Protection hood output side left
Page 6 / 8 18.11.2021
Pos. Item no. Description Part marking
1 00301868S03 COVER RIGHT SIDE SIPLACE 80S
2 00316445-01 SAFETY SCREEN RIGHT
3 00301870S03 COVER LEFT SIDE SIPLACE 80S
4 00316471-01 SAFETY SCREEN LEFT
5 00304540-02 SIDE PANEL RIGHT
6 00301962-02 SIDE PANEL RIGHT HAND
7 00304519-01 BARCODE RAIL - RIGHT SIDE
8 00304548-01 ACTUATOR PART
9 00304577-01 FLEXIBLE ACTUATOR AZ 15/16 SPARE PART
10 00304567-01 CONTACT LEVER
00304576-01 BALL KNOB E25/M6
11 00095565-01 HEXAGON NUT
12 00095321-01 SLOTTED COUNTERSUNK HEAD
SCREW
13 00095120-01 HEXAGON SOCKET HEAD CAP
SCREW
14 00095108-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 12-8.8
15 00095110-01 HEXAGON SOCKET HEAD CAP
SCREW
16 00317575-01 PROTECTION CLIP
17 00320860-01 SLOTTED COUNTERSUNK HEAD
SCREW
18 00317455-01 SHIM
19 00322201-01 PROTECTION CLIP LEFT
20 00320860-01 SLOTTED COUNTERSUNK HEAD
SCREW
21 00316187-01 SWIVEL DOOR SIPLACE 80F LEFT
SIDE
22 00314024-03 SIDE COVER
23 00314025-01 ROTARY AXLE
24 00304587-01 DIN EN ISO 7380-M5 X
12-10.9,VERCU/NI
25 00095565-01 HEXAGON NUT
26 00309802-01 CROSS RECESSED RAISED CHEESE
HEAD SCREW
27 00095564-01 HEXAGON NUT
28 00314029-01 BAR CODE STRIP 2/1
Protection hood output side left
Page 7 / 8 18.11.2021
Pos. Item no. Description Part marking
29 00322203-01 PROTECTION CLIP LEFT
30 00322196-01 SHIM
31 00316190-01 SWIVEL DOOR SIPLACE 80F RIGHT
SIDE
32 00322286-01 SIDE COVER
33 00314025-01 ROTARY AXLE
34 00304587-01 DIN EN ISO 7380-M5 X
12-10.9,VERCU/NI
35 00095565-01 HEXAGON NUT
36 00309802-01 CROSS RECESSED RAISED CHEESE
HEAD SCREW
37 00095564-01 HEXAGON NUT
38 00314028-01 BAR CODE STRIP 2/2 COMPL.
39 00322202-01 PROTECTION CLIP RIGHT
40 00322196-01 SHIM
41 00314026-01 BEARING
42 00845025-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 10-8.8
43 00314031-03 STAY LEFT
44 00314034-01 PLATE Spare Part
48 00314033-02 SPRING (ELASTOMER)
49 00314030-02 PEDESTAL 1
51 00314032-02 PEDESTAL 2
53 00314036-01 SHIM SPARE PART
54 00314027-03 STAY RIGHT
55 00304579-02 SUPPORT PLATE RIGHT BEHIND
56 00304581-02 SUPPORT PLATE RIGHT FRONT
57 00304585-01 LEVELLING PLATE
59 00304599-01 ACTUATING LEVER
60 00304600-01 ACTUATING LEVER LEFT
61 00304602-01 ACTUATING LEVER
62 00304621S01 FLANGE
63 00310867-01 COVER PLATE RIGHT SIDE Spare Part
64 00310868-01 COVER PLATE LEFT SIDE Spare Part
65 00320816-04 HINGED COVER LONG
66 00304577-01 FLEXIBLE ACTUATOR AZ 15/16 SPARE PART
Protection hood output side left
Page 8 / 8 18.11.2021
Pos. Item no. Description Part marking
67 00300491-03 PLATE
68 00304188-01 MOUNTING FOOT 22*4,3*14 STANDARD PARTS
69 00303617-03 HOOD SWITCH OUTPUT Spare Part
70 00301636-04 HOOD SWITCH (LEFT SIDE)
71 00301637-04 HOOD SWITCH (RIGHT SIDE)
72 00303614-03 HOOD SWITCH INPUT Spare Part
73 00303616-03 HOOD SWITCH (RIGHT SIDE)
