93 Product No. 3M ™ T est Equipment Measures Application Grounding — Metal Ground Ground Pro CTM051 Ground Integrity Meter Ground impedance, EMI (high frequency noise) on ground, AC and DC voltage on ground Production eq…
92
For more product information, please visit www.3M.com/static
Product No. 3M
™
Test Equipment Measures Application
ESD Events/EMI
CTC034
CTC034-030
CTC034-031
EM Aware
ESD Monitors
ESD events
Static field
Ionizer balance
Ionizer decay
Diagnostics of ESD environment;
tool ESD qualification;
ESD audit; problem troubleshooting
CTK1A4-C
CTK1AM4-C
CTK2A6-C
CTK2AM6-C
CTK3A5-C
CTK3AM5-C
EM Aware
ESD Monitors
Starter Kits
ESD events
Static field
Ionizer balance
Ionizer decay
Diagnostics of ESD environment;
tool ESD qualification;
ESD audit; problem troubleshooting
CTC082
ESD Pro
ESD Event Handheld
Indicator
ESD events Diagnostics of ESD environment;
ESD audit; problem troubleshooting
CTK053
EMI/ESD Diagnostics Kit ESD events, EMI Diagnostics of ESD and EMI
environment,
problem troubleshooting
Static Field
718
Static Sensor Static field Charged objects and surfaces
711
Charge Analyzer
Also see EM Aware above
Static field, Ionization
performance
Charge retention/
drainage
Charge generation/
drainage
Static field measurements
Ionization balance and decay
Static dissipative materials, mats,
surfaces and surface treatments
Wrist straps
Floor tiles
Ionization
711
Charge Analyzer Static field, Ionization
performance
Charge retention/
drainage
Charge generation/
drainage
Ionization balance and decay
Static field measurements
Static dissipative materials, mats,
surfaces and surface treatments
Wrist straps
Floor tiles
718 + 718A
Air Ionizer Test Kit
Also see EM Aware above
Ionization balance,
Ionization decay
Air ionizers
Test Equipment
93
Product No. 3M
™
Test Equipment Measures Application
Grounding — Metal Ground
Ground Pro
CTM051
Ground Integrity Meter Ground impedance,
EMI (high frequency
noise) on ground,
AC and DC voltage on
ground
Production equipment, tools
Semiconductor, hard disk, flat panel
display, electronic manufacturing
Grounding — Dissipative Grounds
701
Test Kit for Static Control
Surfaces
Resistance surface-to-
ground and surface-to-
surface
Dissipative surfaces
Mats
Floors
Tiles
Materials
SRMETER
Surface Resistance Meter Resistivity in ohm/
square (ASTM D257
units), resistance in
ohm (ANSI/ESD S11.11
UNITS) and resistance
to ground (RTG) for
mats
Dissipative surfaces
Mats
Floors
Tiles
Materials
Shoe / Wrist Strap Testers
740
Wrist Strap and Footwear
Tester
Resistance Single conductor wrist straps,
heel straps, shoes
746
Wrist Strap Tester Resistance
Single conductor wrist straps
747
Wrist Strap and Footwear
Tester
Resistance Single conductor wrist straps,
heel straps, shoes
Instrumentation Verification Instruments
CTE701A
Workstation Monitor
Checker
Resistance, voltage,
high-frequency signal
For WS Aware, Ground Master, Iron
Man Plus and Ground Man Plus
724VK
Verification Kit for 724
Workstation Monitors
Resistance 724 workstation monitors
725VK
Verification Kit for 725
Workstation Monitors
Resistance 725 workstation monitors
Instrument Selection Guide
Test Equipment
94
For more product information, please visit www.3M.com/static
3M
™
ESD Pro
ESD Pro is a hand-held indicator of ESD events that shows the relative
strength of each ESD event and counts the number of ESD events above
the set threshold. ESD events, or electrostatic discharges, can damage
sensitive electronic components. The ultimate goal of ESD protection
such as grounding, wrist straps, ionizers and static dissipative mats is to
prevent ESD events, or at least decrease their strength and frequency of
occurrence. The only way to verify that your ESD protection works is by
knowing whether you have ESD events in your environment, how strong
they are and how many of them occur. Thus, ESD Pro serves as your
ultimate measure of effectiveness of your ESD protection.
ESD Pro is capable of rejecting most non-ESD related EMI
(electromagnetic interference) events. This methodology allows
assessment of the ESD environment in places where EMI events
resulting from stepper motors, solenoids, relays, etc. occur.
Product No. Description
CTC082
Hand-held ESD event indicator with event
count, adjustable threshold and relative event
strength indicator.
Size, in. (cm)
6.25 H x 3.75 W x 1.25 L (15.8 x 9.5 x 3.3)
3M
™
ESD Pro
Test Equipment
