3.1.4. Operational Specifications
Table 15 lists the Edison printer operational specifications.
Table 15. Operational Specifications.
Ambient Operating Temperature
55ºF (13ºC) to 95ºF (35ºC)
Ambient Operating Relative Humidity
30% to 75% Non-Condensing
Maximum Noise Emissions
78 dB(A)
Operating AC Current
Load:
Printer Idle- 1.7 Amps rms
6 axes cycling- 3.5 Amps rms + worknest vacuum
blower- 9.5 Amps rms
INSTALLATION AND INITIAL START-UP Edison Printer User Manual (Part Number 1023838)
46 Rev. A
Copyright © 2017 ITW EAE
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of ITW EAE, unless for purchaser's personal use.
3.2. Unpacking Instructions
Unpack the Edison printer in an area suitable to safely remove crating and packing materials.
After unpacking, use a forklift to skid the printer into place in final operating area.
Attention
All retaining screws (2.5 in/ 63.5mm Phillips Head) are located within 1
in/ 25.4mm of the crate edges.
Attention—Lifting Edison Printer
ITW EAE recommends extended forklift blades of 60 in to 72 in
(152.4cm to 182.8cm) in length to ensure proper weight distribution
when lifting the printer from the skid.
Ensure forklift blades have a total width/span of 36 in (91.44cm).
Ensure the forklift blades are placed within the area designated by
the left and right forklift blade labels, located on the sides of the
printer.
Ensure the forklift is capable of lifting 3000 lbs. (1360.78 kg)
Attention
Do not permit personnel beneath forklift blades or printer at any time.
3.2.1. Remove crating.
1. Remove the screws securing the top of the crate to the front, rear and two side panels (Figure
18).
2. Remove the crate top and set aside.
a. Ensure the crate top does not fall into the crate and damage the printer.
3. Remove the screws securing one side panel to the crate.
4. Remove the side panel to expose the printer.
5. Repeat the above for the remaining side panels.
Edison Printer User Manual (Part Number 1023838) INSTALLATION AND INITIAL START-UP
Rev. A 47
Copyright © 2017 ITW EAE
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of ITW EAE, unless for purchaser's personal use.
3.2.2. Remove packing material and shipping boxes
1. If present, carefully remove blue vacuum bag from the printer (Figure 19).
2. Carefully remove shrink wrap from the printer.
Figure 19. Expose and remove printer from packing materials.
3. Locate the shipping boxes packed with the printer and move
them away from the work area (Figure 20).
4. Remove bottom of crating (Figure 21).
a. Remove the mounting hardware securing the two support timbers running from the left
side of the skid to the right side.
b. Remove the mounting hardware securing the foam isolators to the skid using a ¾ in.
socket.
c. Slide the two support timbers out from under the printer.
Figure 18. Remove crating.
Figure 20. Locate and move shipping
boxes from work area.
