3M
™
Conductive Bags
3M Conductive Bags 2004 are made of opaque, volume-conductive
carbon impregnated polyolefin. They are easily grounded and the electrical
characteristics are not affected by age or humidity. The standard bags are
readily heat-sealable and 4 mils thick. 100 bags per pack.
3M
™
Conductive Drum Liners
3M Drum Liners 2014 do not hold static charge when grounded.
Commonly used as waste container liners, for holding chemicals that could
be ignited by a static caused spark, or dry chemicals that tend to cling to
ordinary nonconductive static-laden plastics. 100 bags per box.
3M
™
Conductive Bags 2004
* Typical values for 4.0 mil film.
Physical characteristics will change with other thicknesses.
Conductive Packaging Properties
*
Property Test Method Typical Value
Thickness
ASTM D2103 4 mil (102 microns)
Strength
Breaking Factor
Puncture
ASTM D882 10 lbs./in.
Fed Std 101 8 lbs.
Heat Seal Parameters
Temperature
Time
Pressure
180°F – 250°F
0.5 – 5.0 sec.
20 – 60 PSI
(1.4 x 105 –
4.1 x 105 N/m2)
Vicat Softening Temp.
-50°F – 150°F
(-46°C – 66°C)
Vicat Softening Temp. ASTM D1525 83°C
Electrical Properties
Volume Resistivity
Static Decay
ASTM D991 <500 ohm-cm
EIA-541 <2 sec.
Water Vapor
Transmission
ASTM F372 3 g/sq. m/day
Chemical Susceptibility
Dilute Acids and Alkalies
Concentrated Acids & Alkalies
Alcohols (Isopropanol)
Hydrocarbons (Heptane)
Ketones (Acetone)
Oil and Gasoline
Aromatic Hydrocarbons
(Toluene) Shelf Life
ASTM D543
Resistant
Slight Attack
Resistant
Moderate Attack
Slight Attack
Moderate Attack
Severe Attack
Indefinite
Product No. Description
2014
Drum Liners.
Wall thickness: 4.0 mil. (102 microns) 100 per box
Standard Sizes, in. (cm)
5 gallon: 18 x 24 (45 x 60)
20 gallon: 24 x 36 (61 x 91)
30 gallon: 30 x 36 (76 x 91)
*55 gallon: 38 x 58 (96 x 147)
* Available 50 per box
Product No. Description
2004
Conductive Bags.
Wall thickness: 4.0 mil. (102 microns)
100 bags per pack
Standard Sizes, in. (cm)
5 x 8 (12.7 x 20.3)
6 x 10 (15.2 x 25.4)
8 x 12 (20.3 x 30.5)
10 x 12 (25.4 x 30.5)
12 x 16 (30.5 x 40.6)
15 x 18 (38.1 x 45.7)
Custom Size, in. (cm)
4 x 4 to 42 x 72 (10.2 x 10.2 to 106.7 x 182.9)
3M
™
Conductive Drum Liner 2014
Packaging
RoHS
Compliant
2002/95/EC
RoHS
Compliant
2002/95/EC
85
3M
™
Conductive Film
This film is opaque, volume-conductive, carbon-impregnated polyolefin,
and is commonly used for material handling, shipping and storage in the
electronic or chemical industries.
3M
™
Conductive Tubing
3M Conductive Tubing 1724 is made of opaque, volume conductive
carbon-impregnated polyolefin, and is used to make bags and sleeves for
specialized packaging or storage requirements. The tubing is heat-sealable
and can be used on automated packaging lines.
Note: Shelf life of products made with conductive resin is five
years. Variations in storage conditions such as temperature
fluctuation, exposure to sunlight or high humidity may reduce
the shelf life.
3M
™
Conductive Film 1700, 1760 Series
3M
™
Conductive Tubing 1724
Product No. Description
Short Rolls
1724
Lay Flat Conductive Tubing.
Thickness: 4.0 mil. (102 microns)
Widths, in. (m) Approx. Length/Roll, ft. (m)
5 (12.7) 500 (152)
12 (30.5) 500 (152)
Product No. Description
Short Rolls
1704
Film. Thickness: 4.0 mil. (102 microns)
Widths, in. (m) Approx. Length/Roll, ft. (m)
36 (0.9) 150 (45.7)
54 (1.4) 150 (45.7)
72 (1.8) 150 (45.7)
1706
Film. Thickness: 6.0 mil. (152,4 microns)
Widths, in. (m) Approx. Length/Roll, ft. (m)
36 (0.9) 150 (45.7)
54 (1.4) 150 (45.7)
72 (1.8) 150 (45.7)
1708
Film. Thickness: 8.0 mil. (203,2 microns)
Widths, in. (m) Approx. Length/Roll, ft. (m)
36 (0.9) 150 (45.7)
54 (1.4) 150 (45.7)
72 (1.8) 150 (45.7)
Long Rolls
1764
Film. Thickness: 4.0 mil. (102 microns)
Widths, in. (m) Approx. Length/Roll, ft. (m)
36 (0.9) 150 (45.7)
Conductive Bags, Drum Liners, Film and Tubing
Packaging
RoHS
Compliant
2002/95/EC
RoHS
Compliant
2002/95/EC
86
For more product information, please visit www.3M.com/static
3M
™
Single Card Carriers
3M Static Shielding Single Card Carriers protect individual printed circuit
boards from static and physical damage during storage and transport.
Interiors are lined with dissipative cushioning foam.
3M
™
Single Card Carrier
300 mil 400 mil 600 mil
3M
™
Single Device Carriers
The rugged injection-molded 3M
™
Single Device Carrier 5701 is
designed to provide cost-effective physical and static protection for
DIPs. The conductive units are volume resistive and will not lose their
conductivity with age, nor do they depend on humidity to function.
Single Device Carrier 5701 meets EIA-541 requirements for static
shielding. A unique “saddle” design supports device leads and helps
prevent accidental bending. Other design features include a smooth
front surface on the container to adhere labels and a living hinge cover
that snaps securely shut. Carrier accepts up to 18-pin 300 mil and 400
mil devices, and up to 28-pin 600 mil devices.
3M
™
Single Device Carrier 5701
3M
™
Conductive Containers
Conductive containers are ideal for static-safe storage, kitting, and
in-process handling and transporting of static-sensitive assemblies
and devices. Made from injection-molded plastic, these containers are
noncorrosive and lightweight. Static-sensitive devices can be transported
in these containers which provide protection from static discharge and
from static fields.
Product No. Length Width Depth
in. (cm) in. (cm) in. (cm)
8520
10 (25.4) 8 (20.3) 1.25 (3.2)
8521
12 (30.5) 9 (22.9) 1.25 (3.2)
8522
18 (45.7) 17 (43.2) 2 (5.1)
8523
10 (25.4) 8 (20.3) 2 (5.1)
Product No. Length Width Depth
in. (cm) in. (cm) in. (cm)
5701
1.55 (3.9) 1.01 (2.6) 0.46 (1.2)
All dimensions are referenced from the inside bottom of the container and are nominal dimensions.
All dimensions are referenced from the inside bottom of the container and are nominal dimensions.
Packaging
