4 Setting up and commissioning User Manual SIPLACE HF Series 4.5 Setting up the placement machine Software Version SR.505.x x 05/2004 US Edition 180 4.5.8.2 HF computer unit - Connecting t he plugs Æ Conn ect the po wer …
User Manual SIPLACE HF Series 4 Setting up and commissioning
Software Version SR.505.xx 05/2004 US Edition 4.5 Setting up the placement machine
179
4
Fig. 4.5 - 11 Computer unit, back panel - Connecting the plugs
(1) Cable guide plate
4 Setting up and commissioning User Manual SIPLACE HF Series
4.5 Setting up the placement machine Software Version SR.505.xx 05/2004 US Edition
180
4.5.8.2 HF computer unit - Connecting the plugs
Æ Connect the power cable as shown in the following diagram:
4
4
Computer unit, front
panel
Plug
Connecting cable
NOTE
Plug Cable
X5pc
X5pc 03002958 + 03002559 Insert as far as the stop
X7pc
X7pc 03002967 Secure with screws
X8pc
X8pc 03002970 Secure with screws
X6pn
X6pn 03010051 Secure with screws
X6pt
X6pt 03002507 W1+W2 Secure with screws
X7pt
X7pt 03003438 W1+W2 Secure with screws
X6pu
X6pu 03002508 W1+W2 Secure with screws
X7pu
X7pu 03003435 W1+W2 Secure with screws
Computer unit, back
panel
Plug
Connecting cable
NOTE
Plug Cable
X15pz
X15pz 03003434 Fix with screws
X3pz
X3pz 03004063 Fix with screws
PE1
Cable ring Grounding cable
Fix as shown in Fig. 4.5 - 8
,
page 176
X27pz
X27pz 03003437 W1-W2 Insert as far as the stop
X2pz
X2pz 03002966 W1-W5 Fix with screws
X1pz
X1pz 03002969 W1-W5 Fix with screws
X62pz
X62pz 03002488 Snap into place
PE2
Cable lug Grounding cable Insert as far as the stop
X1 Fan in extension kit Insert as far as the stop
User Manual SIPLACE HF Series 4 Setting up and commissioning
Software Version SR.505.xx 05/2004 US Edition 4.5 Setting up the placement machine
181
4.5.8.3 HF/3 computer unit - Connecting the plugs
Æ Connect the power cable as shown in the following diagram:
4
4
Computer unit,
front panel
Plug
Connecting cable
NOTE
Plug Cable
X5pc
X5pc 03002958 + 03002559 Insert as far as the stop
X7pc
X7pc 03002967 Secure with screws
X8pc
X8pc 03002970 Secure with screws
X6pn
X6pn 03010051 Secure with screws
X6po
X6po 03010055 Secure with screws
X6pt
X6pt 03010607 W1+W2 Secure with screws
X7pt
X7pt 03010608 W1+W2 Secure with screws
X7pu
X7pu 03002508 W1+W2 Secure with screws
Computer unit,
back panel
Plug
Connecting cable
NOTE
Plug Cable
X15pz
X15pz 03003434 Fix with screws
X3pz
X3pz 03004063 Fix with screws
PE1
Cable ring Grounding cable
Fix as shown in Fig. 4.5 - 8
,
page 176
X27pz
X27pz 03003437 W1-W2 Insert as far as the stop
X2pz
X2pz 03002966 W1-W5 Fix with screws
X1pz
X1pz 03002969 W1-W5 Fix with screws
X62pz
X62pz 03002488 Snap into place
PE2
Cable lug Grounding cable Insert as far as the stop
X1 Fan in extension kit Insert as far as the stop
