4022 591 98247 User Manual
05.07 PPS-Pro v8.2 149
Guidelines for using PPS-Pro
A.3.2 FCM-II TEU
TEU (Toolbit Exchange Unit) for FCM-II type machines do not exist.
A.3.3 ACM, AQ-1 and D9 Nozzles
This table describes which Nozzles can be configured for ACM, AQ-1 and D9.
These nozzles can be configured for ALL 3 ACM machine types.
Nozzle Name Desc.
O1I1 Inner-1 Outer-1 combination
O1I2 Inner-2 Outer-1 combination
O1I3 Inner-3 Outer-1 combination
O1I4 Inner-4 Outer-1 combination
O1I5 Inner-5 Outer-1 combination
O1I6 Inner-6 Outer-1 combination
O1I7 Inner-7 Outer-1 combination
O1I8 Inner-8 Outer-1 combination
O1I9 Inner-9 Outer-1 combination
O1I10 Inner-10 Outer-1 combination
O2I1 Inner-1 Outer-2 combination
O2I2 Inner-2 Outer-2 combination
O2I3 Inner-3 Outer-2 combination
O2I4 Inner-4 Outer-2 combination
O2I5 Inner-5 Outer-2 combination
O2I6 Inner-6 Outer-2 combination
O2I7 Inner-7 Outer-2 combination
O2I8 Inner-8 Outer-2 combination
O2I9 Inner-9 Outer-2 combination
O2I10 Inner-10 Outer-2 combination
O3I1 Inner-1 Outer-3 combination
O3I2 Inner-2 Outer-3 combination
O3I3 Inner-3 Outer-3 combination
O3I4 Inner-4 Outer-3 combination
O3I5 Inner-5 Outer-3 combination
O3I6 Inner-6 Outer-3 combination
O3I7 Inner-7 Outer-3 combination
O3I8 Inner-8 Outer-3 combination
O3I9 Inner-9 Outer-3 combination
O3I10 Inner-10 Outer-3 combination
O4I1 Inner-1 Outer-4 combination
O4I2 Inner-2 Outer-4 combination
O4I3 Inner-3 Outer-4 combination
O4I4 Inner-4 Outer-4 combination
O4I5 Inner-5 Outer-4 combination
O4I6 Inner-6 Outer-4 combination
O4I7 Inner-7 Outer-4 combination
O4I8 Inner-8 Outer-4 combination
User Manual 4022 591 98247
150 PPS-Pro v8.2 05.07
Guidelines for using PPS-Pro
O4I9 Inner-9 Outer-4 combination
O4I10 Inner-10 Outer-4 combination
O5I1 Inner-1 Outer-5 combination
O5I2 Inner-2 Outer-5 combination
O5I3 Inner-3 Outer-5 combination
O5I4 Inner-4 Outer-5 combination
O5I5 Inner-5 Outer-5 combination
O5I6 Inner-6 Outer-5 combination
O5I7 Inner-7 Outer-5 combination
O5I8 Inner-8 Outer-5 combination
O5I9 Inner-9 Outer-5 combination
O5I10 Inner-10 Outer-5 combination
S1 Special Nozzle
S2 Special Nozzle
S3 Special Nozzle
FC1 Force Control nozzle1
FC2 Force Control nozzle2
FC3 Force Control nozzle3
FC4 Force Control nozzle4
SQ500 Soft Solder Nozzle Small
SQ900 Soft Solder Nozzle Large
G1 Gripper 1
G2 Gripper 2
G3 Gripper 3
G4 Gripper 4
G5 Gripper 5
G6 Gripper 6
G7 Gripper 7
G8 Gripper 8
G9 Gripper 9
G10 Gripper 10
G11 Gripper 11
G12 Gripper 12
G13 Gripper 13
G14 Gripper 14
G15 Gripper 15
G16 Gripper 16
G17 Gripper 17
G18 Gripper 18
G19 Gripper 19
G20 Gripper 20
GS1 Special Gripper 1
GS2 Special Gripper 2
GS3 Special Gripper 3
GS4 Special Gripper 4
GS5 Special Gripper 5
4022 591 98247 User Manual
05.07 PPS-Pro v8.2 151
Guidelines for using PPS-Pro
TABLE 17 Nozzle for ACM, AQ and D-9
A.3.3.1 ACM, AQ and D9 TEU
On these 3 machine types a TEU (Toolbit Exchange Unit) CAN be defined. The
names of the TEU are not fixed (can be any name), but a good example would
be just TEU. These TEU contain 10 nozzle positions. On each position can be
any of the above-mentioned nozzles, depending on the size of the nozzle,
defined. The nozzles must be within a certain size (and shape!), otherwise
they don’t fit in the TEU.
TABLE 18 ACM, AQ-1,D-9 TUE / Nozzle relation
GS6 Special Gripper 6
GS7 Special Gripper 7
GS8 Special Gripper 8
GS9 Special Gripper 9
GS10 Special Gripper 10
GS11 Special Gripper 11
GS12 Special Gripper 12
GS13 Special Gripper 13
GS14 Special Gripper 14
GS15 Special Gripper 15
GS16 Special Gripper 16
GS17 Special Gripper 17
GS18 Special Gripper 18
GS19 Special Gripper 19
GS20 Special Gripper 20
<TEU> Nozzle
Position 1 Any Nozzle
Position 2 Any Nozzle
Position 3 Any Nozzle
Position 4 Any Nozzle
Position 5 Any Nozzle
Position 6 Any Nozzle
Position 7 Any Nozzle
Position 8 Any Nozzle
Position 9 Any Nozzle
Position 10 Any Nozzle
