2705 Coplanarity :\tEntry not found
The entry for the component
identification number [3D] is not
found in the specified vision file or
the vision file is not found.
- The vision file is not on the APC.
- The entry is not in the vision file.
- Open the specific vision file in the vision menu of the machine. If that fails, the
file is missing see vision to solve this problem.
- Check the coplanarity checker component ID in the vision menu.
- When it is not in the menu, see vision for how to
2706
Coplanarity :\tCommunication
error with DIO-board
The coplanarity checker DIO
board not found.
- The coplanarity checker DIO board is not in the APC.
- The interrupt of the coplanarity checker DIO board is not
received.
- Check that the coplanarity checker DIO board is correctly inserted in the APC.
- Check the jumper setting of the coplanarity checker DIO board.
2707 Coplanarity :\tInvalid
Process error: Component not
found.
- Component is unsatisfactory.
- Component is not on the right position on the pedestal.
- The wrong component is specified.
- Search area of the component is too small.
- Calibration no longer valid.
- Check the components (are all leads visible?).
- Check the pick to see that the component is well picked.
- Check which package ID is downloaded on the coplanarity checker PC and
check that the same package ID is specified for the measured.
2708 Coplanarity :\tRework
Process error: Measurement result
in the warning area, component is
suspected.
- Unsatisfactory component.
- When many components are suspected, calibration is no
longer valid.
- Warning level of one of the measured items is too low.
- Put the suspected component on the pedestal by hand. Switch to the
coplanarity checker user interface and measure the component. See which
item caused the problem.
- Try another component.
- Check the calibration of the coplanarity checker.
2709 Coplanarity :\tReject
Process error: Measurement result
in error area, the component is
disapproved (rejected).
- Unsatisfactory component.
- When a large amount of components are unsatisfactory,
calibration is no longer valid.
- Reject level of one of the items is too low.
- Put the rejected component on the pedestal by hand. Switch to the coplanarity
checker user interface and measure the component. See which item caused
the problem.
- Try another component.
- Check the calibration of the coplanarity checker vision syste
2800
%1 :\tError detected during
production A not expected error is detected. Unknown.
- Retry.
- Report error to your service representative.
2801
%1 :\tCalibrated vacuum blocked
level out of limits
The calibrated vacuum blocked
level of the head with toolbit, is out
of limits. - Nozzle toolbit vacuum leakage.
- Check toolbit.
- Check vacuum system.
2803
%1 :\tVacuum flow of head not
calibrated
Vacuum flow of head not
calibrated. - Vacuum flow of head not calibrated. - Calibrate vacuum flow.
2804
%1 :\tPossible component on
toolbit after dump
After that the component was
dumped, the component is still
under the toolbit.
- Component error.
- Vacuum system error.
- Dirty dustcatch.
- Check vacuum system.
- Re-calibrate system.
- Check dustcatch in nozzle.
2805
%1 :\tProduction module failed to
restore state of previous shut
down
The state of the machine can not
be restored. - Production was not regularly aborted. - Delete order and restart order.
2806 %1 :\tNo toolbit attached to head No toolbit is attached to head. - No toolbit is attached to head. - Attach correct toolbit.
2809 %1 :\tWrong toolbit in head Wrong toolbit in head. - Wrong toolbit in head. - Mount correct toolbit in head (SETUP - TOOLBIT).
2811 %1 :\tFailed to pick component The component pick action failed.
- Empty feeder.
- Wrong feeder index.
- Wrong toolbit/component relation.
- Check feeder index.
- Fill the feeder with new components.
- Check the toolbit which is used to pick the component, and if it is the correct-
one specified in the action spec.
2812
%1 :\tComponent lost before CA
measurement
The component is lost from the
nozzle during the CA
measurement.
- No correct toolbit specified for this component.
- Bad pick position (coordinates).
- Check toolbit for this component.
- Remove component from toolbit if necessary.
- Check pick-coordinates for the component.
- Check vacuum level.
2813
%1 :\tComponent lost during Co
measurement
The component is lost from the
nozzle during the coplanarity
measurement. - No correct toolbit specified for this component.
- Check toolbit for this component.
- Remove component (large component).
2814
%1 :\tComponent lost during
placement
During the move from component
alignment to place the component
is lost. - Nozzle-component relation not correct. - Verify nozzle-component relation.
2815
%1 :\tComponent retained after
place
The component is still under the
toolbit, after the component has to
be placed. - Restriction in vacuum system. - Check vacuum system.
2816 %1 :\tEnd of verification test The verification is finished.
- The number of actions specified in the verification action spec
are all executed. - Remove verification board from work-area.
2817
%1 :\tFailed to pick glass
component
The glass component of the
verification set was not picked
correctly. - Attach the glass component manually to the nozzle and press skip.
2818
%1 :\tGlass component lost before
CA measurement
The glass component of the
verification set was lost before the
CA measurement. - Attach the glass component manually to the nozzle and press retry.
2819
%1 :\tGlass component lost during
placement
The glass component was lost
during the placement action. - Attach the glass component manually to the nozzle and press retry.
2820
%1 :\tGlass component retained
after place
The glass component retained at
the nozzle after placement.
- Make sure the glass component is attached to the nozzle. If not, attach
manually. Press retry.
2900 %1 :\tFlash-Prom is full
Unable to write to flash PROM, no
more space available. - Flash-PROM is full. - Purge Flash PROM (M&S).
2901
%1 :\tFlash-Prom is write-
protected
The flash PROM has one or more
locations which can not be written.
- The flash PROM is defective.
- The flash PROM is write protected.
- Install Jumper X44 on controller board.
- Replace controller board.
2902 %1 :\tPower-dip detected Power dip detected on controller. - Retry action.
2903 %1 :\tFeeder backup error
The information in the backup
RAM of the controller is not valid. - Empty battery. - Replace controller battery.
2904 %1 :\tWrong flash ID
Flash PROM is write protected, or
is of wrong type.
- The flash prom on the controller is of the wrong type.
- No jumper X44 is installed on the controller card.
- Replace with correct type: 28F256 (Intel 89B9 or SGS 20AA).
- Install jumper X44 on the controller card.
2905 %1 :\tFlash-Prom write error Unable to write to Flash PROM.
- Flash PROM is write protected.
- Defective Flash PROM.
- Install Jumper X44 on controller board.
- Replace Flash PROM of controller.
2906 %1 :\tFlash-Prom erase error Unable to erase flash PROM. - Defective Flash-PROM on controller card. - Replace Flash PROM of controller.
2907 %1 :\tCommunication error lift
The servo controller receives the
wrong parameters. - Wrong data in flash PROM (during initialize).
- Reconfigure trolley
- Recalibrate trolley
2909 %1 :\tCommunication time-out lift
A timeout has occurred during
communication with the motion
controller. - Hardware defect (LM628). - Replace tray trolley controller board.
2910 %1 :\tZero drift lift
The lift servo has received too
many or too less encoder pulses
which is interpreted as a shift in
the zero fine position.
- Defective wiring.
- Defective encoder.
- Defective electronics.
- Check defectives.
- Retry operation, if not correct contact your service representative.
2911 %1 :\tCommunication time-out lift
No response of lift servo controller
within the defined time interval.
- Defective servo controller (LM628) on the tray trolley controller
board. - Replace tray trolley controller board.
2912 %1 :\tPosition error lift
Position deviation of lift larger than
defined in error window.
- Movement outside mechanical range.
- Mechanical friction too high.
- Defective 4A fuse.
- Defective wiring.
- Defective motor.
- Defective motor controller.
- Check mechanical friction according to the procedure described in the Service
Manual.
- Check the 4A fuse.
- Check cables, motor and motor controller.
2913 %1 :\tAmplifier lift disabled
The amplifier of the lift servo is
disabled.
- Servo power is not switched on.
- Safety door is open.
- Switch on servo power.
- Close safety door.
2914 %1 :\tCommunication error puller
Communication error inside the
tray trolley controller.
- Wrong parameters sent to servo controller. This error should
not occur. - Retry action. If not correct, contact your service representative.
2915
%1 :\tCommunication time-out
puller
No response of puller servo
controller within the defined time
interval.
- Defective servo controller (LM628) on the tray trolley controller
board. - Replace tray trolley controller board.
2916 %1 :\tZero drift puller
The puller servo has received too
many or too less encoder pulses
which is interpreted as a shift in
the zero fine position.
- Defective wiring.
- Defective encoder.
- Defective electronics.
- Check defectives.
- Retry operation, if not correct contact your service representative.
2917 %1 :\tTime-out puller
Time-out during communication of
controller.
- Controller hardware error.
- Tray selection interrupted. - Check hardware.
2918 %1 :\tPosition error puller
Position deviation of puller larger
than defined in error window.
- Movement outside mechanical range.
- Mechanical friction too high.
- Defective wiring.
- Defective motor.
- Defective motor controller.
- Check mechanical friction according to the procedure described in the Service
Manual.
- Check cables, motor and motor controller.
2919 %1 :\tAmplifier puller disabled
The amplifier of the puller servo is
disabled.
- Servo power is not switched on.
- Safety door is open.
- Switch on servo power.
- Close safety door.
