Page +$1:+$ 200 SM471 PLUS Electric Circuit Diagram (1/7) 240 (SM33_PW005) (SM48C_PW004) 2.5 mm (BLK) 2.5 mm (BLK) -MAIN S/W L32 L33 L31 -NF1 (3Ø, 20A) L22 L21 L23 SH202-C16 -CP1 2.5 mm (BLK) F ACTOR Y MAIN POWER 4.0 mm …
Page
+$1:+$
199
SM471
PLUS
Safety Control Board Interface (4/4)
NO. Lev. PART NO. PART NAME Q'TY Old No. Reference
1 AM03-020657A CABLE ASSY-BD_PW_SC_J1R_CONV_SUB_IF-EXT 1 AM03-005527A SM471-SC105-1
2 AM03-020641A CABLE ASSY-AIR_INDICATOR_J6R 1 AM03-005526A SM471-SC105
3 AM03-020654A CABLE ASSY-F_OP_PANEL_IF_SACO_F_TBOX 1 AM03-006880A SM48-CV034
4 AM03-020654A CABLE ASSY-F_OP_PANEL_IF_SACO_F_TBOX 1 AM03-006965A SM33-CV023-4
5 AM03-010654B CABLE ASSY-FRONT-TEACHING_BOX_EXT 1 SM471-CV134-1
Page
+$1:+$
200
SM471
PLUS
Electric Circuit Diagram (1/7)
240
(SM33_PW005)
(SM48C_PW004)
2.5 mm (BLK)
2.5 mm (BLK)
-MAIN S/W
L32
L33
L31
-NF1
(3Ø, 20A)
L22
L21
L23
SH202-C16
-CP1
2.5 mm (BLK)
FACTORY MAIN POWER
4.0 mm (BLK)
- 200/208/220/240/380/415VAC FLA20A
-MCCB1
(3Ø, 20A)
L13
L12
L11
-MAIN CON.
TRS
- 3PHASE~50/60Hz SCR 50kA (220VAC)
T
SR
-EARTH PLATE
FRAME GROUND
PE
-TRANS
220V
208200 220
L31
PE
to TB1-1A,TB1-6A
1L1
1L2
22S
22R
(SM471_PW008)
22T
-CP3
TF2L1
TF2L2
TF2L3
220V 220V
0V 220V
200220415380 200 208 380240 415
L32
415208 220 380240
L33
2.5 mm (BLK)
FX,RX,FY1,FY2,RY1,RY2,FS,RS AXIS(SERVO)
to MC1
6.SECONDARY #1 : 1Ø 220(2.5KVA)
SECONDARY #2 : 3Ø 220(3KVA)
2.FREQUENCY : 50/60Hz
1.CAPACITY : 5.5KVA
3.PHASE : 3Ø
4. CONNECTION: Y-Y
<TRANS SPECIFICATION>
5.PRIMARY : 3Ø 200/208/220/240/380/415V, 5KVA
(16A)
DC POWER #5,#6(24VDC)
(FZ1~FZ10, RZ1~RZ10 AXIS)
to TB1-13A,TB1-15A
22R 22T
CONTROL RACK
MONITOR1,2
DC POWER #1~#4(24VDC)
AC FAN
TF1L1
4.0 mm (Y/G)
TF1L2
2.5 mm (BLK)
(SM33_PW006)
CP2-2
CP2-4
2.5 mm (BLK)
2.5 mm (BLK)
2.5 mm (BLK)
(SM471_PW007)
-CP2
(SM48C_PW003-2)
SH202-C16
(16A)
SH203-C16
(16A)
KG20B-T203
(3Ø, 25A)
GV2ME22
TNS-5020
12.5A(Max 30A)
5A(Max 11A)
1.6A(Max 12A)
8A(Max 20A)
(SM33_PW001)
-SK1
RAV-801BXZ-4
(SM471_PW100-01)
(REFER TO PAGE #3)
246
135
1
456
23
2
1
264
321
135
4
4
3
24
13
6
5
2
1
4
3
2
2
PE01
2
2
PE02
2
2
2
2
2
2
SK-FG
1
2
3
4
5
7
8
6
Page
+$1:+$
201
SM471
PLUS
Electric Circuit Diagram (1/7)
NO. PART NO. PART NAME Q'TY Old No. Reference
1 J90831063A MAIN_POWER_CABLE_ASSY SM33-PW001 1 SM33-PW001
2 AM03-020540A CABLE ASSY-SURGE KILLER 1 SM471_PW100-01
3 AM03-018606A CABLE ASSY-MCCB NF_EARTH 1 SM48C_PW003-2
4 AM03-018605A CABLE ASSY-NF_MAIN_SWITCH 1 SM48C_PW004
5 AM03-013512D CABLE ASSY-MAIN SWITCH_TRANS 1 SM33-PW005
6 AM03-001211C CABLE ASSY-TRANS_CP1,2,3 CABLE ASSY 1 SM33_PW006
7 AM03-005482A CABLE ASSY-CP1_TB1_MC1 1 SM471_PW007
8 AM03-005483A CABLE ASSY-CP2_TB1_MC2_CABLE 1 SM471_PW008
