8
6. Operation Box Section (Option)
6-1. Operation Box (Option)
3
4
5
6
7
1
2
8
3
4
5
6
7
1
2
8
No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1
LE1-M5602-00 UY CASE ADD
1 / ○
2
LE1-M5603-00 LABEL
1 / ○
3
LE1-M66JT-10 HNS.OK.SW.ASSY CE
1 / ×
4
LE1-M66JU-10 HNS.NG.SW.ASSY CE
1 / ×
5
LE1-M66JV-10 HNS.EXE.SW.ASSY CE
1 / ×
6
LE1-M66JW-10 HNS.STP.SW.ASSY CE
1 / ×
7
LE1-M66NE-00 HNS.X312-X313
1 / ×
8
LE1-M66NA-01 HNS.X201-X312
1
1.5m
/ ×
9
7. PCB Holder Section
7-1. PCB Holder
2
2
3
3
13
1
12
3
3
4
5
14
6
7
14
6
16
8
11
10
15
9
2
2
2
3
3
13
1
12
3
3
4
5
14
6
7
14
6
16
8
11
10
15
9
No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1
LE1-M9019-01 STOPPER,PCB
1 / ○
2
90990-47J002 KNOB
2 / ○
3
90990-33J033 BOLT STOPPER
2 / ×
4
90990-33J034 BOLT STOPPER
2 / ×
5
LE1-M9018-01 BRACKET
1 / ×
6
LE1-M900C-00 COVER
2 / ×
7
KHW-M8806-20 LIGHT ADJUSTER S
1 / ×
8
LE1-M9011-01 PLATE,FRONT
1 / ×
9
LE1-M9016-01 CLAMPER
1 / ×
10
LE1-M9007-00 PIN,GUIDE
5 / ○
11
LE1-M90A4-10 SPRING
6 / ○
12
LE1-M66MP-00 PCB SEN ASSY 1
1
BASE SEC.
B ×
13
91317-03005 BOLT HEX.SOCKET HEAD
2
M3X5
14
91317-03006 BOLT HEX.SOCKET HEAD
2
M3X6
15
91317-04055 BOLT HEX.SOCKET HEAD
2
M4X55
16
91317-06014 BOLT HEX.SOCKET HEAD
3
M6X14
10
8. Wagon Section (Option)
8-1. Wagon (Option)
8
13
7
9
12
10
4
12
4
10
12
10
4
15
1
3
6
12
4
5
11
2
14
8
13
7
9
12
10
4
12
4
10
12
10
4
15
1
3
6
6
6
6
6
6
6
6
6
6
6
6
6
6
12
4
5
11
2
14
No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1
LE1-M5A18-01 STAY TABLE
1 / ×
2
LE1-M5A19-00 COVER TABLE
1 / ○
3
LE1-M5A1A-00 BOARD TABLE
1 / ○
4
LE1-M5A1E-00 PLATE SHAFT
4 / ×
5
LE1-M5A1G-00 SPACER
1 / ×
6
90990-47J009 PULL
1 / ○
7
90990-58J001 CASTER
4 / ○
8
90990-57J001 FOOT,ADJUSTER
4 / ○
9
99732-20700 NUT,HEXAGON
4 / ○
10
LE1-M5A1D-01 COVER SHAFT
3 / ○
11
91317-04010 BOLT HEX.SOCKET HEAD
2
M4X10
12
91317-08018 BOLT HEX.SOCKET HEAD
1
M8X18
13
91317-06016 BOLT HEX.SOCKET HEAD
16
M6X16
14
98907-04008 SCREW BINDING HEAD
4
15
98707-03010 SCREW FLAT HEAD
4
