7.4.6 Synchronous transport mode
7.4.6.1 Description
In synchronous mode, two PCBs of the same size are moved into the placement position at the
same time. They must be processed as a common panel.
In this way, the top and bottom of a PCB can be processed on a single line, and the time required
to transport the PCB is shorter since two PCBs are always transported at the same time. It also
ensures better utilization of the nozzle configuration.
7.4.6.2 Function
PCBs on conveyor tracks 1 and 2 are moved synchronously onto the conveyor sections (i.e. the
conveyors are controlled synchronously, but independently of one another). The components to
be placed on conveyor tracks 1 and 2 must be organized into a panel via two subpanels. (See the
SIPLACE Pro user manual).
If only one conveyor track (or center conveyor) is full when the placement sequence starts, the
subpanel on this section will be identified as “not for placement”.
7.4.6.3 Restrictions
If the dual conveyor is operated in synchronous mode, the ‘PCB whispering down the line’ option
is deactivated. PCB barcode operation is not supported in this mode. The ‘Global ink spot’ option
cannot be used.
7.4.7 Controlling the dual conveyor using the Single Functions menu
The online help contains information on controlling the dual conveyor and on the Single Functions
menu.
7.4.8 Automatic width adjustment on the dual conveyor
When the command is received, the conveyors are set to the desired width one after another. Dif-
ferent widths are possible.
PLEASE NOTE 7
Automatic width adjustment is deactivated if “synchronous transport” is selected.
User Manual SIPLACE HF Series 7 Station extensions
Software Version SR.505.xx 05/2004 US Edition 7.4 Dual conveyor
307
7.4.9 Technical data – dual conveyor
7
7
7
Fixed conveyor side Right or left
PCB format
Standard (length x width)
Option "Long board"
Dual conveyor in "single conveyor" mode
Standard
Option "Long board"
50 x 50 mm² to 450 x 250 mm²
50 x 80 mm² to 610 x 250 mm²
50 x 50 mm² to 450 x 450 mm²
50 x 80 mm² to 610 x 450 mm²
PCB thickness
Standard 0.3 mm to 4.5 mm ± 0.2 mm
(thicker PCBs available upon request)
Max. PCB warpage Up: 6 mm - PCB thickness
Down: 0.3 mm + PCB thickness
PCB weight Max. 3 kg
Clearance on PCB underside
Standard
Option
25 mm ± 0.2 mm
Max. 40 mm ± 0.2 mm
PCB transport height 830mm ± 15mm (standard)
900mm ± 15mm (optional)
930mm ± 15mm (optional)
950mm ± 15mm (SMEMA: optional)
Type of interface SMEMA / SIEMENS
Component-free PCB handling edge 3 mm
PCB changeover time < 2.5 s
PCB positioning accuracy ± 0.5 mm
Conveyor mode Synchronous or asynchronous
Components on each conveyor Same or different
PCB width on each conveyor Same or different
Ink spot recognition Synchronous: not possible, asynchronous:
possible
Automatic width adjustment Synchronous: not possible, asynchronous:
possible
7 Station extensions User Manual SIPLACE HF Series
7.5 PCB barcode reader Software Version SR.505.xx 05/2004 US Edition
308
7.5 PCB barcode reader
7.5.1 Overview
The PCB barcode reader is used to automatically record and decode barcodes on PCBs. The
PCB barcode reader sends the read data via its serial interface to the transport controller and then
for further processing to the machine controller via the CAN bus.
Fig. 7.5 - 1 PCB barcode block diagram
7
The PCB barcode readers are installed on the input side of the placement machine on the PCB
conveyor. Up to four devices can be retrofitted to each machine. The barcode readers are fitted
so that the barcode labels on the topside and underside of the PCBs can be scanned on both
tracks of the dual conveyor.
There are two variants of the barcode reader:
– 1D barcode reader
This barcode reader processes barcodes. 7
– 2D barcode reader
This barcode reader processes matrix code. Matrix code is primarily used when there is
not enough space for barcode labels. The 2D barcode reader also reads conventional bar-
codes. 7
Device number
1
Bar-
code
reader
Distribution
board
Transport
controller,
right
Barcode
reader
bottom
2
3
Bar-
code
reader
Distribution
board
Transport
controller,
left
Barcode
reader
bottom
4
Machine
controller
Station
computer
SIPLACE Pro
computer
LAN
CAN
bus
V-24V-24
