MODEL GXH-1JS 0710-003 144 カバー部 COVER SECTION Fig. G-6 カバー部（手前） Cover Section-Front 559 557 558 551 564 . 573 . 578 564 . 573 . 578 563 . 572 . 577 578 . 573 . 565 563 . 572 . 577 578 . 573 . 565 516 517 519 520 519 570 …
MODEL GXH-1JS
1012-005
143
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
307 6301360126 COVER 1 829G--010-007 211A9663
308 6301360133 COVER 1 829G--010-008 211A9664
317 6301472881 STAY 1 829G--010-617 211J1401
318 6301473185 STAY 1 829G--010-618 211J1404
319 6301368023 STAY 1 829G--010-619 211J1297
320 6301369532 STAY 1 829G--010-620 211J1300
326 6301336909 BRACKET 2 829G--010-626 211F9331
330 6301382470 FRAME 1 829G--010-600 210B3910
331
6301363776 COVER 1 829G--010-601 211A9701
332 6301363783 COVER 1 829G--010-602 211A9702
335 6301364131 COVER 1 829G--010-605 211A9717
336 6301364148 COVER 1 829G--010-606 211A9718
337 6301458649 COVER 1 829G--010-607 211AA751
338 6301458656 COVER 1 829G--010-608 211AA752
339 6301336824 PLATE 2 829G--010-039 211DA241
343 6301364414 PLATE 1 829G--010-643 211DA535
351 6300002713 SWITCH,BUTTON 2 -S111
829G--010-151 4S1B0032
352 6300000382 ACCESSORY,SW 2 829G--010-152 23H20003
354
6301251752 PILOT LAMP 1 H1 829G--010-154 4T3A0205
356 6301231341 PILOT LAMP 2 829G--010-156 4T3A0201
361
6300007619 BOLT,HEX-SCT 10 M4X8 221A0016
362
6300007732 BOLT,HEX-SCT 12 M5X8 221A0028
363
6300007756 BOLT,HEX-SCT 8 M5X12 221A0030
364
6300007879 BOLT,HEX-SCT 12 M6X12 221A0042
365
6300007886 BOLT,HEX-SCT 4 M6X16 221A0043
366
4111139109 SCR TRS 5X10 10 M5X10 TRS 221E0534
367 4111410307 NUT HEX 4 6 M4 221E0533
371
4111412905 WASHER SPR 4 12 SW4 221H0284
372
4111416705 WASHER SPR 5 20 SW5 221H0287
373
4111413001 WASHER SPR 6 16 SW6 221H0289
376
4111414008 WASHER V 4X9X0.8 12 FW4 221H0315
377
4111414107 WASHER V 5X10X1 20 FW5 221H0318
378
4111414305 WASHER V 6X12.5X1.6 16 FW6 221H0320
G-4
MODEL GXH-1JS
0710-003
144
カバー部
COVER SECTION
Fig. G-6
カバー部（手前）
Cover Section-Front
559
557
558
551
564
.
573
.
578
564
.
573
.
578
563
.
572
.
577
578
.
573
.
565
563
.
572
.
577
578
.
573
.
565
516
517
519
520
519
570
521
521
570
521
570
520
521
570
516
517
522
522
522
522
561
.
571
.
576
562
.
571
568
.
572
568
.
572
.
576
567
.
572
.
577
567
.
572
.
577
528
505
MODEL GXH-1JS
1012-005
145
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
505 6300885361 ACCESSORY,SW (KEY) 1 829G--010-405 23H20053
516 6301491226 BRACKET 2 829G--010-016 211FB239
517 6301491240 PIN,HINGE 2 829G--010-017 216D0546
519
6301491233 BRACKET 2 829G--010-019 211DB240
520 6301265346 BLOCK 2 829G--010-020 211G3493
521 6301508740 PIN,HINGE 4 829G--010-021 216D0550
522
4110010409 RING E 6 4 829G--010-062 221K0099
528
6301273136 PLATE 1 829G--010-028 211D9630
551 6300764932 ACCESSORY,MOT-M 1 829G--010-161 23M00038
557
6300684278 MOTOR,INDUCTION 1 M102 829G--010-157 4M100029
558 6300684292 ACCESSORY,MOT-M 1 829G--010-158 23M00033
559
6300746853 ACCESSORY,MOT-M (FILTER) 1 829G--010-159 23M00037
561
6300007619 BOLT,HEX-SCT 2 M4X8 221A0016
562
6300007626 BOLT,HEX-SCT 2 M4X10 221A0017
563
6300007770 BOLT,HEX-SCT 8 M5X20 221A0032
564
6300007862 BOLT,HEX-SCT 4 M6X10 221A0041
565
6300007893 BOLT,HEX-SCT 4 M6X20 221A0044
566
4110436803 SCR PAN 5X12 4 M5X12 PAN 221E051
1
567 4111406409 SCR PAN 5X16 4 M5X16 PAN 221E0512
568 4111410505 NUT HEX 5 8 M5 221F0085
569
6300008883 SET SCREW 4 M3X4 SET 221C0001
570 6300082296 SET SCREW 4 M4X4 SET 221C0027
571 4111412905 WASHER SPR 4 4 SW4 221H0284
572
4111416705 WASHER SPR 5 8 SW5 221H0287
573
4111413001 WASHER SPR 6 8 SW6 221H0289
576
4111414008 WASHER V 4X9X0.8 4 FW4 221H0315
577
4111414107 WASHER V 5X10X1 20 FW5 221H0318
578
4111414305 WASHER V 6X12.5X1.6 8 FW6 221H0320
G-6
