39 W orkstation Products Dissipative V inyl Mats/Rolls Product No. Description Size, ft. (m) 8254 Floor Roll, Blue 4 x 24 (1.2 x 7.2) 8261 T able Roll, Brown 2 x 24 (0.6 x 7.2) 8263 T able Roll, Gray 2 x 24 (0.6 x 7.2) 8…
38
Workstation Products
For more product information, please visit www.3M.com/static
Non-standard sizes available on custom order basis up to 50 ft. (15.2 m) maximum length.
Product No. Description Size, ft. (m)
8852
Table Roll,
No Hardware, Green
3 x 40 (0.9 x 12.2)
8860
Table Roll, Gray 3 x 24 (0.9 x 7.2)
8861
Table Roll, Blue 3 x 24 (0.9 x 7.2)
8862
Table Roll, Green
3 x 24 (0.9 x 7.2)
8870
Floor Mat, Gray 4 x 6 (1.2 x 1.8)
8871
Floor Mat, Blue 4 x 6 (1.2 x 1.8)
8872
Floor Mat, Green 4 x 6 (1.2 x 1.8)
8880
Floor Roll, Gray 4 x 24 (1.2 x 7.2)
8881
Floor Roll, Blue 4 x 24 (1.2 x 7.2)
8882
Floor Roll, Green 4 x 24
(1.2 x 7.2)
8890
Floor Roll,
No Hardware, Gray
4 x 40 (1.2 x 12.2)
8891
Floor Roll,
No Hardware, Blue
4 x 40 (1.2 x 12.2)
8892
Floor Roll,
No Hardware, Green
4 x 40 (1.2 x 12.2)
88A0
Table Mat, Gray 2 x 3 (0.6 x 0.9)
88A1
Table Mat, Blue 2 x 3 (0.6 x 0.9)
88A2
Table Mat, Green 2 x 3 (0.6 x 0.9)
88B0
Table Mat, Gray 2 x 2 (0.6 x 0.6)
88B1
Table Mat, Blue 2 x 2 (0.6 x 0.6)
88B2
Table Mat, Green 2 x 2 (0.6 x 0.6)
3M
™
Dissipative Vinyl Three-Layer Mats
and Rolls (Premium Performance)
3M Mats and Rolls 8200 Series are soft table and floor mats with a
unique three-layer construction. The top layer is durable static dissipative
vinyl, which has sufficiently low resistance to discharge static-laden
conductors, yet will prevent the shorting of pins on the backs of printed
circuit boards laid on the mat. The middle layer is a highly conductive
scrim that provides the main discharge path to ground, and the bottom
layer is static dissipative foam, providing a durable nonskid cushion.
Non-standard sizes are available on a custom order basis. Compatible
with constant monitors.
3M
™
Floor Mats 8200 Series
Includes one 15 ft. (4.6 m) 3M
™
Ground Cord 3040 and two
3M
™
Snap Fasteners 3050 (installed).
3M
™
Floor Rolls 8250, 8290, 82A Series
Includes two 15 ft. (4.6 m) 3M Ground Cords 3040 and two
3M Snap Fasteners 3050 to be installed by customer.
Note: 8290 and 82A – no hardware included.
3M
™
Table Mats 8210 + 8220 Series
Includes two 3M Snap Fasteners 3050 (installed) and one 3M
™
Wrist
Strap Grounding System 3048. Wrist Straps must be ordered separately.
3M
™
Table Rolls 8230, 8240, 8260,
8270, 8280 Series
Includes two 15 ft. (4.6 m) 3M Ground Cords 3040 and two
3M Snap Fasteners 3050 to be installed by user.
Note: 8230, 8240, 8270 and 8280 – no hardware included.
3M
™
Mats and Rolls 8200 Series
* Tested per ESD Association Standard S4.1 at 72°F, 50% RH using 3M
™
Test Kit
701 for Static Control Surfaces (Megohmmeter).
Note: Non-standard sizes available on custom order basis up to
50 ft. (15.2 m) maximum length.
Properties
Property Typical Value
Material
Top and Bottom Layers — Vinyl
Thickness
0.138 in. (3.5 mm)
Hardness
40 – 50 Shore A
*Resistance
(Surface to Ground)
1 x 10
7
ohm
(Surface to Surface)
4 x 10
7
ohm
Wrist Straps...........................................................pg. 2
Heel Grounders .......................................................pg. 26
Static Control Surface Mark Remover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 44
39
Workstation Products
Dissipative Vinyl Mats/Rolls
Product No. Description Size, ft. (m)
8254
Floor Roll, Blue 4 x 24 (1.2 x 7.2)
8261
Table Roll, Brown 2 x 24 (0.6 x 7.2)
8263
Table Roll, Gray 2 x 24 (0.6 x 7.2)
8264
Table Roll, Blue 2 x 24 (0.6 x 7.2)
8271
Table Roll,
No Hardware, Brown
3 x 50 (0.9 x 15.0)
8273
Table Roll,
No Hardware, Gray
3 x 50 (0.9 x 15.0)
8274
Table Roll,
No Hardware, Blue
3 x 50 (0.9 x 15.0)
82A1
Floor Roll,
No Hardware, Brown
4 x 50 (1.2 x 15.0)
82A3
Floor Roll,
No Hardware, Gray
4 x 50 (1.2 x 15.0)
82A4
Floor Roll,
No Hardware, Blue
4 x 50 (1.2 x 15.0)
8281
Table Roll,
No Hardware, Brown
2 x 40 (0.6 x 12.2)
8283
Table Roll,
No Hardware, Gray
2 x 40 (0.6 x 12.2)
8284
Table Roll,
No Hardware, Blue
2 x 40 (0.6 x 12.2)
8291
Floor Roll,
No Hardware, Brown
4 x 40 (1.2 x 12.2)
8293
Floor Roll,
No Hardware, Gray
4 x 40 (1.2 x 12.2)
8294
Floor Roll,
No Hardware, Blue
4 x 40 (1.2 x 12.2)
The requirements of ESD Standard 4.1, ESD Standard 20.20, EIA 625, MIL-HDBK-263,
and MIL-STD-1686. RTG: 10
7
ohm; RTT: 10
7
; Thickness: .0125 in. Compatible with
Constant Monitors.
Product No. Description Size, ft. (m)
8201
Floor Mat, Brown 4 x 6 (1.2 x 1.8)
8203
Floor Mat, Gray 4 x 6 (1.2 x 1.8)
8204
Floor Mat, Blue 4 x 6 (1.2 x 1.8)
8211
Table Mat, Brown 2 x 4 (0.6 x 1.2)
8213
Table Mat, Gray 2 x 4 (0.6 x 1.2)
8214
Table Mat, Blue 2 x 4 (0.6 x 1.2)
8221
Table Mat, Brown 2 x 3 (0.6 x 0.9)
8223
Table Mat, Gray 2 x 3 (0.6 x 0.9)
8224
Table Mat, Blue 2 x 3 (0.6 x 0.9)
8231
Table Roll,
No Hardware, Brown
2 x 50 (0.6 x 15.0)
8233
Table Roll,
No Hardware, Gray
2 x 50 (0.6 x 15.0)
8234
Table Roll,
No Hardware, Blue
2 x 50 (0.6 x 15.0)
8241
Table Roll,
No Hardware, Brown
2.5 x 50 (0.75 x 15.0)
8243
Table Roll,
No Hardware, Gray
2.5 x 50 (0.75 x 15.0)
8244
Table Roll,
No Hardware, Blue
2.5 x 50 (0.75 x 15.0)
8251
Floor Roll, Brown 4 x 24 (1.2 x 7.2)
8253
Floor Roll, Gray 4 x 24 (1.2 x 7.2)
40
Workstation Products
For more product information, please visit www.3M.com/static
3M
™
Ultra-R2 Rubber — Two Layer
(Standard Performance)
Excellent resistance to solvents, hot solder and soldering irons makes
the Ultra-R2 mats an excellent static safe work surface. Excellent
electrical performance is provided by using a two-layer combination
of static dissipative and conductive rubber materials. Ultra-R2 mats
combine the low contact resistance and convenience of soft mats,
and the conductivity and durability of hard laminates. Meets the
requirements of ESD Standard 4.1, ESD Standard 20.20, EIA 625,
MIL-HDBK-263, and MIL-STD-1686. Rtg: 10
6
ohm; Rtt: 10
7
ohm;
Thickness: 0.060 in. (1.5 mm). Compatible with constant monitors.
Use green mats to indicate lead-free work areas.
3M
™
Mat Kits Includes mat, two snaps, installed, and a 15 ft. (4.5 cm) ground cord
Size Blue P/N Gray P/N Green P/N
24 in. x 36 in.
(60.1 cm x 91.4 cm)
RM2436L2RBL-L RM2436L2RGR-L RM2436L2RGN-L
24 in. x 48 in.
(60.1 cm x 121.9 cm)
RM2448L2RBL-L RM2448L2RGR-L RM2448L2RGN-L
Rolls/Runners
2 ft. x 50 ft.
(0.61 m x 15.0 m)
RM24600L2RBL RM24600L2RGR RM24600L2RGN
3 ft. x 50 ft.
(0.9 m x 15.0 m)
RM36600L2RBL RM36600L2RGR RM36600L2RGN
2.5 ft. x 50 ft.
(0.76 m x 15.0 m)
RM30600L2RBL RM30600L2RGR NA
4 ft. x 50 ft.
(1.2 m x 15.0 m)
RM48600L2RBL RM48600L2RGR RM48600L2RGN
Call for custom sizes.
3M
™
Dissipative Vinyl — Three-Layer
(Standard Performance)
This three-layer vinyl mat provides excellent electrical properties.
The top layer is tough, easy to clean, dissipative vinyl. The center layer,
a highly conductive metal scrim, moves the charge from the surface
to ground quickly. The bottom layer is a durable, non-skid cushion of
dissipative foam. While not as durable as the two-layer rubber material,
this three-layer vinyl is designed to be cost effective. Meets the
requirements of ESD Standard 4.1, ESD Standard 20.20, EIA 625,
MIL-HDBK-263, and MIL-STD-1686. Rtg: 10
7
ohm; Rtt: 10
7
ohm;
Thickness: 0.125 in. (3.2 mm). Compatible with constant monitors.
3M
™
Mat Kits Includes mat, two snaps, installed, and a 15 foot ground cord
Size Blue P/N Gray P/N
24 in. x 36 in.
(60.1 cm x 91.4 cm)
TM2436L3RBL-L TM2436L3RGR-L
24 in. x 48 in.
(60.1 cm x 121.9 cm)
TM2448L3RBL-L TM2448L3RGR-L
Rolls
2 ft. x 50 ft.
(0.61 m x 15.0 m)
TM24600L3RBL TM24600L3RGR
3 ft. x 50 ft.
(0.9 m x 15.0 m)
TM36600L3RBL TM36600L3RGR
2.5 ft. x 50 ft.
(0.76 m x 15.0 m)
TM30600L3RBL TM30600L3RGR
4 ft. x 50 ft.
(1.2 m x 15.0 m)
TM48600L3RBL TM48600L3RGR
Call for custom sizes.
3M
™
Dissipative Vinyl Mat
3M
™
Vinyl — Homogeneous
(Economy Performance)
One-layer static dissipative vinyl for good electrical properties and long
wear. Meets the requirements of MIL-HDBK-263 and MIL-STD-1686.
Rtg: 10
9
-10
10
ohm; Rtt: 10
9
-10
10
of ohm; Thickness: 0.093 in. (0.23 cm).
Not compatible with workstation monitors.
3M
™
Mat Kits Includes mat, two snaps, installed, and a 15 foot ground cord
Size Blue P/N Gray P/N
24 in. x 36 in.
(60.1 cm x 91.4 cm)
TM2436L1BL-L TM2436L1GR-L
24 in. x 48 in.
(60.1 cm x 121.9 cm)
TM2448L1BL-L TM2448L1GR-L
Rolls
2 ft. x 50 ft.
(0.61 m x 15.0 m)
TM24600L1BL TM24600L1GR
3 ft. x 50 ft.
(0.9 m x 15.0 m)
TM36600L1BL TM36600L1GR
2.5 ft. x 50 ft.
(0.76 m x 15.0 m)
TM30600L1BL TM30600L1GR
4 ft. x 50 ft.
(1.2 m x 15.0 m)
TM48600L1BL TM48600L1GR
Call for custom sizes. All mat kits are also available without the kit accessories.
