MODEL GXH-1JS 1012-005 231 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE 461 6301464664 CORD 1 829FE-010-361 4W203589 466 6301494050 CORD 1 829F--010-166 4W203680 467 6301494067 CORD 1 829F--010-167 4W203681 …
MODEL GXH-1JS
0804-003
230
操作パネル部
A OPERATING PANEL SECTION
Fig. FE-5
ケーブル
Cable
467
466
461
See Fig.BS-5
Key No.458
See Fig.BS-5
Key No.456
See Fig.FE-4
Key No.311
See Fig.BL-6
Key No.588
X7403
X7401
X0101
X1102
X1101
X0102
MODEL GXH-1JS
1012-005
231
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
461 6301464664 CORD 1 829FE-010-361 4W203589
466 6301494050 CORD 1 829F--010-166 4W203680
467
6301494067 CORD 1 829F--010-167 4W203681
FE-5
MEMO
