8C-7
I･pulse F1 Series
F1-44 (C type)
P 3
No. Code No. Parts Name Q'ty Parts No.
LG4-M6A30-010
HOLD LEVER ASSY 1 AS-A24-8190-C
LG4-M8A3A-002
CLAMP LEVER ASSY 1 AS5-A24-8191-B
1 K87-M111G-100 PUSH PIN 1
CTF-M08- 325
2
LG4-M1A1K-000
LEVER AXIS PIN 1
FTA-A08-8130-B
3
LG4-M1A3A-000 HINGE PIN 1
1
FTA-A08-8191-1
4
LG4-M1A3B-000 HINGE PIN 2
1
FTA-A08-8192-1
5
LG4-M1A36-000 ARM
1
FTA-A08-8193
6
LG4-M1A33-000 LINK PLATE
1
FTA-A08-8194
7
LG4-M1A3L-000 CLANK ARM AXIS PIN
1
FTA-A08-8195
8
LG4-M1A37-000 ADJUST CLAMP PIN
1
FTA-A08-8196
9
LG4-M1A3K-001 CLAMP LEVER AXIS PIN
1 FTA-A08-8197-B
10 LG4-M6A31-010 HOLD LEVER
1 FTA-A24-8190-C
11
LG4-M6A3B-001 CLAMP LEVER
1 FTA-A24-8191-B
12
LG4-M8A3D-000
STUD 1 FTA-A44-8191
13
LG4-M6A3M-000
SCREW COIL SPRING 1
FTA-A24-8191-SCSp
14 LG4-M6A3C-001 CLANK ARM
1 FTA-A24-8192-B
15
LG4-M6A32-000 LINK PIN T
1
FTA-A24-8198
16
LG4-M6A39-000 LINK PIN U
1
FTA-A24-8199
17 K87-M111T-000 SCREW,SET 1 3MY-3-F
18
K87-M111R-000 SCREW,SET 2 3MY-5-F
19 K87-M21BN-000
SCREW NUT
1
3MH-P
20 K87-M21BM-000 SPRING LOCK WASHER 1
3MU-P
21
22
23
24
25
26
27
28
29
30
31
32
8C-6
8C-7
I･pulse F1 Series
F1-44 (C type)
P 4
No. Code No. Parts Name Q'ty Parts No.
LG4-M8A40-001
Tape Guide Assy 1 AS-A44-8119-C
1 LG4-M7A46-001 Lock Lever
1
FTA-A32-8127-B
LG4-M1A48-001 T.G. PUSH SPRING
1
FTA-A08-8127-50
LG4-M6A48-000 T.G. PUSH SPRING
1
FTA-A24-8127-73
3
LG4-M1A4K-000 T.G.A. Guide Pin
1
FTA-A08-8129
4
LG4-M7A43-000 Shutter Piece
1
FTA-A32-8120-1
5 KW1-M4548-000
Rivet
2
FTA-A24-1120-2
6 KW1-M4549-000
Shutter Guide
1
FTA-A24-1120-3
7 KW1-M4544-000
Shutter Guide Pin
2
FTA-A24-1122-B
8
LG4-M8A41-001
Tape Guide Plate 1
FTA-A44-8119-C
9
LG4-M8A42-001
Shutter Plate 1
FTA-A44-8120-B
10
LG4-M6A49-001 Cover Plate
1
FTA-A24-8123-B
11
LG4-M6A4L-000 Tape Guide Axis Pin
2
FTA-A24-8124
12
LG4-M6A47-000 T.G. Guide Pin
1
FTA-A24-8125
13 K87-M1547-000 Screw,Truss Head 2 T2M-2.5-P
14 K87-M1548-000 Plane Washer 2 2MV(2V-0.4-6-P)
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
※1．．．F1-44-301C～
※1
2
