57
Workstation Products
Image Product No. Description
3033
Snap Fastener, male, 0.125 in. (3.2 mm) hole, 10 mm diameter. For mats and runners. 1800/8800 Series.
3034
Snap Fastener, female, 0.125 in. (3.2 mm) hole, 10 mm diameter. For 3M
™
Mats and Runners
1800/8800 series.
3037
Insulated Bulldog Clip. Fits standard banana plug.
3038
Uninsulated Alligator Clip. Fits standard banana plug.
3040
Ground Cord, 15 ft. (4.6 m), with 10 mm snap. Molded-in male snap fastener with integral
1 megohm resistor on one end, solderless terminal on other. Connects all 3M
™
Static Control Mats
and Runners to building ground.
3041
Grounding Kit for 3M
™
Static Protective Hard Laminate includes #10 screw, lock washer, #10 nut,
lock washer wing nut, #10 self-tapping screw and one 10 ft. (3.0 m) ground cord. Ground cord has
a 1 megohm resistor.
3042
Wrist Strap Grounding System. Grounds two single conductor wrist straps and conveniently
mounts beneath the edge of most work benches. Comes complete with 10 ft. (3.0 m) ground cord.
3043
Interconnect Cord 5 ft. (3.5 m), with 10 mm snap. Molded-in male snap fastener at each end.
Connects all static control mats and runners to each other. Ground cord has a 1 megohm resistor.
CTA242
This remote terminal connects to WS Aware workstation monitors and provides connection for
dual wire wrist straps for an operator and a visitor. Patented plug-in replaceable board with the
jacks reduces cost of ownership of the monitor since only one inexpensive board needs to be
replaced when the jacks are worn out, instead of the entire terminal.
CTA243
Before sensitive devices are handled, Big Brother alarms alert the operator to plug-in. Once Big Brother
senses that the operator is properly grounded the alarm is silenced. The Big Brother wrist strap terminal
makes the WS Aware one of the most intelligent and cost-effective systems on the market today.
CTA245
Replacement board with jacks for WS Aware remote monitors CTA242 and CTA243.
FGC150M
FGC151M
The low profile beveled cap prevents the cord from being accidentally removed from the mat.
A 3/8 in. (10 mm) stud securely snaps to the mat, and at the other end of the 15 ft. (4.5 m) cord
is a ring terminal.
WSGR2
This metal grounding block accommodates two wrist straps and comes complete with mounting
hardware. Designed to be mounted under the bench and keep the wrist strap connections safe.
The integral 15 ft. (4.5 m) cord ends with a ring terminal. Two 4 mm parking studs hold coiled
cords to reduce damage to cords left at the bench. No resistor.
Workstation Accessories
3M
™
Accessories Selection Guide
No Photo
Available
For more product information, please visit www.3M.com/static
58
Workstation Products
3M
™
Scotch-Brite
™
High Performance Cloth 2011
The 3M Scotch-Brite High Performance Cloth 2011 is an efficient
cleaning tool consisting of microfibers in a unique knit pattern. The
Scotch-Brite High Performance Cloth is specifically designed with a
unique combination of bi-component microfibers and knit construction.
This combination provides excellent dust, oil and water pickup with
minimal linting. The bi-component aspect of the microfibers allows for
both oil and water absorption while the microfiber’s ribbon-like shape
provides the maximum surface area for the collection of dust, oil and
water. The unique knit pattern of tufts and valleys allows both small and
large particulates to be trapped within the Scotch-Brite High Performance
Cloth. The combination of microfiber and knit construction provides a
versatile non-scratching tool allowing the Scotch-Brite Cloth to be used
on a wide variety of substrates including delicate surfaces.
The Scotch-Brite High Performance Cloth may be used dry or damp,
with or without cleaning chemicals.
3M
™
Scotch-Brite
™
High Performance Cloths 2011
Note: The 3M Scotch-Brite High Performance Cloth 2011 does
not have static dissipative properties.
Physical Characteristics
Property Typical Value Test Method
Size
12.6 in. x 14.2 in. (32 cm x 36 cm) HCC-TM-69
Thickness
0.062 in. (1.57 mm) HCC-TM-69
Weight
1.09 oz. (30.8 g) HCC-TM-69
Fiber Type
Polyester and nylon
Tuft Density
37 per square cm HCC-TM-86
Water Absorption
7.2 g water per g wipe HCC-TM-73
Oil Absorption
7.1 g oil per g wipe HCC-TM-73
Artificial Sebum Removal
(artificial skin oil)
98% gloss recovery HCC-TM-90
Drag (dry, kinetic coefficient)
Glass
Cross Direction
0.85
0.41
HCC-TM-75
(modified)
Tear Resistance (6400 g pendulum)
Machine Direction
Cross Direction
5570
gram force
4290 gram force
HCC-TM-75
Resistant to
Household Ammonia
Household Bleach
Household Cleaner/Degreaser
Vinegar
Mineral Oil
Vegetable Oil
Linting
Minimal
Laundering
Launderable to 95ºC (200ºF)
Product No. Description
2011
Scotch-Brite
™
High Performance Cloths, 50 per case
Examples of Intended Use
• Fingerprint removal from glass
• Removing glaze and polish from painted metals
• Polishing furniture
• Cleaning and polishing brass
• Dust removal
Standard Size
12.6 in. x 14.2 in (32 cm x 36 cm)
Colors
Blue
Green
Red
Yellow
White
59
Workstation ProductsPackagingWorkstation Solutions
Static Control Packaging
and Transportation Products
3M provides a wide range of static shielding and
barrier packaging products to protect sensitive
electronic components from static charges during
transit and while in storage. To meet your specific
needs, 3M provides shielding bags, cushioned
bags and wrap, moisture barrier bags and more in
a variety of sizes and material composition.
3M
™
Conductive Resin Products are easily
grounded to prevent holding a static charge.
Available as film, tubing, bags and drum liners, this
material is made of opaque, volume-conductive,
carbon-impregnated polyolefin.
The electrical characteristics are not affected by
humidity, and are suited for material handling,
shipping and storage.
Packaging
2
Note: All specifications are subject to change without notice.
