1512
Limms-X
1513
Limms-YR
1514
Limms-YL
1515
Limms supplies
1516
H-Drive
1517
SBIP
1518
CA (Front)
1519
CA (Rear)
1520
FA (Front)
1521
FA (Rear)
1522
CA (Front-Left)
1523
CA (Front-Right)
1524
CA (Rear-Right)
1525
CA (Rear-Left)
1526
Dump 1
1527
Dump 2
1528
Dump 3
1529
Dump 4
1532
Cover (Front)
1533
Cover (Rear)
1534
Cover
1535
Therm. switch
1536
E-Stop (Front)
1537
NOT USED
1538
E-Stop (Rear)
1539
Feeder Section 1
1540
Feeder Section 2
1541
Feeder Section 4
1542
Feeder Section 3
1543
%?
1544
outer
1545
inner
1546
Initializing communication....
1547
Uploading vision files....
1548
Initializing....
1549
%1:Automatic retry on pick error
Only used in MIS reports.
1550
%1:Automatic retry on CA error
(including dump and repick) Only used in MIS reports.
1551
%1 :\tAutomatic retry FA (Spare
measured) Only used in MIS reports.
1552
Flux applicator (Front-Left)
1553
Flux applicator (Front-Right)
1554
Flux applicator (Rear-Right)
1555
Flux applicator (Rear-Left)
1556
RVS
1558
TEU (Rear)
1560
TEU (Front)
1561
Feeder Section 5
1562
Feeder Section 5
1600 SVS :\tUndefined error The SVS error is not defined yet. Unknown.
- Retry and continue.
- Report error to your service representative.
1601 SVS :\tUndefined warning
The SVS warning is not defined
yet. Unknown.
- Retry and continue.
- Report warning to your service representative.
1602
SVS :\tSetup not OK for feeder
%1.%2
SVS detected a mismatch
between current feeder setup and
setup requested by action spec.
A new order with different action spec and feeder setup is
started. Check with SVS system.
1603
SVS :\tCommunication error to
CIMCIS system with feeder
section %1 A system error occurred. Unknown.
- Retry and continue.
- Restart the system.
- Report error to your service representative.
1604
SVS :\tCommunication error with
feeder %1.%2, A system error occurred. Unknown. Check with SVS system.
1650
SVS :\tFeeder %1.%2 (channel
%3) low
The specified feeder is almost
empty. The feeder has not been refilled recently. Refill feeder with components.
2001 %1 :\tPower dip detected
Power dip detected in the servo
power supply circuitry.
- The system power dropped, for a small time period, below a
defined level. - Check system power supply.
2002 %1 :\tZero coarse Z not found
The zero coarse of the Z servo is
not found in a homing action.
- Defective EPD-wiring.
- Defective EPD.
- Defective fuse (F1..4) on main connector board.
- Defective wiring between motor and motor control.
- Defective motor
- Defective motor control
- Check the EPD and EPD-wiring.
- Check the fuse on main connector board.
- Check wiring between motor and motor control.
- Check motor.
- Retry actions, if not correct, then contact your service representative.
2003 %1 :\tZero fine Z not found
The zero fine (encoder marker
pulse) of the Z servo is not found
in a homing action.
- Defective wirling.
- Defective encoder.
- Defective electronics.
- Check wirling.
- Check encoder.
- Check electronics (controller board).
- Retry operation, if not correct then contact your service representative.
2005 %1 :\tAmplifier Z disabled
The amplifier of the Z servo is
disabled. - Software error in aPC. - Retry action, if not correct contact your service representative.
2006 %1 :\tZ not homed The Z servo is not homed. - Software error in aPC. - Retry action, if not correct contact your service representative.
2007 %1 :\tZero drift Z
The Z servo has received too
many or too less encoder pulses
which is interpreted as a shift in
the zero fine position.
- Defective wiring.
- Defective encoder.
- Defective electronics.
- Check wiring.
- Check encoder.
- Check electronics (controller board).
- Retry operation, if not correct then contact your service representative.
2008 %1 :\tPosition error Z
Position deviation in Z larger than
defined in error window.
- Movement outside mechanical range.
- Mechanical friction too high.
- Defective fuse (F1..4) on main connector board.
- Defective wiring.
- Defective motor.
- Defective motor controller.
- Check mechanical friction according to the procedure described in the Service
Manual.
- Check fuse on main connector board.
- Check cables, motor and motor controller.
2009 %1 :\tCommunication time out Z
No response of Z servo controller
within the defined time interval.
- Defective servo controller (LM628) on the placement head
controller. - Replace placement head controller board.
2010 %1 :\tCommunication error Z
Communication error occurred
inside the head controller.
- Wrong parameters sent to head controller. This error should
not occur.
- Retry action.
- Report error to your service representative.
2011 %1 :\tTime-out Z
Homing of Z servo: Controller not
ready within the defined time
interval. - Speed defined in movement class for homing is too low.
- Check the electronics.
- Retry the operation, if not correct then contact your service representative.
2012 %1 :\tZ force sensor damaged
Z force sensor is not working
correctly.
- Defective wiring
- Defective Hall sensor in force control unit.
- Defective electronics.
- Check wiring.
- Check Hall sensor.
- Check electronics.
2013 %1 :\tNo Z force table found The Z force table is not found. - The force control unit is not calibrated. - Calibrate the head force control.
2014 %1 :\tZero fine phi not found
The zero fine (encoder marker
pulse) of the PHI servo is not
found in a homing action.
- Defective encoder wiring.
- Defective encoder.
- Defective motor.
- Defective motor wiring.
- Defective placement head controller.
- Check wirling.
- Check encoder.
- Check electronics (controller board).
- Retry operation, if not correct then contact your service representative.
2016 %1 :\tAmplifier phi disabled
The amplifier of the PHI servo is
disabled. - Software error in aPC. - Retry action, if not correct contact your service representative.
2017 %1 :\tPhi not homed The PHI servo is not homed. - Software error in aPC. - Retry action, if not correct contact your service representative.
2018 %1 :\tZero drift phi
The PHI servo has received to
many or to less encoder pulses
which is interpreted as a shift in
the zero fine position.
- Defective wiring.
- Defective encoder.
- Defective electronics.
- Check wiring.
- Check encoder.
- Check electronics (controller board).
- Retry operation, if not correct then contact your service representative.
2019 %1 :\tPosition error phi
Position deviation larger than
allowed in error window.
- Mechanical friction too high.
- Defective wiring.
- Defective motor.
- Defective motor controller.
- Check mechanical friction according to the procedure described in the Service
Manual.
- Check cables, motor and motor controller.
2020 %1 :\tCommunication time out phi
No response of PHI servo
controller within the defined time
interval. - Defective controller board. - Check controller board and if broken replace it and re-calibrate the head.
2021 %1 :\tCommunication error phi
Communication error inside the
head controller.
- Wrong parameters sent to PHI servo controller. This error
should not occur.
- Retry action.
- Report error to your service representative.
2022 %1 :\tTime out phi
Homing of PHI servo: Controller
not ready within the defined time
interval. - Speed defined in movement class for homing is too low.
- Check the electronics.
- Retry the operation, if not correct then contact your service representative.
2023 %1 :\tPhi encoder error
An error is reported by the PHI
encoder electronics.
- Wrong adjustment of PHI encoder.
- Defective wiring between encoder and interpolation
electronics.
- Defective PHI encoder.
- Defective interpolation electronics (IDP-101). - Contact your service representative.
