555
Transport :\tunexpected board in
run-out
An unexpected board was
detected at the second sensor in
the run-out.
- Unexpected board at second sensor in the run-out
- Defective sensor (either first or second run-out sensor).
- Malfunction in sensor communication.
- Remove unexpected board from the run-out.
- Check first and second sensor of the run-out.
- Retry the operation and continue, if not correct contact your service
representative.
556
Transport :\tMissing board in run-
in
The previous machine signaled
the arrival of a board. However,
the board was not detected within
the time frame
on the first sensor in the run-in
section.
- The board is stuck between the previous machine and the run-
in.
- Defective sensor (first run-in sensor).
- The first sensor is not correctly adjusted.
- Defective wiring I/O.
- Remove the stuck board.
- Adjust the transport width to match the board dimensions.
- Adjust the preceding machine so that it is correctly in line.
- Retry the action.
557
Transport :\tMissing board in run-
in
A board was detected at the first
sensor in the run-in. However, the
board was not detected within the
time frame
on the second sensor in the run-in
section.
- The board is stuck between the first and second sensor of the
run-in.
- Defective sensor (second run-in sensor).
- The second sensor is not correctly adjusted.
- Defective wiring I/O.
- Check width of the transport system, if necessary adjust the width.
- Retry the operation and continue.
- Check the second sensor in the run-in.
- Check wiring I/O.
- Check if sensor sesitivity is set to maximum.
558
Transport :\tMissing board in work-
area
A request was made to transport a
board from the run-in to work-
area. The transport was started,
however, the board was not
detected within the time frame on
the first sensor in the work-area
section.
- The board is stuck between the run-in and the first sensor of
the work-area.
- Defective sensor (first sensor of the work-area).
- The first sensor is not correctly adjusted.
- Defective wiring I/O.
- Check the width of the transport system, if necessary adjust the width.
- Retry the operation and continue.
- Check the first sensor in the work-area.
- Check wiring I/O.
- Check sensor adjustment.
559
Transport :\tMissing board in work-
area
A board was detected at the first
sensor in the work-area. However,
the board was not detected within
the time frame
on the second sensor in the work-
area section. Or the transport was
not able to transport the board out
of the work-area.
- The board is stuck between the first and second sensor of the
work-area.
- Defective sensor (second sensor in the work-area).
- The second sensor is not correctly adjusted.
- Defective wiring I/O.
- Check the width of the transport system, if necessary adjust the width.
- Retry the operation and continue.
- Check the second sensor in the work-area.
- Check wiring I/O.
- Check sensor adjustment.
560
Transport :\tMissing board in work-
area
A board was detected at the
second sensor in the work-area.
However, the board was not
detected within the time frame
on the third sensor in the work-
area section. Or the transport was
not able to transport the board out
of the work-area.
- The board is stuck between the second and third sensor of
the work-area.
- Defective sensor (third sensor in work-area).
- The third sensor is not correctly adjusted.
- Defective wiring I/O.
- Check the width of the transport system, if necessary adjust the width.
- Retry the operation and continue.
- Check the third sensor in the work-area.
- Check wiring I/O.
- Check sensor adjustment.
561
Transport :\ttime-out occurred on
board move
This message is obsolete and
should not occur. - Report error to your service representative.
562
Transport :\tMissing board in run-
out.
A request was made to move a
board out the work-area. The
movement was started but the
board was not detected within the
time frame on the first sensor in
the run-out section.
- Board stuck between work-area and run-out.
- Defective sensor (first sensor in run-out).
- The first sensor in the run-out is not correctly adjusted.
- Defective wiring I/O.
- First sensor in run-out not correctly adjusted.
- Check the width of the transport system ,if necessary adjust the width.
- Retry the operation and continue.
- Check the first sensor in the run-out.
- Check wiring I/O.
- Check sensor adjustment.
563
Transport :\tMissing board at run-
out stop sensor.
A board was detected at the first
sensor in the run-out. However,
the board was not detected within
the time frame
on the second sensor in the run-
out section.
- Board stuck between first and second sensor of run-out.
- Defective sensor (second sensor in run-out).
- The second sensor in the run-out is not correctly adjusted.
- Defective wiring I/O.
- Second sensor in run-out not correctly adjusted.
- Check the width of the transport system ,if necessary adjust the width.
- Retry the operation and continue.
- Check the second sensor in the run-out.
- Check wiring I/O.
- Check sensor adjustment.
564
Transport :\tPrevious board did not
leave work-area
The transport was not able to
position a board in the work-area
because the previous board did
not leave the work-area in time.
- Board stuck between work-area and run-out.
- Sensor malfunction.
- Board is larger as specified in action spec.
- Remove the board for work-area.
- Adjust action spec.
565
Transport :\tUnable to position
board in work-area
The transport is not able to
position a board on the second
sensor in the work-area.
- Transport speed is too large.
- Acceleration is too low.
- reduce board transfer speed.
- enlarge the belt acceleration.
566
Transport :\tIllegal state to execute
command (%1)
Command refused because the
transport controller firmware is in a
wrong state. Software error.
- Retry and continue.
- Restart the system.
- Report error to your service representative.
567
Transport : Transport width out of
range (command: %1)
The requested function cannot be
executed because one or more
parameters (e.g. transport width)
are invalid.
- Coplanarity checker, Flux unit or Wafer handler has been
configured;
maximum transport width when Coplanarity checker
configured: 406mm.
maximum transport width when Flux unit configured: 350
mm.
maximum transport width when W
- Check transport width and modify when necessary.
- Retry and continue.
- Restart the system.
568
Transport :\tCommand (%1) is
refushed
A message is refushed by the
transport controller.
- A command was given to the transport while the same
command was already executing. This might appear when a
transport jogging is in progress.
- Software error.
- Retry the operation.
- Report error to your service representative.
569
Transport :\tTime-out occurred
while executing command (%1)
A transport command is not
finished within a fixed time frame.
- Transport speed is too low.
- Hardware failure.
- Software error.
- Retry the operation.
- Report error to your service representative.
570 Unable to start the transport
The system was not able to start
the transport.
- No servo power present.
- Transport hardware failure. - Switch on servo power.
571
Transport :\trecovery failed, please
check transport
This message is obsolete and
should not occur. - Report error to your service representative.
572 Transport :\tGeneral failure.
An unknown error occurred on the
transport. Retry the error.
573
Transport :\tUnable to retrieve
errors.
The control software was not able
to retrieve the errors on the
transport controller.
- Communication error.
- This is an internal software error. - Check the communication link with the transport controller.
574 Transport :\tCommunication error
A communication error to the
transport controller occurred. - Internal communication failed. - Check the communication link with the transport controller.
575 Transport :\tError clamping board
An occurred while clamping the
board in the work-area.
- Servo power lost during the movement of the lift.
(Cover opened, emergency button pushed)
- Check the board in the work-area.
- Close cover or release emergency button.
- Retry operation and continue, if not correct contact your service
representative.
576
Unexpected board detected in
work area
A board was detected in the work-
area to which no order was
allocated. - A board was put in the work-area. - Remove the board and continue.
577
Possible mismatch between
physical and reported board
locations
Dialog items/functions are
enabled/disabled based on the
presence/absence of boards in the
machine.
- Since the machine has not been started at this moment, there
might be a mismatch between the actual board status and the
reported one. - Start the transport.
578
Transport :\tExternal amplifier
error
The external amplifier DCPA
reports an error.
- The external amplifier DCPA is not correctly connected.
- The emergency circuit has been activated during a movement
of the transport system.
- Check the wiring of the external amplifier as it is mentioned in the Service
Manual.
- Check emergency circuit ( cover, emergency button).
- Retry action if not correct, contact your service representative.
579
Transport :\tboard position in run-
in unknown
The state of the run-in section of
the transport, and therefore the
board position in the run-in is
unknown.
- An attempt to start the transport in order to enable error
recovery was made. However, due to the fact that the board
position in the run-in is unknown, the transport could not be
started. - Retry the transport error.
580
Transport :\tboard position in work-
area unknown
The state of the work-area section
of the transport, and therefore the
board position in the work-area is
unknown. Each time a board is
unclamped, the board position
becomes unknown.
- An attempt to start the transport in order to enable error
recovery was made. However, due to the fact that the board
position in the work-area is unknown, the transport could not be
started. - Retry the transport error.
581
Transport :\tboard position in run-
out unknown
The state of the run-out section of
the transport, and therefore the
board position in the run-out is
unknown.
- An attempt to start the transport in order to enable error
recovery was made. However, due to the fact that the board
positions in the run-out is unknown, the transport could not be
started. - Retry the transport error.
582
Cannot transport verification board
out of work-area
It is not possible to transport the
verification board out of the work-
area. - Remove board manually from work-area.
