MODEL GXH-1JS 0701-002 94 コンベア部 CONVEYOR SECTION Fig. N-8 NA シュート１ NA Chute 1 754 . 767 . 772 759 . 768 . 773 760 . 769 . 774 753 . 767 . 772 758 . 767 . 772 758 . 767 . 772 707 714 715 716 721 71 1 712 727 718 717 712 7…
MODEL GXH-1JS
1012-006
93
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
N-7
604 6301618272 BRACKET(PLATE) 1 829N--010-004 211FD107
605 6301233192 SHAFT 3 829N--010-005 213A1012
606
6301644103 COLLAR 3 829N--010-006 216A1586
607
6301644127 COLLAR 3 829N--010-007 216A1587
608
6301517117 PLATE 1 829N--010-008 211DC322
609 6301415598 BASE 2 829N--010-009 210A2461
610
6301233178 ROD 1 829N--010-010 216C0696
614
6301233055 COLLAR 1 829N--010-014 216A11
13
616 6301626208 BALL SCREW 4 829N--010-016 223B0423
619
6301532097 PULLEY,TIMING 1 829N--010-019 223Q0705
620
6301498089 PULLEY,TIMING 4 829N--010-020 223Q0681
621
6301236803 BELT,TIMING 1 829N--010-021 223L0263
623
6301002729 MOTOR,AC-SERVO 1 -M53 829N--010-023 4M150130
625 6300969009 BEARING,RADIAL 6 829N--010-025 222D0343
641
6301621685 COLLAR 3 829N--010-041 216A1552
651
6300007558 BOLT,HEX-SCT 4 M3X16 221A0010
652
6300007619 BOLT,HEX-SCT 16 M4X8 221A0016
653
6300007626 BOLT,HEX-SCT 2 M4X10 221A0017
654
6300007640 BOLT,HEX-SCT 24 M4X14 221A0019
655
6300007671 BOLT,HEX-SCT 16 M4X25 221A0022
656
6300007749 BOLT,HEX-SCT 2 M5X10 221A0029
657
6300007886 BOLT,HEX-SCT 4 M6X16 221A0043
658
6300008012 BOLT,HEX-SCT 1 M8X20 221A0056
661
4111412905 WASHER SPR 4 58 SW4 221H0284
662
4111416705 WASHER SPR 5 2 SW5 221H0287
663
4111413001 WASHER SPR 6 4 SW6 221H0289
664
4111413100 WASHER SPR 8 1 SW8 221H0291
666
4111414008 WASHER V 4X9X0.8 42 FW4 221H0315
667
4111414107 WASHER V 5X10X1 2 FW5 221H0318
668
4111414305 WASHER V 6X12.5X1.6 4 FW6 221H0320
669
4111414503 WASHER V 8X17X1.6 1 FW8 221H0323
676
4111409905 NUT HEX 3 4 M3 221F0079
677
6300008944 SET SCREW 2 M5X6 SET 221C0007
MODEL GXH-1JS
0701-002
94
コンベア部
CONVEYOR SECTION
Fig. N-8 NA
シュート１
NA Chute 1
754
.
767
.
772
759
.
768
.
773
760
.
769
.
774
753
.
767
.
772
758
.
767
.
772
758
.
767
.
772
707
714
715
716
721
711
712
727
718
717
712
720
719
742
732
736
724
740
741
749
755
750
746
733
704
760
.
769
.
774
757
748
725
709
705
705
722
729
751
.
766
.
771
738
759
.
768
.
773
MODEL GXH-1JS
1012-004
95
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
N-8
704 6301315669 BLOCK 1 829N--010-104 211G3758
705 6301232652 PLATE 2 829N--010-105 211D9252
707 6301315690 SHAFT 4 829N--010-107 213A1126
709 6301233253 SPRING,COMP 4 829N--010-109 222M1297
71
1 6301236933 GUIDE,SLIDE 4 829N--010-111
222C0106
712 6301237022 SENSOR,PELEC 2 -B4201,-B4202
829N--010-112 23G00241
714 6300701838 SEAL 4 829N--010-114 226A0124
715 6300033212 SEAL 4 829N--010-115 226A0003
716 6300701845 SEAL 4 829N--010-116 226A0125
717 6301236889 CAP 4 829N--010-117 217A0128
718 6301241371 BOLT,HEX-SCT(BUTTON HEAD) 11 829N--010-118 221A0319
719
6300484656 PIPE FITTINGS 6 829N--010-119 225F0261
720 6300769029 PIPE FITTINGS 3 829N--010-120 225F0330
721
6300465556 PIPE FITTINGS 1 829N--010-121 225F0253
722
6301274478 TUBE 1 829N--010-232 225G0275
724
6301236445 PULLEY,TIMING 1 829N--010-304 223Q0540
725
6301246352 COLLAR 1 829N--010-235 216A1127
727 6301315539 PLATE 1 829N--010-102 211DA002
729 6301614175 SPACER 5 829N--010-439 211E1
117
732 6301336664 BLOCK 1 829N--010-202 211G3899
733 6301365954 BLOCK 1 829N--010-203 211G4038
736 6301337135 BELT,TIMING 1 829N--010-306 223L0283
738
6301360362 PLATE 1 829N--010-238 211DA512
740 6301337029 BRACKET 1 829N--010-210 211F9334
741 6301241340 MOTOR,AC-SERVO 1 -M56 829N--010-231 4M150196
742 6301358352 BRACKET 1 829N--010-212 211F9568
746 6301337050 BRACKET 1 829N--010-216 211F9337
748 6301236599 BALL SCREW 1 829N--010-218 223B0350
749
6301236698 BEARING,UNIT 1 829N--010-219 222F0089
750
6301236452 PULLEY,TIMING 1 829N--010-305 223Q0541
751
6300007510 BOLT,HEX-SCT 2 M3X8 221A0006
753
6300007619 BOLT,HEX-SCT 2 M4X8 221A0016
754
6300007626 BOLT,HEX-SCT 2 M4X10 221A0017
755
6300007633 BOLT,HEX-SCT 4 M4X12 221A0018
757
6300007657 BOLT,HEX-SCT 4 M4X16 221A0020
758
6300007657 BOLT,HEX-SCT 8 M4X16 221A0020
759
6300007749 BOLT,HEX-SCT 4 M5X10 221A0029
760
6300007893 BOLT,HEX-SCT 4 M6X20 221A0044
766
4111412806 WASHER SPR 3 2 SW3 221H0281
767
4111412905 WASHER SPR 4 12 SW4 221H0284
768
4111416705 WASHER SPR 5 4 SW5 221H0287
769
4111413001 WASHER SPR 6 4 SW6 221H0289
771
4111413902 WASHER V 3X7X0.5 2 FW3 221H0312
772
4111414008 WASHER V 4X9X0.8 12 FW4 221H0315
773
4111414107 WASHER V 5X10X1 4 FW5 221H0318
774
4111414305 WASHER V 6X12.5X1.6 4 FW6 221H0320
