User Manual SIPLAC E HF Series 2 Operational safety Software Vers ion SR.505.xx 05/2004 US Edition 2.2 Warning labels 33 2.2.2 W arning label W202 on the gantries Fig. 2.2 - 3 Warning label W202 on t he gantries Pos. W2 …
2 Operational safety User Manual SIPLACE HF Series
2.2 Warning labels Software Version SR.505.xx 05/2004 US Edition
32
2.2.1.1 Warning label W201
2
Pos. W201 in Fig. 2.2 - 1, item no. 03009338-01 (number per placement system: 1)
2.2.1.2 Warning label W203
2
Pos. W203 in Fig. 2.2 - 1, item no. 03009342-01 (number per placement system: 4)
2.2.1.3 Warning label W204
2
Pos. W204 in Fig. 2.2 - 1, item no. 03009343-01 (number per placement system: 8)
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
SAFE OPERATION OF THE MACHINE
Safe operation of the machine depends absolutely on
the operator being familiar with the user manual and
safety instructions and putting them into effect.
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
User Manual SIPLACE HF Series 2 Operational safety
Software Version SR.505.xx 05/2004 US Edition 2.2 Warning labels
33
2.2.2 Warning label W202 on the gantries
Fig. 2.2 - 3 Warning label W202 on the gantries
Pos. W202 item no. 03009341-01
2 Operational safety User Manual SIPLACE HF Series
2.2 Warning labels Software Version SR.505.xx 05/2004 US Edition
34
2
Pos. W202 in Fig. 2.2 - 3, item no. 03009341-01 (number per HF placement system: 6, HF/3
placement system: 7)
WARNING 2
Powerful permanent magnetic fields inside the machine
DANGER 2
Risk of death for persons with active implants (e.g. pacemakers, insulin pumps, defibrillators).
2
WARNING
Danger of crushing for persons with passive metal implants (e.g. plates, screws).
Do not reach into the machine or bend towards it when the protective covers are open.
Do not bring any metal objects into the area.
