3M
™
Workstation Products Selection Guide
56
Workstation Products
For more product information, please visit www.3M.com/static
Image Product No. Description
723
Accessory Belt Clip to be used with the 3M
™
Wrist Strap Monitor 725
724P
Power Supply for 3M
™
Wrist Strap Workstation Monitor 724 and 3M
™
Static Monitor 790
724VK
Monitor Verification Kit. Verifies the resistance range of the Workstation Monitor 724
725VK
Monitor Verification Kit. Verifies the resistance range of the Wrist Strap Monitor 725
732
Replacement Remote Input Jack. 6 ft. (1.8 m) long cord.
To be used with Workstation Monitor 724.
733
Remote Splitter Kit. 6 ft. (1.8 m) long cord. To be used with Workstation Monitor 724.
740P
Power Supply for 3M
™
Wrist Strap and Footwear Tester 740
746P
Power Supply for 3M
™
Wrist Strap Tester 746
790VK
Verification Kit. One 5 ft. (1.5 m) Dual Conductor Cord 2360, one test wrist band socket
assembly, and one two-wire male connector with 24 in. (0.61 m) lead wire.
2380
Monitor/Table Mat Replacement Cord, 6 ft. (1.8 m), with 10 mm snap. Extends from
the 3M
™
Wrist Strap Workstation Monitor 724 to the static control worksurface to be
monitored. This cord does not have a resistor molded into the snap fastener cap.
2389
Monitor/Table Mat Interconnect Cord, 10 ft. (3 m), with 10 mm snap. A straight cord
with male snap fasteners at each end and no resistors. Used to interconnect two
monitored worksurfaces.
3M
™
Accessories Selection Guide
57
Workstation Products
Image Product No. Description
3033
Snap Fastener, male, 0.125 in. (3.2 mm) hole, 10 mm diameter. For mats and runners. 1800/8800 Series.
3034
Snap Fastener, female, 0.125 in. (3.2 mm) hole, 10 mm diameter. For 3M
™
Mats and Runners
1800/8800 series.
3037
Insulated Bulldog Clip. Fits standard banana plug.
3038
Uninsulated Alligator Clip. Fits standard banana plug.
3040
Ground Cord, 15 ft. (4.6 m), with 10 mm snap. Molded-in male snap fastener with integral
1 megohm resistor on one end, solderless terminal on other. Connects all 3M
™
Static Control Mats
and Runners to building ground.
3041
Grounding Kit for 3M
™
Static Protective Hard Laminate includes #10 screw, lock washer, #10 nut,
lock washer wing nut, #10 self-tapping screw and one 10 ft. (3.0 m) ground cord. Ground cord has
a 1 megohm resistor.
3042
Wrist Strap Grounding System. Grounds two single conductor wrist straps and conveniently
mounts beneath the edge of most work benches. Comes complete with 10 ft. (3.0 m) ground cord.
3043
Interconnect Cord 5 ft. (3.5 m), with 10 mm snap. Molded-in male snap fastener at each end.
Connects all static control mats and runners to each other. Ground cord has a 1 megohm resistor.
CTA242
This remote terminal connects to WS Aware workstation monitors and provides connection for
dual wire wrist straps for an operator and a visitor. Patented plug-in replaceable board with the
jacks reduces cost of ownership of the monitor since only one inexpensive board needs to be
replaced when the jacks are worn out, instead of the entire terminal.
CTA243
Before sensitive devices are handled, Big Brother alarms alert the operator to plug-in. Once Big Brother
senses that the operator is properly grounded the alarm is silenced. The Big Brother wrist strap terminal
makes the WS Aware one of the most intelligent and cost-effective systems on the market today.
CTA245
Replacement board with jacks for WS Aware remote monitors CTA242 and CTA243.
FGC150M
FGC151M
The low profile beveled cap prevents the cord from being accidentally removed from the mat.
A 3/8 in. (10 mm) stud securely snaps to the mat, and at the other end of the 15 ft. (4.5 m) cord
is a ring terminal.
WSGR2
This metal grounding block accommodates two wrist straps and comes complete with mounting
hardware. Designed to be mounted under the bench and keep the wrist strap connections safe.
The integral 15 ft. (4.5 m) cord ends with a ring terminal. Two 4 mm parking studs hold coiled
cords to reduce damage to cords left at the bench. No resistor.
