Start of production
After setting the number of PWBs to be produced, press the <START> switch on the
operator panel to start production.
CAUTION
The head starts to move immediately after the <START> switch is
pressed, and then the machine starts PWB production.
To avoid a risk of injury, do not place your hand in the machine, nor
move your face or head close to the machine during operation.
Before pressing the <START> switch, check that there is no one who is
working in the machine.
Before pressing the <START> switch, check that there is no one who
can be injured when the head starts to move.
Before pressing the <START> switch, check that there are no
obstacles (tools and jigs) attached or left in the machine.
CAUTION
If the feeder bank is never recognized (since the machine zeroes, or the
bank moves down then up), it may be recognized automatically before
the machine moves to the pick position. Since the head moves across
the feeder while the feeder bank is being recognized, do not place your
hand in the machine, nor move your face or head close to the machine.
Especially, take care when the feeder bank is recognized not from the
menu but during teaching or tracking a pick position.
CAUTION
If only one board is clamped, production automatically starts when the
time you set at the menu item "2nd PWB TimeOut" passes. To avoid
a risk of injury, do not place your hand in the machine, nor move your
face or head close to the machine until this time passes completely.
The PWB production starts and the green signal lamp lights to indicate that PWB
production is in progress.
If home positioning has not been completed when the <START> switch is pressed,
press the <HOME> key to execute home positioning, then press the <START> switch
again.
6 − 24
(1) Display of production status
When PWB production starts with the <START> switch pressed, the status of
production is displayed on the screen.
Figure 6.2.2.1 shows the "Production status" screen to b displayed while the
machine is producing PWBs normally. Figure 6.2.2.2 shows the screen to be
displayed when the item "Shows the number of boards produced in large
characters" is selected on the "Production (Display)" tag of the Operation Options
menu.
• Display of normal production status
Figure 6.2.2.1 Production status screen (1)
• In case in which "Shows the number of boards produced in large characters" is
selected on the "Production (Display)" tag of the Operation Options menu
Figure 6.2.2.2 Production status screen (2)
