118
Usage of gripper with adapted
support height needed for
component %1
This odd component has to be
handled by a gripper with an
extended support-height, to avoid
collision with the Fiducial camera.
- This component is too large to be able to rotate it in the area
near the FA-camera and the z-guidance.
- Make sure this component is handled by a gripper with an extended support-
height, so when the head is in the upper position the top side of the component
will not collide with the FA-camera or the Z-guidance of the head.
119
Component %1 can collide with an
obstacle in the work area.
Possible
collision of
component
%1 with e.g.
top plate of
feeder trolley
During handling of the component
it may collide with a high obstacle
in the work area.
- This component must be handled with an extended gripper,
therefore the lowest parts of the component may collide with
high obstacles in the work area. - Verify that no such collision can occur.
120
Global fiducial %1 not measured
before first reference
The placement of a component is
corrected for deviations in the
board position. This is calculated
with the global fiducial alignment
correction matrix specified for the
component. The indicated fiducial
is not measured before the first
placement of a com
- There is no fiducial detection action for the indicated fiducial in
the action spec before the first placement of a component that
uses the fiducial correction matrix in which this fiducial is used. - Modify the action spec.
121
Unable to execute the order
related command - A similar command is currently being executed - Wait till the current command is executed and then try again
122
Order on machine already exists,
use a different name.
The name entered for the order to
be created for the process
program being downloaded from
the Host already
exists on the machine. - A unique name is required. - Use a different order name.
123
Action spec on machine already
exists, use a different name.
The name entered for the action
spec. to be created for the process
program being downloaded from
the Host already
exists on the machine. - A unique name is required - Use a different action spec. name.
124
Operational failed because GEM is
not operational
The requested operation could not
be performed because GEM is not
operational. GEM is not installed or there is no communication with GEM Ensure that GEM is installed and that communication is up and try again
125
Requested operation failed
because specified order does not
exist
Requested operation failed
because specified order does not
exist
- In case of upload operation the specified order does not exist
on the machine
- In case of downlad operation the specified order does not
exist on the HOST Select or specify a different order
126 The operation failed
The process program upload or
download operation failed. Unknown Try again
200 Unknown error detected
The occurred error is unknown to
the system. - Mismatch between controllers or software layers.
- Report error to your service representative.
- Make a logdisk as described in the Service Manual.
201 Illegal recovery action
The selected recovery action can
not be applied for this kind of error. - Wrong display of possible recovery actions. - Try another recovery action.
202
Fail to start transport for error
recovery
An attempt to start the transport
during an error recovery action
failed. - No servo power present. - Switch on servo power.
203 Unknown warning The warning is not specified yet. - Report error to your service representative.
204
Unknown error reported by the
system The error is not defined yet.
- An error was detected which is unknown to the human
interface.
- Retry and continue.
- Report error to your service representative.
205 %1 :\tUnknown warning The warning is not defined yet.
- A warning was detected which is unknown to the human
interface.
- Retry and continue.
- Report warning to your service representative.
206 Undefined process error
The process error is not defined
yet.
- Retry and continue.
- Report error to your service representative.
207 Retry action failed The retry action is unsuccessful. - A machine or process error occurs during the retry action.
- Check error cause and solve error.
- Retry and continue.
- If the retry action still fails, restart the system and report error to your service
representative.
208 Error reason unknown
The process controller signalized
errors, but no errors where
reported, so the reason of the
error is unknown.
- Continue
- Report error to your service representative.
209
Requested function can not be
executed.
The requested function
(Calibration) can not be executed
in this machine state.
- A board is present in the machine.
- An error is not solved on the machine
- Solve error (skip board).
- Remove board out of machine (skip board or using run-out function).
210
Sorry, this function (%1) has not
been implemented (yet)
A function was activated that has
not been implemented in the
current software version.
- Functions that are not complete yet, should not be accessible
for the user.
- By mistake, this function is reachable for the user.
- Clear the error, and do not use the function again, you should not be needing
it.
- Report error to your service representative.
211
System communication error on:
%1
An unexpected system error
occurred.
- Retry and continue.
- Restart the system.
- Report error to your service representative.
212 Communication failure in system
A communication error has been
occurred between the system
controller and the process
controller.
- No connection between the two systems.
- Malfunctioning network card on either system.
- A software problem in the machine.
- Check the coax cable connection between the two systems.
- Check the proper working of the network cards (using diagnostic software).
- Restart the system.
- Report error to your service representative.
213
Single step during error recovery
finished, press retry to resume
The machine is in step mode an
has finished a single step during
the retry of an error. - Press retry again to proceed with the next step in recovering the error.
214 Machine failure An unexpected situation occurred.
- Make a logdisk as described in the Service Manual.
- Restart the system.
- Report error to your service representative.
215
No extra information available
216
Head : %1\x0ASection :
%2\x0AFeeder : %3\x0AChannel :
%4\x0AComponent : %5\x0A
217
Section : %1\x0AFeeder :
%2\x0AChannel : %3\x0AToolbit :
%4\x0ANozzle : %5\x0AVacuum
specified : %6\x0AVacuum
measured : %7\x0AComponent :
%8
218
Automatic temperature drift
calibration failed
The automatic temperature drift
calibration failed. - Retry the operation.
219
Automatic feedersection
calibration failed
The automatic feedersection
calibration failed. - Retry the operation.
300 Machine is not stopped
The requested machine action is
only possible if the machine is
stopped.
- The requested machine action is only possible if the machine
is stopped. - Stop the machine.
301
Machine can not be started while
errors are pending
Production of boards cannot
proceed when machine errors are
pending. - Machine errors are pending. - Solve (retry) all errors and try action again.
302 No order available
The machine can not be started if
there is no default or selectable
order. - There is no order available. - Create an order with the correct selection state and try again.
303
Process errors occurred during
machine start-up
During machine start-up process
errors were detected, causing the
machine to stop.
- Please refer to the error-recovery dialog in the production menu for
appropriate actions.
304 A default order exist.
The production mode of the
machine can not be switched to
pass-through mode. - A order exists in the order schedule. - Abort the current order and try again.
305
The machine contains a
suspected or skipped board
The machine contains a
suspected or skipped board.
- Depending on whether or not the board must be removed from the machine,
the board can be removed. Then perform a retry.
306
Unable to execute production
command - A similar production command is currently being executed - Wait till the current command is executed and then try again
307
Unable to execute passthrough
command - A similar command is currently being executed - Wait till the current command is executed and then try again
400 Action spec download failed
A communication error has been
occurred between the system
controller and the process
controller.
- No connection between the two systems.
- Malfunctioning network card on either system.
- A software problem in the machine.
- Check the coax cable connection between the two systems.
- Check the proper working of the network cards (using diagnostic software).
- Make a logdisk as described in the Service Manual.
- Select skip board in error window.
- Restart the system.
-
