Bulkcase Feeder Module
Page 11 / 13 19.11.2021
Pos. Item no. Description Part marking
29 00321272S03 STRIP SPARE PART
30 00332913S01 WINDOW F. BULK-CASE
00321289-03 FUNNEL CASE 0805/045
31 00305213S01 O-RING 5*1 NBR 7 WEAR PART
00142324S02 FEEDING RAIL CHIP 0805 0,66MM Retrofit Kit
00321364-01 COMPONENTS RAIL COMPLETE
0805/060
00334062-01 COMPONENTS RAIL 0805/0,60
PREASSEMBLED
00321348-02 RAIL UNIT 0805/060
32 00321274S01 COVER
33 00321268S01 HOLDING-DOWN DEVICE
34 00321676S01 TENSION SPRING
35 00320880S01 PC-BOARD FOR LIGHT BARRIER
36 00321370S01 LIGHT BARRIER COMPLETE
37 00321339-02 CHANNEL COVER Spare Part
00321307-02 COMPONENTS SEPARATION
0805/060
38 00321272S03 STRIP SPARE PART
39 00332913S01 WINDOW F. BULK-CASE
00321290-02 FUNNEL CASE 0805/060
40 00305213S01 O-RING 5*1 NBR 7 WEAR PART
00142325S02 FEEDING RAIL CHIP 0805 0,85MM Retrofit Kit
00321365-01 COMPONENTS RAIL COMPLETE
0805/085
00334063-01 COMPONENTS RAIL 0805/0,85
PREASSEMBLED
00321349-02 RAIL UNIT 0805/085
41 00321274S01 COVER
42 00321268S01 HOLDING-DOWN DEVICE
43 00321676S01 TENSION SPRING
44 00320880S01 PC-BOARD FOR LIGHT BARRIER
45 00321370S01 LIGHT BARRIER COMPLETE
46 00321339-02 CHANNEL COVER Spare Part
00321308-02 COMPONENTS SEPARATION
0805/085
47 00321272S03 STRIP SPARE PART
Bulkcase Feeder Module
Page 12 / 13 19.11.2021
Pos. Item no. Description Part marking
48 00332913S01 WINDOW F. BULK-CASE
00321291-02 FUNNEL CASE 0805/085
49 00305213S01 O-RING 5*1 NBR 7 WEAR PART
00142326S02 BULK-CASE COMPONENTS FEEDING
0805/125
00321366-01 COMPONENTS RAIL COMPLETE
0805/125
00334064-01 COMPONENTS RAIL 0805/1,25
PREASSEMBLED
00321350-02 RAIL UNIT 0805/125
50 00321274S01 COVER
51 00321268S01 HOLDING-DOWN DEVICE
52 00321676S01 TENSION SPRING
53 00320880S01 PC-BOARD FOR LIGHT BARRIER
54 00321370S01 LIGHT BARRIER COMPLETE
55 00321339-02 CHANNEL COVER Spare Part
00321309-02 COMPONENTS SEPARATION
0805/125
56 00321272S03 STRIP SPARE PART
57 00332913S01 WINDOW F. BULK-CASE
00321293-02 FUNNEL CASE 0805/125
58 00305213S01 O-RING 5*1 NBR 7 WEAR PART
00142327S02 BULK-CASE COMP.TRANSP.MICRO-
MEL F
00321367-01 COMPONENTS RAIL COMPLETE
MICRO-MELF
00334066-01 COMPONENTS RAIL MICRO-MELF
PREASSEMBLED
00321351-01 RAIL UNIT MICRO-MELF
59 00321274S01 COVER
60 00321268S01 HOLDING-DOWN DEVICE
61 00321676S01 TENSION SPRING
62 00320880S01 PC-BOARD FOR LIGHT BARRIER
63 00321370S01 LIGHT BARRIER COMPLETE
64 00321339-02 CHANNEL COVER Spare Part
00321310-02 COMPONENTS SEPARATION MICRO-
MELF
65 00321272S03 STRIP SPARE PART
Bulkcase Feeder Module
Page 13 / 13 19.11.2021
Pos. Item no. Description Part marking
66 00332913S01 WINDOW F. BULK-CASE
00321294-01 FUNNEL CASE MICRO-MELF
67 00305213S01 O-RING 5*1 NBR 7 WEAR PART
00142328S02 FEEDING RAIL MINI-MELF Retrofit Kit
00321368-01 COMPONENTS RAIL COMPLETE MINI-
MELF
00334069-01 COMPONENTS RAIL MINI-MELF
PREASSEMBLED
00321352-02 RAIL UNIT MICRO-MELF
68 00321274S01 COVER
69 00321268S01 HOLDING-DOWN DEVICE
70 00321676S01 TENSION SPRING
71 00320880S01 PC-BOARD FOR LIGHT BARRIER
72 00321370S01 LIGHT BARRIER COMPLETE
73 00321344S03 CHANNEL COVER FOR MINI-MELF
00321311-02 COMPONENTS SEPARATION MINI-
MELF
74 00321272S03 STRIP SPARE PART
75 00332913S01 WINDOW F. BULK-CASE
00321295-02 FUNNEL CASE MINI-MELF
76 00305213S01 O-RING 5*1 NBR 7 WEAR PART
