Packaging Protection You Can Trust
3M provides the static control packaging to protect electronic items from electrostatic, physical and environmental damage during manufacture,
transportation, and storage. 3M packaging can help you to build a compliant ANSI/ESD S20.20 static control program. S20.20 now refers to
ANSI/ESD S541 to set the performance goals for packaging:
S541 Requirements for Protective Packaging
1. Low charge generation
2. Dissipative or conductive materials for intimate contact
3. A structure that provides electrostatic discharge shielding
Following the Road Map to More Packaging Protection
The 2005 ESD Association Technology Road Map shows that, due to the continued reduction in device size, chips will become more sensitive to static
though 2010, reaching sensitivity levels not observed since 1980. Also, the Industry Council on ESD has proposed that on-chip protection levels be
lowered by half to save space on devices and increase speed. As sensitivity climbs, and on-chip protection falls, robust ESD protective packaging will
be even more critical.
Choose the Protection that You Need
From the following pages, choose the packaging that fits your application, or contact 3M for application guidance.
3M
™
Static Shielding and Moisture Barrier Bags are
tested to comply with ESDA, industry and customer
standards. Cost effective metal-in bags and high
protection metal-out bags allow you to meet protection
requirements for a wide range of device sensitivities.
61
Packaging
3M
™
Dri-Shield System for Dry Packaging
Use the 3M Dri-Shield System 033 to protect SMDs from moisture damage and meet the IPC/JEDEC J-STD-033 standard.
3M
™
Moisture Barrier Bag
Exceeds the MVTR requirements of <.002.
Page 74
3M
™
Moisture-Sensitive Caution Label
Blue print on white label as required
by STD-033.
Page 81
3M
™
Humidity Indicator Card (HIC)
5%, 10%, 60% sensitivity.
Page 80
3M
™
Vacuum Sealer
Removes air to reduce bulk, and heat seals the
bag closed.
Page 81
3M
™
Desiccant
Complies with MIL-D-3464.
Page 81
