MIRTEC_MV-6_OMNI_3D_AOI_Series_Data_Sheet-REV13
Exc lu si ve 1 5MP / 25 MP Co aXP res s Ca me ra Sys te m OM NI -V ISI ON ® 3D Di gi ta l Tri - Fr equ ency M oir é Te ch nol ogy Le ad in g-E dge 12 Pr oj ect io n Bl ue DL P T ec hn o lo gy Pr e c i s io n Co m po u nd…
Exclusive 15MP/25MP CoaXPress Camera System
OMNI-VISION
®
3D Digital Tri-Frequency Moiré Technology
Leading-Edge 12 Projection Blue DLP Technology
Precision Compound Telecentric Camera Lens
Eight Phase Color Lighting System
10MP/18MP SIDE-VIEWER
®
Camera System
Programmable Z-Axis Multi-Focus System
INTELLI-PRO
®
Automatic Programming Software
Multi-Functional AOI-SPI Fusion Technology
INTELLISYS
®
Industry 4.0 Intelligent Factory Automation System
www.mirtecusa.com
PREMIER INSPECTION
3D Gull-Wing Co-Planarity Inspection
3D Solder Fillet Inspection
Standard Features:
Options:
System Specifications:
Option 1 Pixel Resolution: 15 um 58.56 mm x 58.56 mm (2.31” x 2.31”)
Option 2 Pixel Resolution: 10 um 39.04 mm x 39.04 mm (1.54” x 1.54”)
Option 1 Pixel Resolution: 7.7 um 39.42 mm x 39.42 mm (1.55” x 1.55”)
950 Kg (2,094 lbs.)
1,030 Kg (2,270.76 lbs)
870 Kg (1,918.02 lbs)
MV-6 OMNI XL / DL / HV
(Extended Conveyor not available w/ DL)
1,600 mm L × 1,580 mm W × 1,660 mm H (63" x 62.2" x 65.35")
Standard Conveyor: 1,700 mm (66.93") / Extended - 2,400 mm (94.49")
1,700 Kg (3,747.86 lbs)
MV-6 OMNI: Three (3) Stage High-Speed Conveyor / MV-6 OMNI XL / HV: Conveyor Rail Extension (See Specifications).
MV-6 OMNI XL / MV-6 OMNI XL HV
50 mm x 50 mm to 870 mm x 690 mm (2.0" x 2.0" to 34.25" x 27.17")
1,200 mm x 690 mm (47.24" x 27.7") w/ PCB Indexing
1,600 mm x 690 mm (63" x 27.7") w/ PCB Indexing and Optional Conveyor Extension
MV-6 OMNI
50 mm x 50 mm to 510 mm x 460 mm (2.0" x 2.0" to 20.1" x 18.1")
Three (3) Stage Conveyor Option w/ PCB Indexing: 1,020 mm x 460 mm (40.2" x 18.1")
MV-6 OMNI XL DL
Single Lane: 50 mm x 50 mm to 870 mm x 555 mm (2.0" x 2.0" to 34.25" x 22.85")
Dual Lane: 50 mm x 50 mm to 870 mm x 300 mm (2.0" x 2.0" to 34.25" x 11.81")
MV-6 OMNI 3D AOI Series Specifications
Machine Dimensions and Weight
MV-6 OMNI
Vision System (FOV Size)
Air Requirements
Quantity Four (4) - 10MP Color Side-Angle Cameras
PCB Thickness Range
5 Kgf / cm² (0.5 Mpa); (71 PSI)
Digital Tri-Frequency Moiré Technology - 12 Projection Blue DLP
Intel
®
Multi-Core PC, 32” Flat Screen LCD Monitor, Windows 10
TM
OS, HDD, Mouse & Keyboard, Network LAN Card.
MV-6DL OMNI
900 mm L x 1,290 mm W x 1,660 mm H ( 35.43" x 50.79" x 65.35")
Quantity Four (4) - 18MP CoaXPress Color Side-Angle Cameras
SIDE-VIEWER® Camera System
OMNI-VISION® Inspection Technology
3D Inspection Technology
2D Inspection Technology
15MP / 25MP CoaXPress Camera System
Additional Specifications
Lens Configuration
MV-6em OMNI
MV-6 OMNI (Extended PCB Size)
50 mm x 50 mm to 510 mm x 510 mm (2.0" x 2.0" to 20.1" x 20.1")
MV-6em OMNI (Small-Footprint)
50 mm x 50 mm to 330 mm x 280 mm (2.0" x 2.0" to 12.99 " x 11.02")
Lighting System
Eight (8) Phase Color Lighting
1,080 mm W x 1,470 mm D x 1,500 mm H (42.5" x 57.87" x 59.1")
1,080 mm L x 1,610 mm W x 1,610 mm H (42.5" x 63.39" x 63.39")
±2 mm
OMNI-VISION
®
- Digital Tri-Frequency Moiré Technology - 12 Projection Blue DLP - 25mm 3D Inspection Capability.
Single Stage High-Speed Conveyor System with Programmable Width Control and Automatic PCB Support.
Advanced Eight (8) Phase Color LED Lighting System.
Pre and Post Reflow Inspection Capability.
MV-6DL OMNI (Dual Lane)
Single Lane: 50 mm x 50 mm to 460 mm x 590 mm (2.0" x 2.0" to 20.1" x 23.23")
Dual Lane: 50 mm x 50 mm to 460 mm x 300 mm (2.0" x 2.0" to 20.1" x 11.81")
Automatic Teach Tool (ATT) Software - Automatic Programming Using Centroid Data.
Comprehensive Package Type Library - Provides Simple "Drag and Drop" Component Programming.
Local System Software: Repair Plus Software, Statistical Process Control (SPC) Software.
15 Mega Pixel or 25 Mega Pixel CoaXPress Top-Down Color Camera System (See Specifications).
15MP CoaXPress: (3,904 x 3,904 @ 120 fps)
25MP CoaXPress: (5,120 x 5,120 @ 72 fps)
SIDE-VIEWER
®
Camera System - Quantity (4) 10MP or 18MP CXP Side-Angle Digital Color Cameras. (See Specifications).
Programmable Z-Axis Multi-Focus System - Provides Optimal Focus Level for Taller Devices.
ePM-AOI CAD Import Software. ODB++ Import Module Sold Separately (Requires ePM AOI).
AOI-SPI Fusion Technology - Provides Both AOI and SPI Capability in a Single Platform.
2D Bar Code Reader Options: Gun Type, Camera Type and External Mount.
MV-6DL OMNI Shuttle Conveyor Options: Input Shuttle Conveyor, Output Shuttle Conveyor.
Remote PC - Software Purchased Separately.
Power Requirements
Single Phase 200~240V 50~60Hz; 1.1 KW, Breaker Capacity: 25 Amp
PCB Surface Clearance
Top-Side Clearance: 45 mm / Bottom-Side Clearance: 50 mm
PCB Edge Clearance
Top-Edge Clearance: 3 mm / Bottom-Edge Clearance: 3.5 mm
0402 Chip (mm) / 01005 Chip (in) / 0.3 Pitch (mm)
Precision Telecentric Compound Lens Design
Maximum PCB Warpage
Standard: 0.5 mm - 3 mm / Optional: 0.5 mm - 5 mm
Maximum PCB Weight
Remote Software: Repair System Software, Statistical Process Control (SPC) Software, Off-Line Teaching Software (OLTT).
Total Remote Management Software (TRMS) - Requires Server Software for Remote PC and Client Software on All Machines.
INTELLI-TRACK
®
Process Control Software - Requires Server Software for Remote PC and Client Software on All Machines.
SVN Multi-System Version Control Software - Requires Separate PC Server.
PCB Inspection Area
MV-6 OMNI: 4 Kg (8.82 lbs) / MV-6 OMNI XL: 7 Kg (15.43 lbs) / MV-6 OMNI XL HV: 25 Kg (55.12 lbs)
Maximum 3D Inspection Height
25 mm @ ±3 um
2D Inspection Item
Missing Component, Wrong Component, Mis-Alignment, Skewed Component, Polarity,
Tombstone, Solder Bridge, Flipped Device, Solder Ball, Etc.
Robot Positioning System
Precision Closed Loop AC Servo Drive, Resolution: 1 um / Repeatability: ±10 um
Component Height, Position, Lifted Package, Lifted Lead, Solder Fillet, Excessive Solder,
Insufficient Solder, Solder Bridge, Open Solder, Etc.
3D Inspection Item
Minimum Component Inspection
(Subject to change without prior notice)
