User Manual 4022 591 98247 144 PPS-Pro v8.2 05.07 Guidelines for using PPS-Pro T ABLE 12 Intellig ent Sti ck Feeders/Machin e relation A.2.4 Bulk Feeder s This table d escribes which Bulk-F eeder s Assembléon has, the si…
4022 591 98247 User Manual
05.07 PPS-Pro v8.2 143
Guidelines for using PPS-Pro
A.2.3 Stick Feeders
This table describes which Intelligent- and Multi- Stick Feeders Assembléon
has, the size relative to the pick-position (mm) and which machine they fit
on.
Feeder Name Desc. FCM-II FCM-IIM FCM-IIXM ACM D9 AQ-1 AX
ISF2_10 ISF2 stick feeder
SOIC14/16
- - - X X X -
ISF2_15 ISF2 stick feeder
SOLIC
- - - X X X -
ISF2_20 ISF2 stick feeder
SOMIC
- - - X X X -
ISF2_25 ISF2 stick feeder
SOJ20/26
- - - X X X -
ISF2_30 ISF2 stick feeder
SOJ28/32
- - - X X X -
ISF2_35 ISF2 stick feeder
SOJ24/32
- - - X X X -
ISF2_40 ISF2 stick feeder
SOJ36/44
- - - X X X -
ISF2_45 ISF2 stick feeder
PLCC18
- - - X X X -
ISF2_50 ISF2 stick feeder
PLCC20
- - - X X X -
ISF2_55 ISF2 stick feeder
PLCC28/3
- - - X X X -
ISF2_60 ISF2 stick feeder
PLCC44
- - - X X X -
ISF2_65 ISF2 stick feeder
PLCC52
- - - X X X -
ISF2_70 ISF2 stick feeder
PLCC68
- - - X X X -
ISF2_75 ISF2 stick feeder
PLCC84
- - - X X X -
ISF2_80 ISF2 stick feeder
PLCC100
- - - X X X -
SF_SO08 SO-IC8 TOP PLATE - - - X X X -
SF_SO14 SO-IC14 TOP
PLATE
- - - X X X -
SF_SO16 SO-IC16 TOP
PLATE
- - - X X X -
SF_SOL16 SOL-IC16 TOP
PLATE
- - - X X X -
SF_SOL20 SOL-IC20 TOP
PLATE
- - - X X X -
User Manual 4022 591 98247
144 PPS-Pro v8.2 05.07
Guidelines for using PPS-Pro
TABLE 12 Intelligent Stick Feeders/Machine relation
A.2.4 Bulk Feeders
This table describes which Bulk-Feeders Assembléon has, the size relative to
the pick-position (mm) and which machine they fit on.
TABLE 13 Bulk Feeder/Machine relation
A.2.5 Tray Feeders
This table describes which default trays Assembléon has defined. These are
default names.
SF_SOL28 SOL-IC28 TOP
PLATE
- - - X X X -
SF_PL28 PLCC28 TOP
PLATE
- - - X X X -
SF_PL32 PLCC32 TOP
PLATE
- - - X X X -
SF_PL44 PLCC44 TOP
PLATE
- - - X X X -
SF_GEN GENERIC TOP
PLATE
- - - X X X -
WPF_2 ITF2 Waffle Pack
Feeder AIR
X X X
WPF_4 ITF2 Waffle Pack
Feeder AIR
X X X
Feeder Name Desc. FCM-II FCM-IIM FCM-IIXM ACM D9 AQ-1 AX
TBF2_C0201 FCM2 Twin Bulk
C0201
X X X - - - X
TBF2_R0201 FCM2 Twin Bulk
C0201
X X X - - - -
TBF2_C0402 Twin Bulk C0402 X X X - - - X
TBF2_R0402 Twin Bulk R0402 X X X - - - X
TBF2_C0603 Twin Bulk C0603 X X X - - - X
TBF2_R0603 Twin Bulk R0603 X X X - - - X
TBF2_C0805T060 Twin Bulk
C0805T060
X X X - - - X
TBF2_R0805 Twin Bulk R0805 X X X - - - X
TBF2_MELF0604 Twin Bulk
MELF0604
X X X - - - X
SBF2_C0805T125 Single Bulk
C0805
X X X - - - X
SBF2_MELF0805 Single Bulk
MELF0805
X X X - - - X
4022 591 98247 User Manual
05.07 PPS-Pro v8.2 145
Guidelines for using PPS-Pro
NOTE: A user must have the possibility to define his own named trays. These new
user trays should then be selectable on the required Tray-pallets.
Feeder Name FCM-II FCM-IIM FCM-IIXM ACM D9 AQ-1 AX
WAFER - - - X X - -
BQ23X23 - - - X X X -
BQ28X28 - - - X X X -
CQ28-52 - - - X X X -
CQ44-84 - - - X X X -
CQ52-100 - - - X X X -
CQ68 - - - X X X -
CQ68-132 - - - X X X -
CQ84-164 - - - X X X -
MQ10X10 - - - X X X -
MQ10X10H - - - X X X -
MQ14X14 - - - X X X -
MQ14X14H - - - X X X -
MQ14X20 - - - X X X -
MQ14X20H - - - X X X -
MQ28X28 - - - X X X -
MQ28X28H - - - X X X -
MQ32X32 - - - X X X -
MQ40X40 - - - X X X -
PB23X23 - - - X X X -
PB27X27 - - - X X X -
PB35X35 - - - X X X -
PQ100 - - - X X X -
PQ132 - - - X X X -
PQ164 - - - X X X -
PQ196 - - - X X X -
PQ244 - - - X X X -
PQ52 - - - X X X -
PQ68 - - - X X X -
PQ84 - - - X X X -
TQ05X05 - - - X X X -
TQ07X07 - - - X X X -
TQ10X10 - - - X X X -
TQ12X12 - - - X X X -
TQ14X14 - - - X X X -
TQ14X20 - - - X X X -
TQ20X20 - - - X X X -
TS06X16 - - - X X X -
TS08X20 - - - X X X -
