Tape Feeder Module 24/32 mm S
Page 6 / 8 19.11.2021
Pos. Item no. Description Part marking
1 00141193S01 TAPE FEEDER MODULE 24/32MM S
DP
Spare Part
2 00375641S02 DRIVE UNIT SPARE PART
3 00325382S01 PRESSURE SPRING 0.5X3.5X20.7 SPARE PART
4 00328214-02 RUBBER BUFFER WEAR PART
5 00324931S01 TRANSMITTER UNIT SPARE PART
00324932-01 TRANSMITTER BLOCK
00327134-01 STOP UNIT
00327135-01 GUIDE
00310857-01 STOP PIN
6 00308948S01 PRESSURE SPRING 0.16X1.36X6.7 SPARE PART
00309127-01 SLOT-TYPE LIGHT BARRIER
7 00376294S01 SPRING PLATE (DPF) SPARE PART
00376311-01 SUPPORT BLOCK 24/32 (DPF)
8 00376312-01 SPRING PLATE 24/32 (DPF)
9 00376313-01 SPRING PLATE SINGLE PART 24/32
(DPF)
00376300-01 TAPE DISPOSAL, COMPLETE (DPF)
00322251-02 STRIPPING DEVICE 1, COMPLETE
10 00376301S01 SUPPORT FOR ROCKER 1 ASSY
(DPF)
SPARE PART
11 00322355S02 SUPPORT PLATE FOR ROCKER 1 SPARE PART
12 00309104S01 PRESSURE SPRING 0.6X5.6X18 V2A SPARE PART
13 00322245S01 ADJUSTING SCREW SPARE PART
14 00375637-01 LIGHT BARRIER TAPE DISPOSAL
(DPF)
15 00322440S01 ROCKER 1 ASSY, 24/32MM FEEDER SPARE PART
00325689-01 SUPPORT FOR TOOTHED WHEEL
ASSY, COMPLETE
00322547-03 SUPPORT PLATE FOR TOOTHED
WHEEL ASSY
16 00322359S01 SHAFT FOR ROCKER 2, 24/32MM
TAPE
SPARE PART
00322360-02 SHAFT FOR FIXED TOOTHED WHEEL
17 00322446S01 ROCKER 2 ASSY, 24/32MM FEEDER SPARE PART
18 00332394S01 STRIPPER SHEET METAL 1 SPARE PART
00322384-02 ROCKER 2 SPARE PART
Tape Feeder Module 24/32 mm S
Page 7 / 8 19.11.2021
Pos. Item no. Description Part marking
00322231-02 COVER 1, COMPLETE
00322251-02 STRIPPING DEVICE 1, COMPLETE
19 00322392-03 TOOTHED WHEEL 2
00302716-01 FREE WHEEL
00326995S02 BEARING BUSH SPARE PART
00322388S01 LID
20 00322450S02 GEARWHEEL 1 ASSY SPARE PART
00322454-01 MOTOR, COMPLETE
21 00350834S01 STRIP REMOVAL MOTOR, 24-32MMS
PREASSMBL.
SPARE PART
00322410-01 COVER PLATE
00325556-01 PROFILE, TOP, COMPLETE
22 00322359S01 SHAFT FOR ROCKER 2, 24/32MM
TAPE
SPARE PART
00322418S03 FLAP SPARE PART
00322419-01 PROFILE, BOTTOM
23 00332348S01 STRIPPER SHEET METAL 2 SPARE PART
24 00325454S01 CONNECTING CABLE 12-88MM S-
FEEDER
SPARE PART
25 00375636-01 CHAIR PROFILE 24-72MMS WITH
PINS (DPF)
Spare
26 00376332-01 COUNTERPLATE 24/32 WITH
PRESSED-IN PINS
SPARE PART
00376295S01 SPACER, FRONT (DPF) SPARE PART
27 00322249S01 TAPE SUPPORT SPARE PART
00322263-01 TAPE CHANNEL, TOP
28 00325701S02 CENTERING PLATE ASSY SPARE PART
29 00322343S01 SPECIAL SCREW SPARE PART
00325554-02 COVER PROFILE SPARE PART
30 00322274S02 TAPE CLIP FOR 24MM TAPE FEEDER SPARE PART
31 00322502S01 SPHERICAL CAP SPARE PART
32 00377202-01 CONTROL PANEL (DPF)
00328094-01 SEALING 12/56 S
33 00301621-01 BELT BIN PLUG-IN AXIS 24/32 MM Spare Part
00330774-01 SHEET METAL PLATE FOR TAPE
SUPPORT COMPLETE
34 00309103S01 PRESSURE SPRING 0.5X3.5X20.7 SPARE PART
Tape Feeder Module 24/32 mm S
Page 8 / 8 19.11.2021
Pos. Item no. Description Part marking
V2A
35 00322226S01 TAPE SPRING FOR 24/32MM FEEDER SPARE PART
36 00322746S01 LONG-LOK SCREW SPARE PART
00322246S03 TAPE SUPPORT, BOTTOM, BACK SPARE PART
00322269-01 TAPE CHANNEL, BOTTOM MIDDLE
00325542-01 SIDE PANEL 1
00325545-01 TAPE CHANNEL, BOTTOM FRONT
SIDE
37 00322119S07 CONTROL FOR 12-56MM S TAPE
FEEDER
SPARE PART
38 00375633-01 DISTRIBUTOR BOARD F. 12-56 MM S
TAPE (DPF)
39 00376296-01 LOCK, COMPLETE 24/32 (DPF)
40 00323208S04 PICKUP WINDOW SPARE PART
00322741-04 WINDOW FLAP
41 00322705S02 FILLER BLOCK SPARE PART
00322337-01 CABLE COVER 1
00341735-01 CABLE COVER 2 COMPLETE
42 00330620S01 PRESSURE SPRING 0.7X3.5X19 SPARE PART
43 00331114S01 LONG-LOK SCREW WITH SLIT SPARE PART
44 00332583S01 SEALING TRANSMITTER BLOCK SPARE PART
45 00341861S01 LEVER FOR FOIL CONTAINER SPARE PART
46 00349083S01 COVER PLATE - DRIVE UNIT SPARE PART
00376299-01 COVER PLATE BOTTOM 24/32 (DPF)
00375740-01 MOUNT FOR COVER PLATE BOTTOM
(DPF)
