INSTALLATION AND INITIAL START-UP Edison Printer User Manual (Part Number 1023838)
62 Rev. A
Copyright © 2017 ITW EAE
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of ITW EAE, unless for purchaser's personal use.
Attention
Each of the above items must be properly installed to ensure
safe transit of the printer.
3.7.2.1. Panel Support Blocks
Lift the front panel support and position the two foam blocks between the panel support and the
work table. Repeat for the rear panel support.
3.7.2.2. Table Lift Brackets
To install the brackets at the back of the printer:
1. Jog Worknest Z so its Current Position = 25.00000
2. Using six Socket Head Cap Screws (SHCS) (M4x10) and flat washers, install the two table
lift shipping brackets (1022812) and associated RBO tags securing the table to the printer
frame.
3.7.2.3. Vision Gantry
Position the vision gantry at the back of the printer, then secure the gantry to the print head
casting using one cable tie and RBO tag.
Attention
Power down the printer at this time.
3.7.2.4. Shuttle Brackets
1. Using two Socket Head Cap Screws (M4x10) and flat washers, attach one of the shuttle
shipping brackets (1022677) and associated RBO tag to the bottom of the print head casting.
2. Position the shuttle so the upper holes of the bracket align with the upper mounting holes in
the print head casting. Secure the bracket to the casting using two Socket Head Cap Screws
(M4x10) and flat washers.
Edison Printer User Manual (Part Number 1023838) INSTALLATION AND INITIAL START-UP
Rev. A 63
Copyright © 2017 ITW EAE
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of ITW EAE, unless for purchaser's personal use.
3. At the other side of the printer, attach the remaining shuttle shipping bracket (1022677) and
associated RBO tag to the print head casting using four Socket Head Cap Screws (M4x10)
and flat washers.
3.7.2.5. Wiper Brackets (front)
Using four Socket Head Cap Screws (M4x10) and flat washers, install the two front wiper
shipping brackets (1022814) and RBO tags securing the wiper to the frame.
3.7.2.6. Wiper Brackets (rear)
Using two Socket Head Cap Screws (M4x10) and flat washers, install the rear wiper shipping
bracket (1022815) and RBO tag. This bracket is located behind the take-up roll.
3.7.2.7. Stage Brackets
Using two Socket Head Cap Screws (M4x10) and flat washers, install the two stage shipping
brackets (1022675) and associated RBO tags on the right and left sides to secure the stage to the
left and right gantry shuttle arms.
3.7.3. Secure the Bypass Key
Using a cable tie, secure the Bypass Key and RBO tag to the Emergency Stop Switch.
3.7.4. Network Cable Removal
Remove the network cable from the back of the computer.
3.7.5. Light Tower Removal
1. Unplug the light tower, remove the bottom nut, and lift the tower off the top of the machine.
2. Screw the bottom nut back onto the light tower post for safe keeping.
3. Wrap the light tower in bubble wrap and pack in a box for safe keeping.
3.7.6. Air Line Removal
Disconnect the air line from the pneumatics panel.
INSTALLATION AND INITIAL START-UP Edison Printer User Manual (Part Number 1023838)
64 Rev. A
Copyright © 2017 ITW EAE
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of ITW EAE, unless for purchaser's personal use.
3.7.7. Secure the Power Cable
Unplug the power cable and place it inside the printer between the computer and the pneumatics
panel.
3.7.8. Hood Block Installation
Close the hood and, while doing so, place two foam blocks (one on each side) between the hood
and the side covers.
3.7.9. Pack and Secure the Monitor/ Monitor Arm
1. Unplug and remove the monitor from the monitor arm.
2. Screw the monitor mounting hardware into the back of the monitor, then pack the monitor in
a box for safe keeping.
3. Flip up the keyboard tray and apply bubble wrap to the tray and mounting bracket. Position
the arm against the side of the printer.
3.7.10. Crate the Printer
Attention
ITW EAE recommends using extended forklift blades of 60 in
to 72 in (152.4cm to 182.8cm) in length to ensure proper
weight distribution of the printer.
Forklift blades must have a total width/span of 36 in
(91.44cm).
Ensure forklift blades are placed within the area designated
by the left and right forklift blade labels, located on the sides
of the printer.
Forklift must be capable of lifting 3000 lbs. (1360.7 kg)
Attention
Install the shipping isolator mounting hardware in the same
holes used for the leveling pads.
