39 1. After switching-on the station Technical Data: Signal Interfaces Signal Interface (20-Pin Ribbon C able Connector) to upstream station x3 to downstream stati on x4 Pin 13 GND 24 V Pin 10 Reserved Pin 14 Arrived Pin…
38
Description
S
SS
SI
II
IP
PP
PL
LL
LA
AA
AC
CC
CE
E E
E O
OO
On
nn
nli
lili
lin
nn
ne
ee
e
The product Remote Support en-
ables online access to the line
computer, station computer and
machine controller of SIPLACE
placement systems from the sup-
port centers in Munich, Norcross
and Singapore. The SIPLACE ex-
perts in the pertinent support cen-
ter can employ remote data and
the program files of the individual
SIPLACE lines in Production to an-
swer all questions about the
placement systems, immediately
and online.
S
SS
SI
II
IP
PP
PL
LL
LA
AA
AC
CC
CE
E E
E R
RR
Re
ee
em
mm
mo
oo
ot
tt
te
e e
e S
SS
Su
uu
up
pp
pp
pp
po
oo
or
rr
rt
t t
t i
ii
in
nn
n
A
AA
Ac
cc
ct
tt
tu
uu
ua
aa
al
l l
l P
PP
Pr
rr
ra
aa
ac
cc
ct
tt
ti
ii
ic
cc
ce
ee
e
Remote Support is offered on the
basis of communication via ISDN
(Integrated Services Digital Net-
work). Due to its high data trans-
mission speed (64,000 or 128,000
bits/s) ISDN is an ideal medium for
high-speed transfer of large quanti-
ties of data, the SIPLACE expert at
a “Remote Support Position”,
which consists of one line com-
puter, one station computer and a
communications router, can log
himself or herself into the corre-
sponding computers of the
SIPLACE line in the customer's
plant. Remote Support positions
are available in Munich, Norcross
and Singapore. An ISDN router is
also installed at the SIPLACE or
site LAN of the customer. There
need be only one such router per
production facility, however, if the
lines at the customer's site are in-
terconnected via a site LAN.
Basically, the same functionality is
available via Remote Support as is
possible at the local computers
(line computer, station computer
and machine controller).
To comply with the customer's
need for security where sensitive
production data are involved, many
mechanisms (automatic callback,
password protection, switch-off
mode, etc.) are integrated into the
system and can be applied specifi-
cally.
.
SIPLACE Software Architecture:
Remote Support (Option)
SIPLACE Expert Knowledge Immediately and Round the World
Customer´s production
bay
SIPLACE Support
Station
Public networks / Interfaces
Support LAN
Munich
Norcross
Singapore
Customer LAN
ISDN
39
1. After switching-on the station
Technical Data:
Signal Interfaces
Signal Interface (20-Pin Ribbon Cable Connector)
to upstream station x3 to downstream station x4
Pin 13 GND 24 V Pin 10 Reserved
Pin 14 Arrived Pin 9 Reserved
Pin 15 Permission Pin 8 Reserved
Pin 19 Request Pin 4
+30 V DC
unsaturated
Pin 20
GND 24 V for request / re-
leased (contact separation)
Pin 5 GND 24 V
Pin 18 Released Pin 6 +24 V DC
Pin 12 Trouble signal loop Pin 11 Trouble signal loop
Pin 11 Pin 12
Pin 3 +24 V DC Pin 15 Permission
Pin 2 GND 24 V Pin 13
GND 24 V for per-
mission / arrived
(contact separation)
Pin 1 +30 V DC unsaturated Pin 14 Arrived
Pin 8 Reserved Pin 18 Released
Pin 9 Reserved Pin 19 Released
Pin 10 Reserved Pin 20 GND 24 V
Requirement
Delivery
Permission
Receival
Requirement
Delivery
Permission
Receival
Transport Direction
Conveyor Section 1
PCB
Sensor
PCB
Sensor
Conveyor Section 2
Station n
transports
PCB
to delivery
Station n+1
is ready to
receive PCBs
Conveyor 1 is On Conveyor 2 is Off
40
A detailed documentation of the
PCB transport signal interface is
available on request.
Technical Data:
Signal Interfaces
Conveyor 1 is Off Conveyor 2 is On
Conveyor 1 is Off Conveyor 2 is On
Requirement
Delivery
Permission
Receival
Requirement
Delivery
Permission
Receival
2. PCB handling has started
Conveyor 1 is On Conveyor 2 is On
Transport Direction
Conveyor Section 1
Conveyor Section 2
Station n
delivers PCB
to station n+1
Station n+1
waits for PCB
from station n
Requirement
Delivery
Permission
Receival
Requirement
Delivery
Permission
Receival
PCB
Sensor
Transport Direction
Conveyor Section 1
PCB
Sensor
Conveyor Section 2
Station n
has just
delivered PCB
Station n+1
waits for PCB from
station n, but has
not received it
PCB
Sensor
3. PCB is at delivery
Transport Direction
Conveyor Section 1
PCB
Sensor
Conveyor Section 2
Station n Station n+1
has just received
the PCB
Requirement
Delivery
Permission
Receival
Requirement
Delivery
Permission
Receival
4. PCB transport is finished
