52 W orkstation Products For more pr oduct information, please visit www .3M.com/static 3M ™ Portable Field Service Kit (Premium Performance) The 3M Portable Field Service Kit 8505 is a small, lightweight kit that offers…
51
Workstation Products
Ionization Controller and Monitors, Signs, Posters, Aisle Marking Tape
3M
™
Signs
Protect your products by notifying staff and visitors that static control
precautions are required. Signs and Aisle Marking Tape allow you to
clearly identify the areas requiring static protective measures. Apply
them to doors, floors, walls, tote boxes, or to any area containing static
sensitive parts. As part of ISO9000, many companies have implemented
ESD control programs that reference the standards ESD 20.20, EIA 625,
or MIL-HDBK-263. These standards require that work areas for static
sensitive items be designated.
3M
™
ESD Warning Signs
These signs provide the warning message and symbol as required by EIA
625 and MIL-HDBK-263. Black lettering on a yellow background gives
clear warning that static-safety precautions are necessary. Signs come
complete with adhesive strips for easy mounting.
3M
™
ESD Warning Posters
These poster-sized 17 x 22 in. (43.2 x 55.9 cm) signs are great for
building and section entry areas. Available in English or Spanish.
Packaged five posters per box.
3M
™
Aisle Marking Tape
Protect your products by notifying staff and visitors that static control
precautions are needed. ESD Aisle Marking Tape allows you to clearly
identify the areas requiring static protective measures. This 6 mil,
scuff-resistant tape features a repeating ESD Warning Symbol and message.
Bright yellow background makes the black text easy to read. Rolls are
3 in. (7.6 cm) wide and 54 ft. (16.5 m) long on a 3 in. (7.6 cm) core.
3M
™
ESD Warning Sign,
8.5 in. x 11 in. (21.6 cm x 27.9 cm)
3M
™
ESD Warning Poster,
17 in. x 22 in., Spanish (43.2 cm x 55.9 cm)
3M
™
ESD Warning Poster,
17 in. x 22 in., English (43.2 cm x 55.9 cm)
3M
™
ESD Warning Sign,
4 in. x 10 in. (10.2 cm x 25.4 cm)
3M
™
Aisle Marking Tape, 3 in. x 54 ft. (7.6 cm x 16.5 m)
Product No. Description
ESDSIGN4X10
4 in. x 10 in. (10.2 cm x 25.4 cm) Sign
ESDSIGN8.5X11
8.5 in. x 11 in. (21.6 cm x 27.9 cm) Sign
SIGN17X22E
17 in. x 22 in. (43.2 cm x 55.9 cm)
Sign, English
SIGN17X22S
17 in. x 22 in. (43.2 cm x 55.9 cm)
Sign, Spanish
AISLETAPE54
3 in. x 54 ft. (7.6 cm x 16.5 cm)
Caution Tape
52
Workstation Products
For more product information, please visit www.3M.com/static
3M
™
Portable Field Service Kit
(Premium Performance)
The 3M Portable Field Service Kit 8505 is a small, lightweight kit that
offers the same level of static control as the full-sized 3M
™
Field Service
Kit 8501, yet is small enough to fit in a shirt pocket.
Custom logo imprinting on the worksurface is available.
3M
™
Portable Field Service Kit 8505
Tested per ESD Association Standard 4.1 at 72OF, 50% RH using 3M
™
Test Kit 701 for Static
Control Surfaces (Megohmmeter).
8505 Properties
Typical Property Value
Resistance: 1 x 10
6
ohm to 1 x 10
9
ohm
(Surface-to-ground)
Product No. Description
8505
Lightweight Portable Field Service Kit
Kit contains:
• Static Dissipative Worksurface with Pocket
0.015 H x 15 W x 20 in. L
(0.38 mm x 38 cm x 51 cm)
• 3M
™
Adjustable Wrist Band 2204
• Lightweight Heavy-Duty Coiled Ground Cords:
3M
™
Wrist Strap Ground Cord 2240, 5 ft. (1.5 m)
3M
™
Extension Ground Cord 2243, 5 ft. (1.5 m)
3M
™
Worksurface Ground Cord 3063, 5 ft. (1.5 m)
• 3M
™
Alligator Clip 3038
3M
™
Field Service Kit Product Selection Guide
Features Model
Premium
Portable, 22 in. x 24 in. (55.9 cm x 61 cm), static dissipative, red worksurface, includes Wrist Strap Monitor 725 and dual conductor wrist strap 8507
Portable, 15 in. x 20 in. (38.1 cm x 50.8 cm), static dissipative, red, lightweight worksurface, includes adjustable fabric wrist strap and grounding accessories 8505
Standard
Portable, 22 in. x 24 in. (55.9 cm x 61 cm), static dissipative, red worksurface, includes adjustable fabric wrist strap and grounding accessories 8501
8.75 in. x 24 in. (22.2 cm x 61 cm) static dissipative, red worksurface, includes adjustable fabric wrist strap and grounding accessories, installed in
remote, unattended telephone switching enclosures
8502
Economy
Portable, 24 in. x 24 in. (61 cm x 61 cm), static dissipative, red worksurface, includes adjustable fabric wrist strap and grounding accessories, low cost FSKL3RD
Field Service Kits
Sensitive microelectronic components can be damaged, even destroyed,
by one ever-present enemy — static electricity. Electronic equipment is
especially susceptible to static electricity during servicing.
Static dissipative products manufactured by 3M are designed to
provide protection at a variety of field service sites, from typical office
environments to remote telephone terminals. The standard field service
kit quickly and reliably removes any static charge on the technician and
provides a durable, static-free surface upon which to lay parts. The
lightweight version offers the same protection in a flexible, compact
package. The telephone terminal service kit is especially designed to be
installed at remote telephone switches or CEVs to provide convenient
static protection on-site.
Practicing proper static control in the field can save time, money and
aggravation for both your customers and your company. Enable your
technicians to do the job right the first time with a static dissipative
portable field service kit from 3M.
53
Workstation Products
Field Service Kits
3M
™
Portable Field Service Kit
(Standard Performance)
The 3M Portable Field Service Kit 8501 is designed to provide effective
static protection in a compact package for the electronics field technician.
The entire kit folds to a size that fits easily into most tool cases. Two
pockets sewn into the worksurface provide storage for the cords.
3M
™
Portable Field Service Kit 8501
Custom logo imprinting on the worksurface is available.
Tested per ESD Association Standard 4.1 at 72OF, 50% RH using 3M
™
Test Kit 701 for Static
Control Surfaces (Megohmmeter).
8501 Properties
Typical Property Value
Resistance: 1 x 10
6
ohm to 1 x 10
9
ohm
(Surface-to-ground)
Product No. Description
8501
Static Dissipative Portable Field Service Kit
Kit includes:
• Static-Dissipative Worksurface
0.021 H x 22 W x 24 in. L
(0.53 x 56 x 61 cm)
• 3M
™
Ground Cord Assembly 3051
• 3M
™
Alligator Clip 3038
• 3M
™
Adjustable Wrist Band 2204
3M
™
Portable Field Service Kit
(Premium Performance)
The 3M Portable Field Service Kit 8507 with a 3M
™
Wrist Strap
Monitor 725 bundles together two static control products to give a field
technician the same continuously monitored, static protected working
environment as that enjoyed by workers in a manufacturing facility.
3M
™
Portable Field Service Kit 8507
Product No. Description
8507
Portable Field Service Kit includes Wrist Strap Monitor
725 and Dual Conductor Wrist Strap
Kit contains:
• Static Dissipative Worksurface, foldable,
0.021 H x 22 W x 24 in. L (0.53 mm x 56 cm x 61 cm)
red with gray cotton edging. Two pockets, each
8 in. x 11 in. (20.3 cm x 28.0 cm), ground snap.
• 3M
™
Wrist Strap Monitor 725, 2.5 H x 2.6 W x 1.1 in. L
(6.4 x 6.6 x 2.8 cm), black. Battery-powered, 9 V (not
included). Ground cord, 6 ft. (1.8 m), with ground clip.
Ground snap on unit to connect to the worksurface.
• 3M
™
Dual Conductor Adjustable Fabric Wrist Band 2368
• 3M
™
Dual Conductor Coiled Cord 2370, 10 ft. (3.0 m)
