5 W orkstation Products Product No. Description ECWS61M-1 Band, 6 ft. (1.8 m) cord 3M ™ Wrist Strap ECWS61M-1 3M ™ Wrist Strap 2272 3M ™ Wrist Strap — Adjustable Elastic Fabric (Economy Performance) This wrist strap set …
4
Workstation Products
For more product information, please visit www.3M.com/static
3M
™
Wrist Strap — Adjustable Elastic
Fabric (Premium Performance)
This wrist strap set features a fully adjustable, stretch elastic wrist band
and a 6 ft. or 12 ft. (1.8 m or 3.6 m) coiled cord. The hypoallergenic,
silver-plated band provides 360-degree conductivity around the wrist
for maximum skin contact. The band fabric is extra-soft and avoids the
scratchy feel of other bands. A machined snap provides a consistent
1 pound removal force. The polyurethane polymer strain relief survives
1 million flexes. Made in the USA. Meets these standards: ANSI/ESD
S20.20, EIA 625, MIL-STD-1686, and MIL-HDBK-263.
Cord Features
• Polyurethane, high tensile
strength coiled cord.
• High quality coiled cord:
1,000,000 bending cycles.
• UL Listed. Date coded
for traceability.
• Made in the USA.
Band Features
• Machined snap (4 mm)
for a reliable connection.
• Soft, hypoallergenic
silver-plated band.
• Stainless steel
(302 Series) backplate.
• Adjustable, locking clasp.
• UL Listed. Date coded
for traceability.
• Made in the USA.
3M
™
Wrist Strap — Adjustable Elastic
Fabric (Standard Performance)
This wrist strap set features a fully adjustable stretch fabric wrist band
and 6 ft. (1.8 m) coiled cord. The band provides 360-degree conductivity
around the wrist for maximum skin contact. Band curling is reduced by
the woven band fabric. The retractable coiled cord connects to the wrist
band via a 1/8 in. (4 mm) post snap and contains a 1 megohm resistor.
A “spinning style” banana jack reduces cord tangles and improves
the cord’s life span. Meets the requirements of ANSI/ESD S20.20, EIA
625, MIL-STD-1686, and MIL-HDBK-263. Includes alligator clip. Band
available in blue or maroon.
Features
• 360-degree wrist contact.
• 6 ft. (1.8 m) coiled cord.
• 1/8 in. (4 mm) snap.
Product No. Description
WBB-AFWS61M
Fabric Wrist Band,
6 ft. (1.8 m) coiled cord
WBB-AFWS121M
Fabric Wrist Band,
12 ft. (3.6 m) coiled cord
WBB-AFWS
Fabric Wrist Band, Blue/White
CC61M
6 ft. (1.8 m) coiled cord
CC121M
12 ft. (3.6 m) coiled cord
RACC61M
6 ft. (1.8 m) coiled cord,
right angle plug (not UL listed)
RACC121M
12 ft. (3.6 m) coiled cord,
right angle plug (not UL listed)
Product No. Description
BLUEWS61M
Fabric Wrist Band, blue,
6 ft. (1.8 m) coiled cord
BLUEWS121M
Fabric Wrist Band, blue,
12 ft. (3.6 m) coiled cord
BLUEWS
Fabric Wrist Band, blue
BLCC61M
6 ft. (1.8 m) coiled cord
BLCC121M
12 ft. (3.6 m) coiled cord
Product No. Description
MWS61M
Fabric Wrist Band, maroon,
6 ft. (1.8 m) coiled cord
MWS121M
Fabric Wrist Band, maroon,
12 ft. (3.6 m) coiled cord
MWS
Fabric Wrist Band, maroon
MCC61M
6 ft. (1.8 m) coiled cord
MCC121M
12 ft. (3.6 m) coiled cord
3M
™
Adjustable Elastic Fabric Wrist Band
3M
™
Wrist Strap BLUEWS61M
3M
™
Coiled Cord CC61M
5
Workstation Products
Product No. Description
ECWS61M-1
Band, 6 ft. (1.8 m) cord
3M
™
Wrist Strap ECWS61M-1
3M
™
Wrist Strap 2272
3M
™
Wrist Strap — Adjustable Elastic
Fabric (Economy Performance)
This wrist strap set provides a cost effective means of grounding
production staff. Featuring an adjustable fabric wrist band, a 6 ft.
(1.8 m) retractable coiled cord and a 1/8 in. (4 mm) snap.
3M
™
Wrist Strap — Adjustable Elastic
Fabric (Economy Performance)
This wrist strap set provides a cost-effective method of grounding
personnel. Features a comfortable, adjustable band, a 5 ft. (1.5 m)
coiled cord and 1/8 in. (4 mm) snap.
Features
• Meets the requirements of ANSI/ESD S20.20, MIL-STD-1686, and EIA 625.
• Cost-effective design.
• 6 ft. coiled cord.
• 1/8 in. (4 mm) snap.
• Alligator clip included.
Product No. Description
2271
Economy Adjustable Fabric Wrist Band is made
of stretch weave fabric, blue color with white trim.
2272
Economy Adjustable Wrist Band with coiled cord.
5 ft. (1.5 m) practical extended length, blue color
with white trim. Includes alligator clip.
3M
™
Adjustable Thermo Plastic Wrist
Strap (Economy Performance)
The 3M Adjustable Wrist Straps 4600 Series feature a thermoplastic band
with an integrally molded conductive interior. The wrist strap utilizes an
easy on/easy off adjustable “zipper” style latching mechanism and is
available with 1/8 in. (4 mm) snaps and 5 ft. (1.5 m) and 10 ft. (3.0 m)
ground cords.
3M
™
Wrist Strap 4600 Series shown with ground cord and alligator clip
Product No. Description
4620
Blue Wrist Band with 1/8 in. (4 mm) stud
4650
Blue Wrist Band with 5 ft. (1.5 m) coiled cord
Wrist Straps
6
Workstation Products
For more product information, please visit www.3M.com/static
3M
™
Wrist Band 2205
3M
™
Wrist Band AMWS
3M
™
Wrist Strap — Adjustable Metal
(Premium Performance)
Made from jewelry-quality stainless steel, our durable metal wrist band
creates a superior electrical contact to the user’s wrist. The flex-metal
style band uses adjustable links to assure a secure and comfortable fit.
This product meets the requirements of ESD Standard 1.1, ANSI/ESD
S20.20, MIL-STD-1686, MIL-HDBK-263, and EIA 625.
3M
™
Metal Wrist Band — Fixed Size
(Premium Performance)
3M Metal Wrist Bands 2200 Series feature quality Speidel
™
metal
expansion bands for durability and comfort. Each link is covered with
an insulative plastic cap. Compatible with the 3M
™
Wrist Strap Ground
Cords 2210, 2220 and 4610/4611.
Three sizes are available: small for user’s wrists from 4.5 in. to 6 in.
(114 mm to 152 mm) in circumference; medium for user’s wrists from
5.5 in. to 7.25 in. (140 mm to 184 mm); and large for user’s wrists larger
than 6.5 in. (165 mm). Available with 1/8 in. (4 mm) snap end. This
product meets the requirements of ESD Standard 1.1, ANSI/ESD S20.20,
MIL-STD-1686, MIL-HDBK-263, and EIA 625.
Features
• Metal band for durability and easy cleaning.
• Tough outer band coating to protect wearer from electrical hazards.
• Lot coded for traceability.
Product No. Description
2205
Bulk pack of 25 metal wrist bands (Small)
2206
Bulk pack of 25 metal wrist bands (Medium)
2207
Bulk pack of 25 metal wrist bands (Large)
Product No. Description
AMWS61M
Adjustable Metal Wrist Band,
6 ft. (1.8 m) coiled cord
AMWS121M
Adjustable Metal Wrist Band,
12 ft. (3.6 m) coiled cord
AMWS
Adjustable Metal Wrist Band
