43
Workstation Products
Dissipative Sheets and Worksurfaces
3M
™
Dissipative Hard Laminate Sheets
Dissipative Hard Laminate Sheets are used where a hard, durable,
electrically safe surface is needed, providing a low coefficient of
friction to permit heavy objects to slide easily. Controlled conductivity
(surface-to-ground) virtually eliminates shock hazard when working
on a powered component.
This material is post-formable with normal high pressure laminate
process techniques used by furniture makers. Using this technique,
a tight 0.5 in. (12.7 mm) radius is possible, which allows installation
without seams in corners and over rounded edges when forming parallel
to sanding lines. The laminate provides a comfortable rounded front on
which personnel can rest their arms. It is resistant to common solvents
and to hot solder droppings.
3M
™
Dissipative Rigid Worksurfaces
Static Dissipative Rigid Worksurface 8300 Series have the high abrasion
resistance of a laminate, yet are as easy to install as table mats. The
nonglare surface also resists staining, scorching and common solvents.
All edges and corners are rounded, and the laminate comes ready to
use with two factory-installed snap fasteners, and one 3M
™
Grounding
System 3048 for wrist strap/table mat.
Note: For consistent static charge dissipation from rigid,
conductive flat-bottomed totes and trays, use of a pad or mat
of 3M Dissipative Vinyl Material 8200 in conjunction with this
static-protective hard laminate is suggested, especially in areas
where relative humidity often drops below 30%.
3M
™
Dissipative Hard Laminate Sheets
3M
™
Rigid Worksurface 8300 Surface
Non-standard sizes and colors are also available, subject to minimum order quantity.
* Tested per ESD Association Standard 4.1 at 72oF, 50% RH using 3M Test Kit 701 for Static
Control Surfaces (Megohmmeter)
Product No. Color Size, ft. (m)
8360
Beige
4 x 8
3 x 12
5 x 12
(1.2 x 2.4)
(0.9 x 3.7)
(1.5 x 3.7)
8365
Gray
4 x 8
3 x 12
5 x 12
(1.2 x 2.4)
(0.9 x 3.7)
(1.5 x 3.7)
8375
White 5 x 12 (1.5 x 3.7)
Product No. Color Size, in. (cm)
8343
Beige 0.125 x 24 x 36 (0.32 x 61.0 x 91.0)
8344
Gray 0.125 x 24 x 36 (0.32 x 61.0 x 91.0)
8353
Beige 0.125 x 24 x 36 (0.32 x 61.0 x 91.0)
8354
Gray 0.125 x 24 x 36 (0.32 x 61.0 x 91.0)
Properties
Property Typical Value
Thickness
0.037 in. (0.94 mm)
Hardness
Abrasion resistance:
> 1500 cycles Tabor Wheel 32
*Resistance
(Surface to Ground)
7 x 10
6
ohm
(Surface to Surface)
6 x 10
7
ohm
Wrist Straps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 2
Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 12
Static Control Surface Mark Remover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 44
Dissipative Rubber Mats/Rolls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 37
Static Control Surface Mark Remover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 44
Static Control Floor Tile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg. 112
44
Workstation Products
For more product information, please visit www.3M.com/static
3M
™
Clean Walk Mats
3M Clean Walk Mats 5830 are designed to remove dirt and contaminants
from shoe soles, wheels and other passing objects on contact. When
the top sheet becomes soiled, it can be peeled back to reveal a clean
adhesive sheet underneath.
3M
™
Worksurface Cleaning Products
The 3M Static Control Surface Mark Remover 8001 is an extra-strength
fluid that is designed to remove ordinary dirt and grime as well as
difficult spots and stains from all types of static control surfaces, such
as table mats, floor mats, hard-laminate benchtops, portable field-
service kit work surface, etc. Unlike many cleaning products, the 3M
Static Control Surface Mark Remover 8001 is not corrosive, per FTMS
101C, Method 3005, and leaves no tacky residue that attracts dirt,
attacks delicate parts, or increases the contact resistance of the surface.
It is a clear, colorless, homogeneous, water-based liquid that contains
detergents, conditioners and other cleaning additives and has a fresh,
clean scent.
3M laboratory tests have proven the cleaner to be an excellent topical
antistat, maintaining a consistent surface resistivity (1x10
11
ohm/square)
over extended periods in both normal (55% RH) and dry (13% RH)
environments. Simply spray on any washable surface and wipe off with a
clean cloth or sponge — no rinsing required. The cleaner is designed to be
used full-strength and supplied in handy quart spray bottles.
3M
™
Static Control Surface Mark Remover 8001
Product No. Description
5380
Clean Walk Mats, 30 mats per pad
Size, in. (cm)
18 x 36 (45.7 x 85.7)
18 x 45 (45.7 x 114.3)
25 x 45 (63.5 x 114.3)
Product No. Description
8001
Surface Mark Remover
Size: 1 quart spray (32 oz.)
Shelf-life: two years
3M
™
Clean Walk Mats 5830
Product No. Description
ANTISTAT1QT or
ANTISTAT1GAL
Topical Antistat Spray
Size: 1 quart spray (32 oz.)
1 gallon jug
Product No. Description
LOTION8OZ or
LOTION1GAL
Static Safe Hand Lotion
Size: 8 oz.
1 gallon
3M
™
Topical Antistatic Spray
Staticide is a safe, easy-to-use, topical antistatic solution that can be applied
to walls, ceilings, floors, carpets, fixtures, worksurfaces, tools, equipment,
conveyor belts, clothing, and other materials to render them non-static
generating. Meets the requirements for topical antistats as required in
MIL-HDBK-263. Available in 1 quart spray bottle or 1 gallon jug.
3M
™
Static Safe Hand Lotion
This static dissipative, non-contaminating lotion keeps skin moist for
better contact between the wrist strap and the skin, as recommended
by MIL-HDBK-263. Available in 8 oz. or 1 gallon plastic bottles.
45
Workstation Products
Cleaning Products and Ionizer Selection Guide
3M
™
Ionizer Selection Guide
Model 960 963 980 991
Type
Single DC Blower x x
Overhead Triple Fan DC Blower x
Tool DC Blower x x
Ionizer Gun x
Applications
Workbenches x x x
Tools x x
Material Handling x x x
Industries
Electronics Assembly x x x x
Back End Semiconductors x x x x
Military x x x x
Medical Equipment x x x x
Aerospace x x x x
