MPM UP2000印刷机中文操作手册 - 第26页
CAUTION, The machine is n ow goin g to ( 警 告 , 機器 現 在 要 移動 , 內部不能 有 move. ST A Y CL EAR. 任何東西 , 需 清除 ) Pr ess NE XT to Continue, o r EXIT to Qu it. ( 按 NEXT 繼續 , 按 EXIT 離開 ) 你按 NEXT 之後 ， 出 現 下列訊 息及視 窗： Pr ess S ELECT to …
1.3.3 選擇 Calc. Pre-Boardstops-X 進入基板 X 方向停止位置參數設定
Pre board stop position learned (機器自行計算基板停止位置)
Press SELECT to continue(按 SELECT 繼續)
Press Done when finished. (當你做完上述之步驟，按 Done)
1.4 選擇 Stencil 進入測鋼板高度參數設定
Hardware Required:
Board , Stencil , Tactile ,
Please install a stencil now. (請現在放入鋼板)
The FRAME CLAMPS will activate when (按 NEXT 後,啟動鎖住鋼板)
you press NEXT.
Press NEXT to Continue, or EXIT to Quit. (按 NEXT 繼續, 按 EXIT 離開)
你按 NEXT 之後，出現下列訊息及視窗：
The next step is to set STENCIL HEIGHT. (然後進行測鋼板高度)
Press NEXT to Continue, or EXIT to Quit. (按 NEXT 繼續, 按 EXIT 離開)
你按 NEXT 之後，出現下列訊息及視窗：
Calc. Pre-Boardstop-X
-----Warning Message-----
X AXIS – SOFTWARE LIMIT WARNING!
Press NEXT to Continue.
Stencil
Pre board stop position learned
Press SELECT to continue
Press Done when finished.
Please install a stencil now.
The FRAME CLAMPS will activate when
y
ou press NEXT.
Press NEXT to Continue, or EXIT to Quit.
The next step is to set STENCIL HEIGHT.
Press NEXT to Continue, or EXIT to Quit.
锡膏印刷机 www.smt11.cn
CAUTION, The machine is now going to(警告,機器現 在要移動,內部不能有
move. STAY CLEAR.任何東西,需清除)
Press NEXT to Continue, or EXIT to Quit. (按 NEXT 繼續, 按 EXIT 離開)
你按 NEXT 之後，出現下列訊息及視窗：
Press SELECT to JOG the sensor clear of(按 SELECT 移動偵測感應器,勿
paste or stecil apertures,碰到鋼板上錫膏及鋼板上 PAD 孔)
or Press NEXT to CONTINUE. (按 NEXT 馬上開始在本位置偵測鋼板高度)
Press SELECT or NEXT to Continue. (按 SELECT 或 NEXT 繼續)
你按 SELECT 之後，出現下列訊息及視窗：
JOG ACTIVE…(移動現在刮刀行程位置)
SQUEEGEE STROKE -112.050
Press EXIT to quit. (按 EXIT 離開)
你按 NEXT 與 EXIT 之後，出現下列訊息及視窗：
JOG ACTIVE…
SQUEEGEE STROKE -112.050
Press EXIT to quit.
CAUTION, The machine is now going to
move. STAY CLEAR.
Press NEXT to Continue, or EXIT to Quit.
Press SELECT to JOG the sensor clear of
paste or stecil apertures,
or Press NEXT to CONTINUE.
Press SELECT or NEXT to Continue.
Locating the board…
CAUTION：
：：
：Auto height sensor in
progress. Please wait…
锡膏印刷机 www.smt11.cn
(開始載入 PCB,自動偵測鋼板高度)
Stencil height FOUND. (完成偵測鋼板高度)
Press NEXT to Continue. (按 NEXT 繼續下一步驟)
1.5 選擇 Squeegee 進入測刮刀高度與刮刀行程參數設定
Hardware Required:
Squeegee Blades , Stencil , Tactile
This Utility will set the SQUEEGEE height.(使用測刮刀高度)
Press NEXT to Continue, or EXIT to quit. (按 NEXT 繼續, 按 EXIT 離開)
按 NEXT 之後，出現下列訊息視窗：
Please install a stencil now. (現在請放入鋼板)
The REAME CLAMPS will activate when(按 NEXT 之後,啟動鋼板固定夾)
you press NEXT.
Press NEXT to Continue, or EXIT to quit. (按 NEXT 繼續, 按 EXIT 離開)
按 NEXT 之後，出現下列訊息視窗：
You must now install the squeegee blade. (你現在必須安裝刮刀)
Press NEXT to Continue, or EXIT to quit. (按 NEXT 繼續, 按 EXIT 離開)
Squeegee
This Utility will set the SQUEEGEE height.
Press NEXT to Continue, or EXIT to quit.
Please install a stencil now.
The REAME CLAMPS will activate when
y
ou press NEXT.
Press NEXT to Continue, or EXIT to quit.
You must now install the squeegee blade.
Press NEXT to Continue, or EXIT to quit.
Stencil height FOUND.
Press NEXT to Continue.
