76 For more pr oduct information, please visit www .3M.com/static 3M ™ Dri-Shield 3000 Moisture Barrier Bag Made from static dissipative nylon, aluminum foil, and static dissipative pol yeth yle ne, t he ba g off ers e x…
75
3M
™
Moisture Barrier Bags Product Selection Guide
Product Technology Benefit Application Page
Bags for MIL-PRF-81705 MVTR
Dri-Shield 2000
Moisture Barrier
Bag, Aluminized,
3.6 mil
Bags are made from multiple layers
of metallized polyester and dissipative
polyethylene. Bags protect SMDs from
moisture and static damage. Flexible
structure is easy to vacuum seal.
Lot coded for QC traceability.
Dry packaging of devices in
compliance with MIL-PRF-81705
MVTR.
78
3370
Moisture Barrier
Bag, Aluminized,
3.6 mil
Bags are made from multiple layers
of metallized polyester and dissipative
polyethylene. Bags protect SMDs from
moisture and static damage. Contains
no amines, amides or N-Octanoic Acid.
Outgassing levels are extremely low.
Outgassing levels are extremely
low. Dry packaging of devices in
compliance with MIL-PRF-81705
MVTR.
78
Puncture Resistant
Dri-Shield 2700
Puncture Resistant
Moisture Barrier
Bag, Aluminized,
7 mil
Dri-Shield 2700 bags provide superior puncture
resistance and drop test performance. This
reduces vacuum loss due to punctures from
sharp trays and rough handling. Bags protect
from moisture and static damage. Lot coded
for QC traceability.
Highest puncture resistance to
reduce vacuum loss. Dry packaging
of devices in compliance with
MIL-PRF-81705 MVTR.
79
Low Voltage Retention (Metal-Out)
Dri-Shield 2500
Metal-Out Moisture
Barrier Bag,
Aluminized, 3.6 mil
Combines the moisture barrier technology
and low charge retention for charge retention
of less than 50 volts and shielding as low
as 1 nJ. Stops static damage to transient-
sensitive GMR devices.
Dry packaging of devices in
compliance with MIL-PRF-81705
MVTR.
79
ZipTop Reclosable Barrier Bags
Dri-Shield 3400 ZipTop
Reclosable ZipTop
Moisture Barrier
Bag, Foil, 4 mil
ZipTop feature makes the bag easy to open
and close. Dri-Shield 3400 bags are made
from a high barrier foil structure. Bags
should be heat sealed to fully protect SMDs
from moisture.
Reclosable to allow for access to
parts. Dry packaging of devices
in compliance with IPC/JEDEC
J-STD-033.
76
Dri-Shield 2000 ZipTop
Reclosable ZipTop
Moisture Barrier
Bag, Aluminized,
3.6 mil
ZipTop feature makes the bag easy to open
and close. Bags should be heat sealed to
fully protect from moisture.
Reclosable to allow for access to
parts. Dry packaging in compliance
with MIL-PRF-81705.
78
Moisture Barrier Bags Selection Guide
3M
™
Moisture Barrier Bag with 3M
™
Humidity Indicator Card and 3M
™
Desiccant
Packaging
76
For more product information, please visit www.3M.com/static
3M
™
Dri-Shield 3000 Moisture Barrier Bag
Made from static dissipative nylon, aluminum foil, and static dissipative
polyethylene, the bag offers extremely low MVTR and is designed
to provide maximum moisture protection for surface mount devices
(SMD). Please inquire for sizes. Bags are RoHS Compliant* and
lead-free**.
Features
• Meets the requirements of IPC/JEDEC J-STD-033.
• Strong, heat sealable, suitable for vacuum packaging.
• Meets electrical and physical requirements of EIA 583,
ESD S541, EIA625, and MIL-PRF-81705, and ANSI/ESD S20.20.
• Static safe: dissipative inner and outer surfaces.
• Amine free, passes outgassing and corrosion tests.
• Used for packaging SMDs in trays, shipping tubes, and tape and reel.
• Printed with ESD and moisture symbols; lot coded for traceability.
• Testable to industry standards.
3M
™
Dri-Shield 3400 Moisture Barrier Bag
Specially designed for high volume applications, this bag offers the
barrier properties required by JEDEC specs at a lower cost. Please
inquire for sizes. Bags are RoHS Compliant* and lead-free**.
Features
• Meets the requirements of IPC/JEDEC J-STD-033.
• Strong, lightweight, heat sealable, suitable for vacuum packaging.
• Meets electrical and physical requirements of EIA 583, ESD S541,
EIA625, and MIL-PRF-81705, and ANSI/ESD S20.20.
• Static safe: dissipative inner and outer surfaces.
• Amine free, passes outgassing and corrosion tests.
• Used for packaging SMDs in trays, shipping tubes, and tape and reel.
• Printed with ESD and moisture symbols; lot coded for traceability.
• Testable to industry standards.
Dri-Shield 3000 Properties
Physical Properties
MVTR <0.0003 g/100
sq.in./24 hrs
ASTM F 1249
Puncture Resistance 17 lbs MIL-STD-3010
Tear Strength (Elmendorf) 980 grams ASTM D1922
Thickness 6.1 mils ±10%
Tensile Strength 5400 PSI, 380kg/cm
2
ASTM D882
Seal Strength >15 lbs ASTM D882
Electrical Properties
Surface Resistivity/Resistance
ASTM D257 ANSI/ESD STM11.11
Interior <10
12
ohm/square or <10
11
ohm
Exterior <10
12
ohm/square or <10
11
ohm
Metal <100 ohm
Static Shielding <15 volts MIL-PRF-81705, EIA 541
Static Shielding <10 nJ ANSI/ESD S11.31
EMI Attenuation 45 dB MIL-PRF-81705
Static Decay <0.03 seconds MIL-STD-3010
Silicone or Amine Content Not detected FTIR
Dri-Shield 3400 Properties
Physical Properties
MVTR <0.0003 g/100
sq.in./24 hrs
ASTM F 1249
Puncture Resistance 20 lbs MIL-STD-3010
Tear Strength (Elmendorf) 110 grams ASTM D1922
Thickness 4.0 mils SCC 008
Tensile Strength 8500 PSI, 598kg/cm
2
ASTM D882
Seal Strength >15 lbs ASTM D882
Electrical Properties
Surface Resistivity/Resistance
ASTM D257 ANSI/ESD STM11.11
Interior <10
12
ohm/square or <10
11
ohm
Exterior <10
12
ohm/square or <10
11
ohm
Metal <100 ohm
Static Shielding <20 volts MIL-PRF-81705, EIA 541
Static Shielding <10 nJ ANSI/ESD S11.31
EMI Attenuation 45 dB MIL-PRF-81705
Static Decay <0.01 seconds MIL-STD-3010
Silicone or Amine Content Not detected FTIR
3M
™
Dri-Shield 3400 Moisture Barrier Bag
3M
™
Dri-Shield 3000 Moisture Barrier Bag
Packaging
RoHS
Compliant
2002/95/EC
RoHS
Compliant
2002/95/EC
77
3M
™
Dri-Shield 3200 Metal-Out
Moisture Barrier Bag
This bag is engineered to provide low charge retention and rapid static
decay. Low MVTR provides maximum moisture protection for surface
mount devices. Please inquire for sizes. Bags are RoHS Compliant*
and lead-free**.
Features
• Metal layer is positioned near the outer surface for fast charge decay
and low charge retention.
• Meets the requirements of IPC/JEDEC J-STD-033.
• Strong, lightweight, heat sealable, suitable for vacuum packaging.
• Meets electrical and physical requirements of EIA 583, ESD S541,
EIA625, and MIL-PRF-81705, and ANSI/ESD S20.20.
• Static safe: dissipative inner and outer surfaces.
• Amine free, passes outgassing and corrosion tests.
• Used for packaging SMDs in trays, shipping tubes, and tape and reel.
• Printed with ESD and moisture symbols; lot coded for traceability.
• Testable to industry standards.
Dri-Shield 3200 Properties
Physical Properties
MVTR <0.0003 g/100
sq.in./24 hrs
ASTM F1249
Puncture Resistance >20 lbs MIL-STD-3010
Tear Strength (Elmendorf) 110 grams ASTM D1922
Thickness 4.0 mils SCC 008
Tensile Strength 8500 PSI,
598kg/cm
2
ASTM D882
Seal Strength >15 lbs ASTM D882
Electrical Properties
Surface Resistivity/Resistance
ASTM D257 ANSI/ESD STM11.11
Interior <10
12
ohm/square or <10
11
ohm
Exterior <10
5
ohm/square or <10
9
ohm
Metal <100 ohm
Static Shielding <20 volts MIL-PRF-81705, EIA 541
Static Shielding <10 nJ ANSI/ESD S11.31
EMI Attenuation 45 dB MIL-PRF-81705
Static Decay <0.01 seconds MIL-STD-3010
Charge Retention <100 volts CPM
Silicone or Amine Content Not detected FTIR
3M
™
Dri-Shield 3700 Moisture Barrier Bag
This puncture resistant bag offers more strength for packaging items
with sharp edges. Low MVTR provides maximum moisture protection for
surface mount devices. Please inquire for sizes. Bags are RoHS
Compliant* and lead-free**.
Features
• Meets the requirements of IPC/JEDEC J-STD-033.
• Puncture resistant.
• Strong, lightweight, heat sealable, suitable for vacuum packaging.
• Meets electrical and physical requirements of EIA 583, ESD S541,
EIA625, and MIL-PRF-81705, and ANSI/ESD S20.20.
• Static safe: dissipative inner and outer surfaces.
• Amine free, passes outgassing and corrosion tests.
• Used for packaging SMDs in trays, shipping tubes, and tape and reel.
• Printed with ESD and moisture symbols; lot coded for traceability.
• Testable to industry standards.
Dri-Shield 3700 Properties
Physical Properties
MVTR <0.0003 g/100
sq.in./24 hrs
ASTM F1249
Puncture Resistance >25 lbs MIL-STD-3010
Tear Strength (Elmendorf) 185 grams ASTM D1922
Thickness 4.0 mils SCC 008
Tensile Strength 13000 PSI,
914kg/cm
2
ASTM D882
Seal Strength >15 lbs ASTM D882
Electrical Properties
Surface Resistivity/Resistance
ASTM D257 ANSI/ESD STM11.11
Interior <10
12
ohm/square or <10
11
ohm
Exterior <10
12
ohm/square or <10
11
ohm
Metal <100 ohm
Static Shielding <20 volts MIL-PRF-81705, EIA 541
Static Shielding <10 nJ ANSI/ESD S11.31
EMI Attenuation 45 dB MIL-PRF-81705
Static Decay <0.01 seconds MIL-STD-3010
Silicone or Amine Content Not detected FTIR
3M
™
Dri-Shield 3200 Metal-Out Moisture
Barrier Bag
3M
™
Dri-Shield 3700 Moisture Barrier Bag
(label optional)
Moisture Barrier Bags
Packaging
RoHS
Compliant
2002/95/EC
RoHS
Compliant
2002/95/EC
