Page +$1:+$ 62 DECAN F2 Full Dual Conveyor (1/12) 1 2 A 3 Entry Zone Extension Assy Exit Zone Extension Assy
Page
+$1:+$
61
DECAN
F2
Page
+$1:+$
62
DECAN
F2
Full Dual Conveyor (1/12)
1
2
A
3
Entry Zone Extension Assy
Exit Zone Extension Assy
Page
+$1:+$
63
DECAN
F2
Full Dual Conveyor (1/12)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
A AM03-011121A CONVEYOR-FD_LR_ASSY 1
AM03-011693A ASSY,CONVEYOR-FD_LR_EX_PT 1
AM03-011391A CONVEYOR-FD_LR_EX_ASSY 1
AM03-011695A ASSY,CONVEYOR-FD_RL_EX_PT 1
AM03-011397A CONVEYOR-FD_RL_EX_ASSY 1
1 AM03-011700A ASSY,CONVEYOR-FD_ENTRY_ZONE_PT 1
AM03-011123A CONVEYOR-FD_ENTRY_ZONE_LR_ASSY 1
AM03-011702A ASSY,CONVEYOR-FD_ENTRY_ZONE_EX_PT 1
AM03-011393A CONVEYOR-FD_ENTRY_ZONE_LR_EX_ASSY 1
2 AM03-010588A SM511_WORK_ZONE_ASSY_LR 1
AM03-011604A SM511_WORK_ZONE_ASSY_RL 1
3 AM03-011701A ASSY,CONVEYOR-FD_EXIT_ZONE_PT 1
AM03-011122A CONVEYOR-FD_EXIT_ZONE_LR_ASSY 1
AM03-011703A ASSY,CONVEYOR-FD_EXIT_ZONE_EX_PT 1
AM03-011392A CONVEYOR-FD_EXIT_ZONE_LR_EX_ASSY 1
